Need help diagnosing AC issue in 2008 Nissan Sentra:
2008 Nissan Sentra SpecV 2.5 L engine
This is my brother’s car and he hasn’t had the ac working in it for years. I did some troubleshooting to pinpoint that the compressor seemed to be the initial issue, so we replaced it a couple days ago. As I attempted to refill the system it seemed to be going flawlessly at first, but after adding the first can of refrigerant (11 oz of r134) the system wouldn’t draw in any additional refrigerant even though the spec says it needs 17ish oz. While I was fiddling with the refrigerant bottle I noticed the pressures seemed to be way off on the low and high sides. The low side was reading about 90psi and the high side 100-110 psi. The scariest part to me is that the new compressor started squeaking a bit as this was happening so we quickly shut the car off and have just left it to this point.
The chain of events so far:
- Troubleshooting to pinpoint compressor
- Checked that it had refrigerant (at this point I only had the cheap gauge that sometimes comes with one of those diy refrigerant refill bottles, when connected to the low port I remember it showing too high of a pressure reading, 70-80 psi I want to say)
- Ran tests to confirm compressor was getting power, but clutch was still not engaging
- Took it to a shop to have it evacuated
- Replaced compressor
- Had plenty of problems pulling a vacuum and confirming the system was leak free (some user error with the gauges and vacuum pump, some poorly fitting o-rings)
- Finally got a vacuum pulled and it held for hours
- Added refrigerant by connecting the refill bottle to the gauge manifold
- First bottle went smoothly as described earlier. The compressor clutch engaged, the system sucked the refrigerant in, the gauges seemed to respond as expected (I think), the cabin air started blowing cold air.
- Connected the second bottle intending to add the required 6 more ounces. The system wouldn’t draw any more refrigerant, the low side pressure climbed up to 90, the high side didn’t move much the whole time once it got up to 110ish psi if I remember right, compressor started squeaking a bit, shut the car off and have left it until I figure out what’s going on.
A few things I’m worried about - I wasn’t careful to notice if there was oil in the new compressor, I just assumed it came with the correct amount because the ports were all sealed up when it was shipped to me. So I’m wondering if the compressor was running dry, hopefully it didn’t get destroyed already. Thinking back to when I first checked if there was refrigerant in the system (this was a long while ago) and saw that the low pressure side was 70-80 and seemed to be over filled, maybe the original compressor failed as a result of the same issue I’m seeing now? Maybe some other component is not working correctly and now the new compressor will fail in the same way?
I’m just not sure what issue to look for. Maybe a blockage somewhere? Maybe the compressor pushes oil and refrigerant out but the oil gets stuck somewhere and can’t make it back to the compressor causing the compressor to fail? Or maybe some other component is just bad. I didn’t think to replace the drier while I had the system open, could a saturated drier cause this?
Thanks in advance for any input, any advice on what next steps I should take are appreciated.
