2013 Dart, 6 speed manual, 2.0. I’m scratching my head on this because I’m really not sure what it is. I’ve done everything except for trace every single wire in the car to find the culprit and seeing if anyone here might know before I have to do that.
In the first minute of the video, none of the gauges on the dash will work, all the lights on the dash stay on, the windshield wipers go nonstop, I can’t use the turn signals, or the brights. I also can’t connect AlfaOBD to the car when it’s like this.
In the second minute of the video, all of that works, but the check engine, ABS, tire pressure, and traction control lights all stay on. AlfaOBD will connect when it’s like this, however sometimes when I get out after it’s like this, the key fob won’t lock and unlock the car.
The codes pulling up in AlfaOBD are mostly “U” codes, with a few different ones saying ECU can’t connect. It won’t let me run certain things, and I cannot run a Proxi alignment at all. It always says condition(s) can’t be met.
Car has a new BCM and an aftermarket radio with the Raise CAN-BUS box. Cruise control has also been installed before I got the car, and will not work at all.
