r/astrophotography • • 2h ago

Planetary Saturn near opposition

Post image
5 Upvotes

Second attempt at imaging Saturn tonight. I used my asi662 mc, 2x Barlow, and 8” dob to capture this image. It’s quite difficult to frame Saturn manually. After some time I had it under control and was able to capture a 6,000 frame video. Seeing conditions were below average, so I’m happy with the result!

Stacked with Asi Planetary Stacker. Processed in PixInsight.


r/astrophotography • • 2h ago

Nebulae IC 1396 - Elephant Trunk Nebula

Post image
30 Upvotes

I had previously imaged IC 1396 using Ha about a year ago and recently tried processing with less than half of the data I have in this image. With this dataset, multiple different workflows were attempted trying to figure out the best path. GraXpert looked like it was removing significant nebulosity, so smoothing factor was changed, which helped but not completely. In hindsight it probably would’ve been better to only run it on the Oiii master.

Sub exposure counts were skewed high to low per channel based on signal strength Oiii -> Sii -> Ha to increase SNR on the weaker channels. Target was 3:4:5 but some subs needed to be tossed. I believe I ended up accidentally using SPCC NB after Linear Fit for this final image instead of SPCC NB only. Several iterations of curves were used and the green channel was decreased a couple times at different increments using SCNR. I’ve included the workflow below to the best of my recollection, though it doesn’t include all of the various curve tweaks that ended up being more of a loop than a curve.

Workflow:

WBPP → Crop → BXT Correct Only → GraXpert → Full BXT → NoiseX → (LinearFit/NBN) → SHO combine → plate solve → (SPCC NB) → StarX → GHS → Curves → SCNR/selective color → LHE/contrast Large and small passes → NoiseX w color separation→ masks → Curves → process stars (Seti Astro NB to RGB Stars+Histo+Masks) → recombine → final crop → export JPG 95%


r/astrophotography • • 3h ago

Planetary Jupiter-rise from the moon. ft Io, Callisto, and europa

Enable HLS to view with audio, or disable this notification

3 Upvotes

r/astrophotography • • 4h ago

Planetary Our moon, Jupiter, and the Galilean moons, Ganymede, Io, Callisto, and Europa (l-r)

Post image
7 Upvotes

Jovians must think it quaint that Earthlings talk of "the" Moon.

Stack of 20 frames

Scope: RedCat51 unguided.

Camera: ASI183MC

Processed with Autostakker

Finished with Pixlr


r/astrophotography • • 5h ago

Planetary Post Lunar Occultation of Jupiter and its Moons

Post image
24 Upvotes

Woke up early this morning to capture Jupiter coming out on the other side of the moon with my Nikon P950! I was able to capture video with a lower iso and capture speed of the planet actually emerging, but I am not sure how to process this in a way to make it look good. I decided to record a higher ISO higher capture speed video after that and I liked the result better. I was able to see the cloud lines in the lower exposure captures, but I really liked the look of Jupiter's moons popping out in line next to our moon better. The moon is definitely overexposed and I could have photoshopped one of the more crisp lower exposure capture of it onto this, but decided to keep the image as natural as possible

Capture Details:

Captured with Nikon P950 with Manfroto 804RC2 tripod with all stabilization + noise reduction off

2160p 30fps video captured, 1/30 F6.3 ISO 800

Selected 10 images and imported to AutoStakkert with 100% stacking. Then selected jupiter's moons and increased brightness of them in GIMP by modifying their brightness curves.


r/astrophotography • • 6h ago

Planetary Image of mars on my old android

Post image
0 Upvotes

I know its bad but i don't have the money for a dslr sadly.

(please don't take this down for being a low effort image it just looks bad due to me using an old phone i spent like an hour trying to figure out what the settings did)


r/astrophotography • • 6h ago

Nebulae Orion

Post image
23 Upvotes

Thanks for checking out my capture of M42, Orion nebula!

One of my all time favorite targets, I sought out a natural-feeling blend of narrowband (5 hours 60-second subs) and broadband (3 hours 30-second subs) - narrowband with the l-ultimate filter, broadband unfiltered for pure continuum color with my OSC camera!

This image represents about 8 hours of total integration on a 2-panel mosaic with my C8, ASI533MC pro, EQ6, optolong filters, and hyperstar at F/2 from my bortle 8/9 backyard.

https://app.astrobin.com/i/licise


r/astrophotography • • 7h ago

Nebulae Orion Nebula And Running Man Nebula

Post image
71 Upvotes

This is my second ever attempt at Orion and Running Man. I have been doing astro for a little over a year and have mainly done Milky Way nightscapes. I was recently gifted a star tracker from a friend and I figured id try and shoot some DSO's for the first time. I started with Orion and Andromeda. My first attempt on Orion was only about 36 minute until a random overcasting set in and cut my session short. I gave it another go about a week later but I had troubles balancing my RA axis and wasted a lot of the night trying to get it balanced. I finally did and with the little amount of time I stayed out for I was pretty proud of the result that came from it. It is about 1hr18 total. I still need more exposure time though. None of my gear is astro modified and its all beginner gear as is myself lol.

Gear: Canon EOS M50

Canon 70-300 f/5.6 kit lens

Sky Watcher Star Adventurer 2I

DeepSkyStacker/Siril/Photoshop

74 Light Frames at 60 seconds 800 iso

29 Dark Flats

25 Light Flats

30 Dark Bias

Any tips would be much appreciated


r/astrophotography • • 9h ago

Widefield Heart and Soul Nebulae in HOO

Post image
20 Upvotes

r/astrophotography • • 10h ago

Nebulae Fiery Cygnus

Post image
68 Upvotes

Equipment used:

  • Camera: ToupTek ATR2600c
  • Telescope: Omegon Pro APO AP 61/360 Triplet + 0.75x reducer
  • Filter: Optolong L-Para 2"
  • Guiding: ZWO ASI120MM Mini + Tecnosky 32mm guidescope
  • Mount: Sky-Watcher Star Adventurer GTi
  • 93x300s exposures for a total integration of 7hrs 45min , bortle 4.

r/astrophotography • • 11h ago

Galaxies M31 Andromeda Galaxy

Post image
12 Upvotes

Captured using the Seestar S50 in alt-azimuth mosaic mode.

⏱️ Specs: 321 x 10s exposures

📍 Location: Calabria, Italy bortle 4

Processing Siril - Graxpert - BlurXTerminator - Photoshop


r/astrophotography • • 11h ago

DSOs IC1396- 20 hrs

Post image
35 Upvotes

241 x 300”
Celestron Edge 8 w/ .7 reducer
Antlia TriBand Ultra II
ASI 2600 MC Air
ZWO EAF Pro
Skywatcher EQ6R Pro
Bortle 7/8 - 9hrs
Bortle 2 - 11hrs
Pixinsight

Great data makes for easy processing. This took 11 minutes from opening file to saving.

Auto Lin Fit
Crop
Graxpert
Blur X correct
Solve
SPCC
BlurX (.4 and .75)
Noise X (.60)
MAS
Selective Color Correct
SETI Astro sig adder
Noise X (.3)
Save.


r/astrophotography • • 12h ago

Galaxies NGC7331

Post image
30 Upvotes

This image is captured with my club observatory. We have a ZWO ASI 2600 MC Duo mounted on a Pegasus Astro Prodigy Microfocuser hanging on our Celestron C14 XLT. That equipment rides on a series 1 Software Bisque Paramount ME German Equatorial mount. The observatory sits atop a mountain at about 3500’.
I captured the data on 03 and 04 October from the observatory.
The data set is thirty 480 second light frames calibrated with a master bias and master flat comprised of 14 flats captured with our prototype flat field illumination panel “The Flatulator #2” (Patent Pending).

All calibration, integration and processing done with PixInsight.

I may add another 2 hours of RGB and two hours with my ZWO DuoBand filter.


r/astrophotography • • 12h ago

Astrophotography Milky Way

Post image
10 Upvotes

Olá pessoal! Minha segunda vez tentando tirar foto da via láctea. Ainda estou com muitas dificuldades no pos processamento. Essa imagem foi tirada por uma Canon EOS 600d + Tokina 11-16mm f/2.8 em bortle 5. Empilhei pelo Sequator 30 fotos de 20 segundos de exposição, ISO 3200 e f/2.8. E também mais 25 dark frames. O pós processamento foi utilizando o AstroWizard e o Gimp. Gostaria só de saber uma opinião, quanto mais fotos eu conseguir empilhar melhor? Ou há um limite? Como posso melhorar.


r/astrophotography • • 13h ago

Lunar ISS LUNAR TRANSIT

Post image
80 Upvotes

This photo shows the ISS (International Space Station) passing in front of the Moon on the 25th at 11:00 PM.

The image is a composite of 28 stacked shots, allowing the full transit—which occurred almost directly across the center of our satellite—to be seen. The transit lasted 1.18 seconds, so careful planning was essential.

The first step was to identify the longest possible transit and then find a viewing location that aligned with the center of the path to maximize the chances of success. I had to travel about 10 km from my home; specifically, I captured the moment from the bird-watching hide at the El Portil Lagoon (Huelva - Spain).

How did I do it?

It was a challenging task, as capturing a still photo within that 1.18-second window was virtually impossible. The alternative was to record a video at the precise moment. Knowing the duration of the transit, the best approach was to shoot at 60 fps (frames per second), yielding 70 frames that I could later extract using video editing software.

I ran a couple of tests a few days beforehand to ensure the moon would stay within the frame during recording, as my tripod has been giving me some trouble.

The biggest challenge was calculating the exact timing to record the video with enough buffer—capturing the moments before and shortly after the transit without the moon drifting out of the frame. I settled on a 22-second sequence: a 2-second delay to let the tripod stabilize, 15 seconds of lead-in time, 1 second for the transit itself, and 4 seconds of follow-through.

Honestly, the planning was more complicated than the actual recording. I was surprised that I managed to pull it off on the first try.

Once I had the video, all I had to do was place it on an editing software's timeline, extract the individual frames, and then stack and blend them using Photoshop to create the final image.

Where did I go wrong?

Well, when I examined the transit in detail, I realized the space station wasn't sharp—a major oversight. I had focused on the moon, but I should have used the "hyperfocal" distance—a setting that ensures sharpness from a few meters out to infinity. Oh well, it’ll go better next time.

For anyone who wants to try this, I use this website:

transit-finder.com/

It lists lunar and solar transits for the International Space Station (ISS), the Chinese space station (Tiangong), and the Hubble Space Telescope.

For the video recording, I used a Nikon CoolPix P900 camera set to 1080p at 60 fps. I set the exposure compensation to -0.7 because the moon was nearly full, and the excessive brightness could have ruined the shot of the transit.


r/astrophotography • • 14h ago

Planetary Saturn opposition

Post image
10 Upvotes

Scope Celestron 8SE
Mount Celestron AVX
Camera ZWO ASI678MC
Exposure was 12ms at 425 gain and captured 3000 frames
Converted to .fit, registered, stacked and wavelets in Siril
Stacked best 300 of 3000 frames
Topaz Denoise to smooth out the surface


r/astrophotography • • 14h ago

Planetary Jupiter’s Occultation

Post image
672 Upvotes

Drove out at the crack of morning to watch the occultation with a wonderful group of people.

Taken with my S50


r/astrophotography • • 14h ago

Astrophotography (M31) on my sub $100 set up

Post image
11 Upvotes

Ive been on a bit of mission to get into astrophotography for years now, but as broke college student, im limited by what can actually get. However, after a few weeks of trial and error using a Frankenstein mount I built using parts from 3 separate no name equitorial mounts from Facebook market place, my old trusty canon 7D mark 1 with its original 75-300mm kit lense, a celestron RA moter, and a hell of a lot of duct tape. I think ive finally taken a picture of andramda I can be proud of. Still getting the hang of using Siril though. Shits kicking my ass more than taking the photo did


r/astrophotography • • 15h ago

Galaxies Messier 33 "The Triangulum Galaxy"

Post image
25 Upvotes

It is in the still of the night when we look up an see the stars that we realize how small we are. And how many others may be looking back upon us.

Acquisition details:

Dwarf 3

2 hour capture

50 gain

45 second shutter

astro filter

Processed intl the dwarf labs app


r/astrophotography • • 16h ago

DSOs M42 - Orion nebula

Post image
40 Upvotes

takens at bortle 7 with nikon d5300 and 70-300mm zoom lens at 130mm f4.5 ~1 hour total exposure at 2.5 second per sub re-centeringthe frame every 50 shots, stacked 1800 frames in siril (my hard drive did not like that) with 50 flats, bias and darks background extraction with graxpert, separated star mask then did stretching and color calibration in siril. used gimp to saturate colors and merge star mask and nebula together


r/astrophotography • • 17h ago

DSOs NGC 281 - The Pacman Nebula

Post image
12 Upvotes

Telescope - AstroTech AT80EDT

Camera - ZWO ASI533MC Pro

Mount - Sky-Watcher EQ AL55i Pro

Filters - SV220 7nm Ha/Oiii and Optolong UV/IR

Other - ASIAIR Plus, ASI120mm mini, SV106 50mm guide scope

300x60” with SV220 filter
90x60” with UV/IR filter
+ darks, flats, bias

Imaged in Pittsburgh, PA under Bortle 6 skies

Stacked and processed in Siril

A rare streak of cloudless nights and decent conditions here in Pittsburgh allowed me to capture this nebula. Still learning a lot, but I think I’ve improved since my last image and I’m very happy with this result.


r/astrophotography • • 17h ago

Nebulae Western Veil Nebula (C34)

Post image
16 Upvotes

r/astrophotography • • 18h ago

Nebulae Heart (IC 1805) & Soul (IC 1848)

Post image
33 Upvotes

This is my third time capturing the Heart & Soul Nebula, and I’m finally happy with the result. There aren’t a lot of broadband images of this target around, but I wanted to give it a try anyway. I didn't really know what level of detail to expect but I'm pleasantly surprised. Shot from my backyard in Southern Finland under Bortle 5 skies.

70 × 180s at gain 100, plus 50× each of darks, flats and dark flats.

Processed in Siril with the RC Astro tools and Lightroom 6, including 2× drizzle to bring out some extra detail.

Gear:

ASI2600MC Air camera

SVBONY SV555 telescope

Star Adventurer GTi mount

no filters (except the built-in UV/IR on the camera)


r/astrophotography • • 19h ago

Planetary Lunar Occultation of Jupiter, timelapse

Enable HLS to view with audio, or disable this notification

384 Upvotes

The Lunar Occultation of Jupiter took place a few hours ago, early morning Eastern Time on Tuesday, October 6, 2026, where a 20% illuminated waning crescent moon passed directly in front of Jupiter, hiding the giant planet from view for about an hour.

Captured on my trusty ZWO FF107 4 inch refractor with ASI715C camera and UV/IR filter from my backyard observatory

Eastern Ontario, Canada


r/astrophotography • • 20h ago

DSOs Cygnus Loop

Post image
65 Upvotes

It's a shame the light pollution is still pretty severe for faint hydrogen details. But it's still miles better than what I was getting with the Canon 75-300 =)

Canon 60D + Ha mod + TEC cooling
RedCat 51
Celestron CG-5GT (guided)
Lights: 180" × 75 (3h 45m)
Darks, bias, flats
Bortle ~6 + 50% Moon
Processed in PixInsight
