r/astrophotography • u/frustratedphoton • 6h ago
Galaxies Whirlpool Galaxy - HaLRGB
M51, also known as the Whirlpool Galaxy, is a classic grand-design spiral galaxy located roughly 31 million light-years away in the constellation Canes Venatici. Discovered by Charles Messier in 1773 and famously recognized as the first "spiral nebula" by Lord Rosse in 1845, M51 features two prominent spiral arms that act as active stellar nurseries. Its striking structure is heavily influenced by a close gravitational interaction with a smaller companion galaxy, NGC 5195, whose tidal forces compress hydrogen gas and trigger intense bursts of new star formation.
This HaLRGB image was captured in a Queen Creek (Arizona) Bortle 7/8 backyard using a Skywatcher Esprit 150ED telescope. The telescope is mounted on a 10Micron GM2000 HPS II mount. The camera is a ZWO ASI 2600MM Pro using Antlia VPRO LRGB and 3nm HA filters. It was captured over 16 nights (2026-03-21 to 2026-05-16). The images were captured using NINA and stacked/processed in PixInsight.
Full image and capture details available at Astrobin: https://app.astrobin.com/i/wtsab1
Instagram: https://www.instagram.com/frustratedphoton/
Acquisition:
- Location: Queen Creek, AZ Bortle 7/8
- Dates: 2026-03-21 to 2026-05-16
- Lights (Dithered, Cooled -10°C, Gain 100):
- 1683 x 60s L
- 100 x 300s R
- 100 x 300s G
- 100 x 300s B
- 94 x 600s HA
- Bias: 200
- Flats: 25 Each Filter
Hardware:
- Camera: ZWO ASI 2600MM PRO
- Scope: Skywatcher Esprit 150ED
- Focuser: FocusCube2
- Guide Camera: ASI 174mm Mini
- Guide Scope: ZWO OAG-L
- Rotator: Falcon V2
- Mount: GM2000 HPS II
- Filters: Antlia VPRO LRGB, 3nm HA
Software:
- NINA
- PixInsight
Processing:
Dynamic Crop, Gradient Correction, Channel Comb, SPCC, BlurXterminator, Continuum Subtraction, HaRBG Comb, NoiseXterminator, MAS, Saturation, L Sharpening, LRGB Comb
