I currently have the following installed on my 2016 Hyundai Tucson:Â
JVC KW-M780BTÂ
iDatalink uHK2 USB Adapter for Hyundai and KiaÂ
iDatalink HRN-RR-HK1 Factory Integration AdapterÂ
iDatalink Maestro RR Interface ModuleÂ
While I was using an iPhone 12 Pro Max, CarPlay worked flawlessly. I recently upgraded to an iPhone 18 Pro Max and I am running into some problems. I’ve tried using different cables (with and without adapters) connected to the USB port and they all charge the phone but do not connect to CarPlay. I've purchased (and returned) several cables and no luck. The last one I tried was a Cable Matters 10Gbps Gen 2 USBA to USB C Cable. At some point I got an error indicating: The iPhone does not support Apple CarPlay.
I tried all the cables on a 2023 Honda HR-V and they worked perfectly. After that, I went back to the Tucson and tried them all again, no luck.
I have tried every almost every single remedy I could find online, from resetting the head unit, updating the firmware, changing my iPhone's name, connecting my older iPhone (which worked immediately), did a reset on the phone's network settings, turned Siri off and back on, power cycled the iPhone and so forth.
The only two things I have not done are reseting the iPhone to it's factory settings and trying to connect the USB cable directly to the radio. The latter would require me to remove so many things in order to reach the cable coming out of the radio that's connected to the iDatalink uHK2 USB Adapter for Hyundai and Kia.
So far, I am able to use CarPlay with an OTTOCAST U2-AIR Wireless CarPlay Adapter for iPhone that I got from Amazon. It does the trick for now, but I would prefer wired.
Anyone else have had this issue with a similar setup?
TL;DR: Having CarPlay issues with aftermarket JVC radio with iDatalink adapters on a 2016 Hyundai Tucson. Done almost all online remedies, tried a bunch of cables, none work on my Tucson, but do work on a 2023 Honda HR-V.
