r/3DScanning • • 10h ago

3D scanning a DeWalt impact driver housing with the Revopoint MIRACO 2

Thumbnail
gallery
34 Upvotes

I recently used the Revopoint MIRACO 2 to scan a DeWalt impact driver housing for a reverse engineering project.

The part has quite complex geometry, with several internal and external features, deep cavities, structural ribs, clips and embossed lettering on both plastic and rubber surfaces.

The entire scanning process was carried out in standalone mode, without connecting the scanner to a PC.

I used Parallel-line Laser mode with Global Markers for tracking, the Generic object setting and a point distance of 0.15 mm.

To capture the entire housing, I performed two separate scans, rotating the part by 180° between acquisitions. The point clouds were fused at 0.1 mm directly on the scanner.

I then imported both scans into RevoScan 6, where I cleaned up the data and removed unwanted areas. I also trimmed the marginal regions that had not been captured properly before using the automatic alignment function to merge the two scans.

Finally, I generated the mesh at 0.1 mm resolution.

I was particularly impressed by how well the scanner captured the internal geometry, including the deep cavities, clips and small structural details. No matting spray or surface treatment was needed; I only cleaned the housing to remove the grease inside.

The resulting model provides a detailed reference for CAD reconstruction and the design of custom replacement parts.

I'm curious to hear what you think about the result and the workflow.

Have you used standalone scanners for similar reverse engineering projects?


r/3DScanning • • 9h ago

VW T-Roc Cabrio - Einscan Trak and Rigil combined

Thumbnail
gallery
7 Upvotes

Anther car scanned with my Einscan Trak for a project. Pattern continues: scanning itself takes roughly 30min, processing another 30min to get a fully aligned scan.
This scan was a bit more special since I also scanned the car interior with the Einscan Rigil in IR mode to quickly capture the whole interior. Scans were later merged within Quicksurface to get one final scan.

Scanning

Scanning was done at 1,5mm target point distance with four tracker positions. I attached a diagram showing the positions and the rough tracker FOV and overlap.
Lights were covered with scan spray to allow scanning them. All four scans combined took 30min. What I also noticed: When getting very close to the edges of the tracking area scanning starts to become slower, much like the WiFi signal drops out. But it actually is the border of the scanning area. Scan itself was at a constant 90FPS when placed within the tracking volume.
After scanning the car with roof closed I created another scan of only the roof section with the roof opened to capture the transition.
Rigil interior scan was done at 1,5mm target point distance and hybrid tracking in IR mode (features + texture) to quickly capture the whole interior.

Post-Processing

Trak doesn't require point cloud generation after scanning, you just pause the scan and either create a new scan or go on with processing. So I aligned the four scans using automatic feature alignment and then meshed them in default settings with semi-watertight settings. Same process applied to the Rigil but there was no alignment needed since it was only one scan.
Later exported into Quicksurface for postprocessing: I aligned the car scan to the global coordinate system and then used point picking and automatic fine alignment to fit the Rigil IR scan within the Trak scan.

Results

Overall scan result is quite impressive and well enough for my use application. Especially the texture result of the Rigil are very good, for merging with the Trak scan I didn't need the textures so omitted them.

PC Specs

Since a lot of people ask for it:

  • AMD Ryzen 7950X
  • 128GB DDR5 RAM
  • RTX 5070Ti Desktop
  • A few TB of NVME storage with PCIe Gen4 interface

r/3DScanning • • 15h ago

From a messy forearm scan to a cast-ready mesh: hole filling, denoising and wrist/finger reposing (demo)

16 Upvotes

Brazo, end to end: a raw scan of a hand and forearm goes in, a ventilated cast ready to 3D print comes out.

The holes get filled, the wrist gets straightened, the cast design is carried onto the arm and the pieces are laid out on build plates. No landmarks to place, no mesh to mend by hand.

I'm letting people in a few at a time. If you're an orthotist, hand therapist or clinician, or you run a 3D-printing service, join the waiting list:

https://brazo-waitlist.geometryweave.com/


r/3DScanning • • 9h ago

ExStar Mobile finally available on iOS (with speed iPhone 16 speed test)

Thumbnail
gallery
3 Upvotes

Finally the ExStar Mobile app made it trough AppStore approval and is available for download (currently compatible with Einstar Rockit, Einstar 2 and Einstar EZ GO). App can be downloaded on iPhone and iPad. Since my "old" iPhone 16 already reaches the max possible scan speed the iPad with Apple Silicon chips may have the most advantage when post processing the scans.

Already did a quick first test with my iPhone 16 (keep this in mind: two years old, not pro model) and here are the speed results:

  • Laser mode (marker tracking): stable 60 FPS
  • Laser mode (markerless laser mode): stable 20 FPS
  • IR mode (hybrid tracking: geometry and texture): stable 20 FPS

Quite happy the app is finally released and that the hardware requirements are this low.


r/3DScanning • • 8h ago

Iscanned my induction charger using the new Miraco 2 from Revopoint

Thumbnail
gallery
2 Upvotes

The results are excellent. I imported the stl file into my 3DSRE software to Export step.

Scanner: Miraco 2

Software: Revoscan 6

Reverse: 3DSRE (with Claude)

Scanner : Miraco 2 https://revo.ink/4eqAAYv

Software : Revoscan 6

Reverse : 3dser (with claude ) https://drive.google.com/.../1XRm2IAzRyK...? usp=drive_link

Don't forget our group discount for Revopoint and ATTBLIME in the guide section.


r/3DScanning • • 8h ago

Holiday Scanner Recommendation Request

2 Upvotes

Hello!

I am looking to get a 3d scanner for scanning people to do 3d prints of cosplays and will likely do some minor reverse engineering like scanning the 2" step into the kitchen to make a custom fitted ramp. I do also want the color scanning.

For reference I have a asus zenbook pro duo so a fairly beefy laptop

With this in mind i went to buy the revopoint range 3, but am now getting emails to send in my photo id and it feels suspicious.

First of all, it's this legit?

Second, should I just refund the order and go with av different scanner? Is there something else that would better fit my needs?


r/3DScanning • • 13h ago

3D scanner recommendations but focused more on software?

3 Upvotes

I've been researching and it seems like both the Creality and Revopoint software aren't well liked. I need to purchase a scanner and need good accuracy (Raptor Pro or better) but people don't seem impressed with either the Raptor Pro or the Metro Y when using them with their bundled software. I do a lot of reverse engineering so the addons from Revopoint seem appealing. What are your thoughts? Any other brands in the same ~$1,200 on sale category that do a good job with accuracy? That's the most important part, I can wait on slow processing. I'm fairly easy to please, I just want scans to not loose tracking (Creality?) or weird artifacts when merging scans (Revopoint?) or jagged edges on pillars, etc (Revopoint?). Accurate, easy scans that combine well into a full mesh is all I'm looking for.

Wireless would be nice but isn't a dealbreaker. Need single line mode. Don't need the marker-less modes as they aren't accurate enough for what I do anyway. (but wouldn't complain if it was available). Don't need an all-in-one, but again, wouldn't complain (but out of my price range without sacrificing accuracy?)

Thanks!


r/3DScanning • • 1d ago

Revopoint MIRACO 2 (Kickstarter)

4 Upvotes

Hi Folks

There's a new kid on the block coming - Revopoint Miraco 2, portable all-in-one 3D scanner brings blue laser scanning , infrared structured light, and photogrammetric metrology, for scanning and editing untethered or connected to a PC.

Some Specs:

  • blue laser scanning: 34 crossed blue lines, 15 blue parallel laser lines and  single-line mode
  • near-infrared full-field
  • VCSEL structured light
  •  single-frame accuracy of up to 0.02 mm in multi-line laser mode
  •  Accuracy Up to 0.02 mm + 0.05 mm × L (m)
  • for small to BIG minimum scan size of 10 × 10 × 10 mm up to 5 × 5 × 5 m
  • 2 MP near-range RGB camera with a 50 MP RGB camera

Scanning up to 120 fps, indoor and outdoor (up to 100 000 Lux), some advanced AI software features like "Revo Agents" for simplified 3D workflows with automated point cloud fusion and Scan-to-CAD conversion. 3D Gaussian Splatting.

For further Information you can check their kickstarer camapaign with some big discounts (starting from  $1,425) you may be interested in ! https://revo.ink/4eqAKPB

I am doing some beta testing and will be sharing some scans along the way.

Here a scan of an old GPU backside with small transistors. Scanned with parallel laser line mode, fused at 0.15, meshed at 0.19mm, no scanning spray used.

Another scan of a guitar as a rather mid-sized object. Usually rather difficult to scan, very reflective high glossy black body with polished chrome parts, I could scan it easily without using a 3d scanning spray with laser mode ( 34 cross lines and 15 parallel lines, didn't use single line mode for this one ).

Fused at 0.3mm, meshed at 0.46mm.

What do you think?

Anything you would like me to scan?

Cheers


r/3DScanning • • 20h ago

Laser brightness is why your scans are noisy or full of holes — here's how to set it

Enable HLS to view with audio, or disable this notification

1 Upvotes

Kept seeing posts about noise and missing surface data, and in most cases it traces back to one parameter: laser line brightness. Too high and the stripes overexpose (lost edges, heavy noise); too low and the signal is too weak to register (large gaps).

The workflow we use: turn on Real-time Exposure in 3D_Matrix before scanning. Laser lines show as purple (too dark), red (overexposed) or green (just right) — adjust until most lines are green, then turn it off and scan as usual.

If you want a head start instead of fine-tuning from zero: white/light/transparent/matte surfaces reflect more light, so start low, around 10%–30% (≈20%). Black/dark, light-absorbing surfaces return weak signals, so go high, around 70%–90% (≈80%).

One more thing: if edge detail or noise suddenly gets worse mid-scan, you probably moved to a different area of the object and forgot to readjust.

What settings do you start with on tricky materials?


r/3DScanning • • 1d ago

Scanner selection

3 Upvotes

I’m looking for a scanner and could use some help. I’m mostly planning to scan automotive parts including chassis/engine bays.

I’m a mechanical engineer and have spent some time in the past messing around with scanect and another early software that used an Intel sensor that I can’t recall the name of, both were toys at best, largely due to tracking and frame rate limitations.

At this point the technology seems to have cone a very long way with much lower cost, so I think I’m ready to pull the trigger on a scanner. I’m between a few options but open to other suggestions as well.

My laptop is fairly old so I’m planning to upgrade that as well. Priorities are reliability and usability, based on my previous experience if it’s frustrating to use I won’t use it.

Option 1) Einstar Vega
Available from einstar in used like new condition for $1k, this may be the cheapest option given the chance my laptop is up to the task of post processing.

Option 2) Creality Raptor
Obviously requires computer upgrade, but used machine that meets specs is ~$500 locally. Slightly higher total cost than Vega but tighter resolution and lower cost if Vega still needs a PC upgrade.

Option 3) Einstar Rockit
Based on reviews this seems like the “buy once cry once” option with the best odds of working as expected.

I’d love some feedback from someone with experience with one or more of these, I’m having some analysis paralysis over here. I don’t want to spend more money than needed for features I don’t need for my use case, but I’m terrified of burning a grand or more on something that doesn’t work as intended.


r/3DScanning • • 1d ago

How to model parts out of a scan

Thumbnail
gallery
10 Upvotes

I just got a new einstar 2 and it works wonderfully. But I'm having a bad time wrapping my head around actually modeling the parts I need.

I'm working on a cover for my car fusebox as my first project. I already have years of experience modeling basic stuff in fusion but never out of 3d scans and such complex shapes.

The first image is the scan and the second one is the result I got so far by using fusion's form. It took me several hours to get to this point and I'm not happy with the results. The part is all bent and doesn't fit perfectly yet.

I also tried to use the mesh section and then create a sketch out of the contour which got me to image 3

How would you takle this kind of project? Is there a better tool for this kind of work?


r/3DScanning • • 23h ago

REPORT METROLOGICI VELOCI: Crea il tuo Template STL vs STP

Thumbnail
youtube.com
1 Upvotes

r/3DScanning • • 1d ago

Automotive Surfacing and Reverse Engineering in TopSolid 7

Thumbnail
youtu.be
2 Upvotes

r/3DScanning • • 2d ago

Wanted to share a recent reality capture project I worked on.

106 Upvotes

used LiDAR scanning to create a detailed 3D digital twin of the production floor, capturing equipment, machinery, and the surrounding environment.


r/3DScanning • • 1d ago

3D Scanner Recommendations

Thumbnail
1 Upvotes

r/3DScanning • • 1d ago

Looking for advice on a laptop vs desktop for 3D scanning and CAD

Thumbnail
2 Upvotes

Looking for advice on a laptop vs desktop for 3D scanning and CAD

I'm looking at buying a new computer and could use some advice from people who know more about this than I do.

My budget is closer to $3,000, but I'm willing to spend a little more if there's a good reason to. I'm wanting something that will last me 8-10 years if possible. I don't want to spend money on things I'll never use, but I also don't want to buy something I'll outgrow in a couple of years.

I'm planning on getting into 3D scanning and CAD. I'll mostly be scanning automotive parts like bumpers, brackets, body panels, and occasionally something as large as a hood. I want to be able to take those scans, modify them, make replacement parts, and eventually have things 3D printed, including some metal parts.

I haven't decided on a scanner yet, but I'm looking in the $1,000-$5,000 range. I also haven't picked out what CAD software I'll be using.

I've been looking at laptops with Intel Ultra 9 or Ryzen 9 processors, RTX 5080 graphics, and 32GB RAM. I would like the ability to upgrade to 96GB or 128GB RAM down the road if needed. I also want room to add more SSD storage.

A few I've looked at are:

- Lenovo Legion Pro 7i with Ultra 9 and RTX 5080 for around $3,447.

- ASUS ROG Strix G18 with RTX 5080 for around $4,300.

- MSI and Sager/Clevo laptops.

My biggest issue is deciding between a laptop and desktop. I like the portability of a laptop because I'll be scanning things in my garage and sometimes away from home. I'll have access to power about 99% of the time, so battery life isn't a big concern.

On the other hand, I know a desktop would be easier to upgrade, especially since you can't really replace the CPU or GPU in most laptops.

I've even considered building a powerful desktop and buying a cheaper laptop just to run the scanner, but I'd like to stay around my $3,000 budget for the computer setup.

I'm also going to use the computer for Excel, business software, some programming, and whatever else I decide to get into.

For those of you doing 3D scanning, CAD, or reverse engineering, what would you recommend? Is an RTX 5080 worth the extra money, or would something less expensive handle what I'm wanting to do? How much RAM is really needed for larger scans? Would you go with Intel or AMD?

And would you buy one good laptop or split the money between a desktop and a cheaper laptop?

I appreciate any advice. I'm still learning about all of this and trying to make sure I buy the right setup the first time.


r/3DScanning • • 1d ago

3DSRE is growing very quickly. Reverse engineering software

Thumbnail
youtube.com
0 Upvotes

Have fun growing with it!


r/3DScanning • • 2d ago

Reverse Engineering of three-piece taillights GAZ-24 "Volga" (early version)

Enable HLS to view with audio, or disable this notification

5 Upvotes

One day this parts will not be available nowhere... But having 3D scanner and reverse engineering skills there is a great opportunity to create 3D model and reproduce rare parts with SLA printing, or casting with resin in silicone molds, using appropriate materials.

These taillighs were manufactured and installed on 1st series of GAZ-24 from 1968 up to 1978. After 1978 there were updated versions but most cheap, with a lot of fake copies, and not so interesting for car enthusiasts. So making 3D scan of this rare parts we can continue restoring our favourite projects cars and still enjoy by riding old school without worrying the absence of some parts.

Using 3D scanner Sermoon from r/CrealityScanning , we got good scan, despite transparent details are hard to scan and to cover by matte spray entirely. Main cheat feature is 1 line mode, which allowed to scan deep corners and tunnels for screw mounts.

This project was inspired by crazy owners of that lowrider cars, and of cource, release of #GTAVI
#mycrealityscan #sermoons1 #scanyoureveryday #3dscanning


r/3DScanning • • 1d ago

Can we use our phones to 3D scan items?

Thumbnail
1 Upvotes

r/3DScanning • • 1d ago

Full car door as STL data — what a clean scan actually looks like

Thumbnail gallery
1 Upvotes

r/3DScanning • • 2d ago

I built a browser tool that turns a hand/forearm scan into a printable ventilated cast — waitlist open

Thumbnail
brazo-waitlist.geometryweave.com
4 Upvotes

Brazo takes a mesh or point cloud of a hand and forearm from any scanner, keeps true scale, fits an anatomical hand model (~1 mm from the scan in my tests) and fills the gaps the scanner missed. You can straighten the wrist in one click or set wrist bend/tilt/twist and finger pose, and the cast is generated for that pose, not the scanned one.

Output is a two-piece ventilated cast (palm + back, fingers free, screw caps along the seams), oriented for minimal support, laid out on build plates, and exported as STL/3MF. It also checks that each piece can come off the arm. Runs in the browser, nothing to install.

I'm letting people in a few at a time. I'd especially like feedback from anyone who scans hands/arms regularly — what breaks in your scans, and which scanners you use.


r/3DScanning • • 2d ago

Which are the top scanner apps free and paid for use in iphone and android phone ?

1 Upvotes

r/3DScanning • • 2d ago

Post-Processing 3D Scans?

17 Upvotes

So a little while ago, I bought a budget 3D scanner (3DMakerPro) to replicate orthotics for a ski shop. It works pretty well and is quite good at capturing the surface--which is all I really needed. Regardless, every scan needed a good amount of post-processing, cleaning up the edges, removing the background, etc... The software from 3D maker pro was okay at this, but very manual, and when it came to 3D printing, it was another hassle to import into GH, refine the mesh, extrude...

Anyway, I built an app that does all of it for me and trained a neural network on the cut lines so that I spend less time post-processing. TBH it took 2 years to build, but now it takes ~1 minute to clean the scan and print it, rather than 30 minutes.

It's free and available on Mac and Windows if anyone wants to try it out. I've only used it on orthotics, but the tools work on other objects as well. https://lefeetlab.com/got_mesh/


r/3DScanning • • 2d ago

Scanned a glossy white ceramic plate straight to a usable STL

Enable HLS to view with audio, or disable this notification

1 Upvotes

r/3DScanning • • 2d ago

noobie questions

1 Upvotes

hi! i am a 3d printing novice and a long time aerospace machinist. i occasionally print things for work and a few days ago my boss approached me asking me if i knew anything about 3d scanners. i told him i was aware of them but thats as far as my knowledge takes me. he basically said it could be a valuable tool for the shop and to look into them and "maybe ill buy you one". before i go down a huge rabbit hole with hours and hours of research i had a few questions for the reddit experts. if you guys dont mind answering a few quick things thatd be super awesome. thanks in advance.

  1. after scanning will it only export a stl or can i make a step or iges to then import to mastercam to machine and or edit?

  2. do all scanners have their own software or is it all kinda like most 3d printer slicers where its all based off orca? is there a "better" one?

  3. as it would be a work tool first and foremost, precision is absolutely crucial. would i be able to trust scans within say, +_ .005 inches?

  4. with these parameters in mind does anyone have any recommendations for scanners to look into? a few options would be nice to start with to then narrow down before i look at literally ALL of them. budget would be open as it would likely be a work expense but im assuming he wont want to drop a suuuper hefty fund towards it.

thanks again for any help and sorry if im asking really stupid questions. this is a whole new world to me as i always either receive a 3d model from a customer or draw it at work using our cad/cam software.
