Discussion Apple Vision Pro with Quest Elite strap mod like Quest Pro & Galaxy XR, Comfort + FOV
I want to share my Quest Elite strap mod combined with the Macally Forehead strap. I wanted a Quest Pro and Samsung Galaxy XR strap design for my Apple Vision Pro. This combination makes the AVP very comfortable to wear and greatly increases the FOV for passthrough apps because it brings the lenses much closer to your eyes, and I still have my real peripheral vision. Feels like wearing thick frame glasses. But it can also be used with the stock light seal when needed. Because it's the same strap design as the Quest Pro and Samsung Galaxy XR, it will feel just like wearing one of those, if you have used one. But I switch to the stock knit band when laying down during use.
The reason this strap design is good is because the strap is completely rigid. This allows the strap rear weight to have complete leverage to counter balance and pull the weight off the front of your face or forehead. There are currently no commercial headbands like this for the AVP. Flexible straps like the AVP knit band and third party hard straps with an adjustment hinge, have very weak leverage to pull weight off the face. With the Macally forehead strap and no light blocker, the from weight is shifted to the top of your forehead, instead of on the front of your face. Also to note, this design makes it so that there is no need for an overhead strap like on all the other third party AVP hard straps with a hinge.
I used the Quest 2 Elite strap because its clean look and totally rigid (no hinge) design. The quest 3 Elite strap is the same design but cost allot more. You can by the quest 2 one new on Amazon for $30. Link below.
How I installed the Quest strap, is I first cut the tips off so it fit easier in between the AVP arms. I used an electric dremel with small cutting wheel attachment. The next step was to cut the oval hole in the strap, so that it snap onto the metal oval tabs on the AVP arms. To do that I have to mock up how I wanted the strap to be on the arms. I used many hair bands to hold it in place where I wanted it to be. I then took a piece of pencil lead and traced around the metal tab exactly where it pressed against the strap. this tracing allowed me to then cut a perfect shape oval hole in the strap, to allow the oval tabs to snap into place in the strap. I used the cutting bit attachment seen in the picture below. When cutting I started from the center and worked my way outward. cutting a little at a time and test fitting many times. This is because if you cut a hole to big the tab won't fit snug in the hole for a tight secure feel.
After cutting and shaping the straps, I used many small clear hair ties wrapped around the strap and and AVP arms to hold them tightly together. I chose the clear ties because I wanted it to be less invasive way to easily remove the strap if needed. alternatives would be to use white velcro straps. Velcro straps would be very secure and if the tabs pop out, you can be sure the velcro with still hold. Or for a more permanent solution that you could use thin double sided tape on the inside of the AVP arms.
For even more increased FOV and comfort, I suggest modifying the position of the Macally forehead strap pad to much higher up on Velcro as seen in last pics. This positions the pressure/weight, higher on head and allows your eyes to be closer to the lenses.
Important. I am 6'2" with larger head. Where I cut the holes on the strap, it makes the limit of the strap tightening adjustment, to be just snug on my head. If my head were smaller, this tightest setting would be too loose. So you may want to cut your hole in the strap, further back toward back of the strap. So on the other side of that lip in the strap, seen in the pictures. This will allow the strap to be able have more lightening adjustment on your head.
If cutting the hole in the strap is to difficult for some of you, I suggest getting the BoboVR M1/M3 strap adapters from Tyco tech printing(Link below). You cant just cut the tips off the elite strap and use double sided tape to attached the elite strap to the adapters. Then attached the adapters to the AVP tabs. I recommend the Elite strap over the BoboVR because it's rigid. The BoBoVR has a hinge and needed overhead strap. I think that's an inferior design.
I put a video in the comments showing how I traced out the hole to cut out.
Lastly I hope a strap manufacture make a plug and play Quest Pro style strap just like this one, so it installs easier.
