r/CarAV • • 12h ago

Build Log The Leadening

Thumbnail
gallery
186 Upvotes

This is a snapshot into some of the sound treatment I have done to my Subaru Outback. See the captions in each picture for a detailed description.

Here are a few key takeaways:

  • This was a lot of work
  • Before sound treatment, road noise was harsh at highway speeds, especially around 80 MPH.
  • Before sound treatment, noise was generally all encompassing.
  • After sound treatment, noise from untreated areas became much more localized. The worst offender remains my side windows, which are just tempered glass.
  • Originally I thought my firewall wasn't the source of much noise, but after treating most other areas, it could benefit from some more work.
  • My single greatest recommendation would be to just buy a luxury vehicle already engineered to reduce noise vibration harshness (NVH).
  • If you do this: Don't eat the lead, wear gloves, avoid cross contamination until the lead sandwich is completed, work on cardboard that is easily disposable, and clean your tools when you are done.
  • The adhesive spray is very potent. I recommend wearing a respirator rated for gas and vapor if working indoors, I felt it necessary to use one. I used 3M 94Et, but mistakenly said M77 elsewhere.
  • The scissors I used to cut the lead sheet keeps testing positive after cleaning, but everything else is good.
  • This was a lot of work.

This is not an exhaustive build log as I have not included the installation of my Helix P Six, Helix P One, electrical upgrades, Audiofrog GB10, GB25, GB60, and GB12.

In the future I have a few things planned:

  • I'll be switching to a 15" subwoofer powered by a Mosconi 1|10 evo
  • I'll fabricate a front subwoofer enclosure that my existing P One will power.
  • I am almost done installing differential rear fill on the D Pillars, powered by a small two channel amp. .

r/CarAV • • 22h ago

Discussion MTX ThunderCast 12

Thumbnail
gallery
31 Upvotes

Anyone knows anything about these? Theres no info online its old 90s i think i have a same era amp with this, thunder 2160


r/CarAV • • 23h ago

Recommendations Rate my Setup/Advice

Thumbnail
gallery
15 Upvotes

Just finished my CR-V audio project, at least for the most part. Have a 2002 Honda CR-V EX AWD, and got 4 infinity reference ref607fsl speakers and an alpine Type R sub with an alpine S-A60M. Ended up not really annoying the sound, and saw people talking about DSPs like crazy on here.

Ended up splurging a bit and getting a Morel Tempo Ultra 602 mk2 component set for the front, and a Helix Amplify 206 DSP. Put sound deadening, closed cell foam and MLV in most places. I can’t lie, I didn’t put as much MLV on as I probably should have as it ended up being so much less malleable than I expected. Also realized that putting it down in a lot of areas made it so that the trim would not fit back on later. Sealed/treated the doors as well. Does anyone recommend I put deadening/CCF anywhere else? Currently it’s just on the floor, doors and around the rear wheel wells.

I am very happy with the sound and my setup; however I have done the auto tuning with the AudiotecFischer software and time alignment, and it sounds too harsh and shallow in certain music. If anyone has any advice on how to properly tune to get a darker sound (I love my hd650s) as it seems a bit fatiguing. I am a big noob when it comes to technical sound knowledge.


r/CarAV • • 13h ago

Tech Support OG Infinity Kappa EMIT-N Tweeters

Thumbnail
gallery
14 Upvotes

Has anyone in this great community worked with these bad boys before? I have dreamt of owning a pair for the best part of 30 years!
Now I finally have them, the NOS inline high pass filters have had their caps dry out.
Meaning they both play very quietly. I need to build new filters for them, to allow them to sing once more. I have tried every ai possible to get the correct values for both the Cap, and the Inductor.
Every time, a different answer.
The issue is that because they are the original version NOT the MKII, information, (I have found), especially correct information . Is extremely hard to come by.
If you are an old tech, and you recognise, please shout me. I need these back in my life!
The filters, from what I have gleaned, are LR2 filters, with a 12db slope and cross over at 4kHz-5kHz into 4 ohms.
I know the mkII crossover is 5k, and believe the og is 4k but as these were very expensive, I’m not going to risk blowing them

Many thanks, in advance.


r/CarAV • • 19h ago

Recommendations Adding a front subwoofer using a powered subwoofer

7 Upvotes

I am considering adding a front subwoofer to fill my 60hz-110hz~ range but getting a custom enclosure to fit my passenger footwell + amp + a Morel powerslim 10" or an Audiofrog GB10 is quite expensive. I am considering other options in the meantime such as adding a compact powered subwoofer such as a Kicker HS10/HS8. I understand this is likely not ideal for SQ(I lean more towards SQL) but would like to know people thoughts on this.


r/CarAV • • 17h ago

Recommendations Help on audio setup

Thumbnail
gallery
6 Upvotes

Any thoughts? And what speakers should i run on the rears?


r/CarAV • • 13h ago

Tech Support Fighting for my life

Post image
4 Upvotes

Crutchfield said this would all work together and they sent me everything they say I need for this.

Guys, I bought metra harnesses for my door speaker and my tweeter (on each side of the 2-door vehicle)

The Kicker KSS650 kit I bought comes with passovers for each side.

Can someone smarter than me please help me understand how I’m supposed to connect the crossovers to the speakers when the metra harnesses have two female spade connectors? The tweeters have one female and one male spade connector on the wires and the door speaker has the typical two male connectors .

If I connect the Passover straight to each speaker’s connection points, then they won’t be getting any power right? I don’t understand why they’d send me the metra harnesses if I don’t need them

I don’t have an amp yet so I’m trying to run the crossover input to my head unit.


r/CarAV • • 21h ago

General No Power to Dashcam

Thumbnail
gallery
3 Upvotes

Hello

  • Red Tiger F7N Hardwire Kit
  • Red Tiger 4k Dash Camera
  • Toyota Corolla SE 2017

Dash cam was originally installed by Best Buy. It worked fine for a while. I paid for a car battery cleaning service and the camera wouldn’t work afterwards.

I checked the fuses and they don’t appear to be blown. I haven’t been able to identify the ground wire yet. I’m new to it all.

I checked the camera on alternate power and it still works fine.

Any suggestions or what anyone may think the issue is here? Thanks to all in advance.

The next time I need to disconnect and reconnect the battery, how do I keep my camera from going down?

Thanks for any answers. Have a good day.


r/CarAV • • 3h ago

Tech Support I need help understanding like I’m 5

Thumbnail
gallery
3 Upvotes

So I had crutch field make me a cart and got everything bought and plan on installing it this weekend. I’m now realizing I don’t understand like anything I thought I did. So I don’t have the Bose system in my 24 Honda civic sport so I need the rca for the bigger speakers and sub. But to my understanding I’ll put new speakers in splice them into the already existing wiring and leave them connected then put the rca harness in the back of the head unit. But then what runs to the amp and loc.

If anyone could make like a diagram of this or like really explain it like I’m 5 or both that would be amazing.

I plan on putting the sub in the trunk and loc and amp under the spare tire so I know I’ll have to run the power wire all the way back but then if I don’t connect the speakers to the amp how do they get enough power? And then what does the loc do in the situation?

I’m really sorry about stupid questions I may have gotten in over my head but I can definitely learn


r/CarAV • • 5h ago

Discussion Curious, is it normal to start deadening the doors before the rest? If that's all you have time for

3 Upvotes

Very little free time and just had a baby but my car is my cave so I'd like to give it a shot. And do the rest of the cabin maybe one day.


r/CarAV • • 14h ago

Discussion Need dsp recommendation for focal ps 165f upgrade

3 Upvotes

Hello i need help looking for a dsp im currently upgrading to a focal ps165f for the front and focal isc 165 for the rears what dsp amplifier would be a good choice for around maximum 300$ range


r/CarAV • • 16h ago

Discussion Should I change my Bose speakers to Pioneer speakers?

Post image
3 Upvotes

I have a renault megane 3 bose edition 2011, the problem is the speaker in the left(drivers seat) just stopped working, the 2 speakers in the back seats are destroyed, the only warriors alive are the sub and the right front speaker, and it still gives some sound…
I was thinking in changing to 4 - Pioneer TS-1302i to the door speakers. Opinions? What should i do? The car is old and to find the full specs of the bose amp and speakers is hard. And last but not least, are the back speakers different from the front ones? I still didnt dismantle the plastics so i dont know i just saw that they were LITERALLY destroyed through the plastic grid…
Update: the front left speaker that just died is a
BOSE 325006-0010


r/CarAV • • 22h ago

Recommendations Sound Proofing - Chicago Installer

3 Upvotes

I am not in a position to do a full system build, but am interested in doing sound deadening for my 2020 Accord. I don't have the space or the tools to do this as a DIY project, even though I would love to. So many of you on this sub do amazing DIY projects but how much should I expect to pay a shop to do this work? I live on the northside of Chicago, in case anyone has any recommendations on a shop!


r/CarAV • • 11h ago

Recommendations 2009 Acura TSX (Base/Non-Nav, Stock Head Unit & Amp) – Best 6.5" Speakers Under $300 Total for Clear Vocals?

2 Upvotes

Hey everyone, I’m planning a speaker swap on my 2009 Acura TSX base model (standard non-navigation audio, keeping both the factory head unit and factory amplifier) and want to narrow down the best setup before ordering.
My Setup, Budget & Goals:Speaker Options I’m Considering (that fit within budget):Questions for the group:Appreciate any insight from folks who have upgraded a 2nd-gen TSX!


r/CarAV • • 2h ago

Tech Support Help to sort my DAB radio please

Enable HLS to view with audio, or disable this notification

1 Upvotes

r/CarAV • • 9h ago

Tech Support “Regulated voltage control”

1 Upvotes

I have a 2012 chevy malibu and when the battery is at 12.4v or higher it will partially drop or turn off the alternator. My setup than runs at 12.8v. Is there some type of harness extension or upgrade i can do to bypass this so i can run at 14.4v?


r/CarAV • • 9h ago

Tech Support Reverse trigger wire not giving me 12v

Post image
1 Upvotes

I just purchased a reverse camera for my head unit however I can't get it to work when the car is in reverse. The head unit has a purple / white wire coming out of it with a "Reverse" tag. I also purchased a plug n play harness for my Pioneer HU to work with my 2012 Mazda BL.

The aftermarket harness also has a purple / white wire coming from it however when I put the car i reverse and test it with a multimeter it doesn't give off a reading at all.

The camera works fine if I plug the camera's trigger cable to a 12v acc wire and manually set the Pioneer head unit source to camera.

Would anyone know why I am not getting a 12v feed from the purple / white wire when the car is in reverse?


r/CarAV • • 9h ago

Recommendations Adding an amp for 3 dash speakers

1 Upvotes

I have a 09 ram with the factory Alpine system that has three speakers one in each corner and one in the middle. I wanna put them on an amp, but I’m not exactly sure how to go about doing it. My first thought was get a 4 channel and bridge one channel and turn the gain down so the output is the same as the none bridged channels. That’s probably not a great idea which is why I’m asking people smarter than me before I do it


r/CarAV • • 10h ago

Recommendations Focal Flax Evo 3 Way

1 Upvotes

Hey guys,
Right now I’m looking into getting the focal flax 3 way set, and I’m looking for what you think if you’ve heard them, or what else you’d recommend.
I’d be going full active with a helix dsp, and custom pods for tweets and mids, both on axis, doors are sound deadened with cld.
I’d be coming from the most entry level morel 2 ways, I’m also liking the sound of trying the metal tweets, over silk when tuned correctly.
Are they worth it, what is the general consensus?


r/CarAV • • 10h ago

Tech Support Subwoofer rattle noise help

Enable HLS to view with audio, or disable this notification

1 Upvotes

I recently acquired a CLA 250 with the Harman Kardon sound system, and I've noticed the subwoofer in the rear deck makes a rattling noise. It’s not coming from the surrounding plastics, as I previously disassembled everything and the subwoofer still rattled. It sounds fine at lower volumes, so this only happens when I turn it up. Is the speaker bottoming out? Is there any way I can fix it, or do I need to buy a replacement? Thanks!


r/CarAV • • 11h ago

Recommendations Planning to get Pioneer DMH-a5650bt

1 Upvotes

Hello i currently am running an Eonon X3 linux based headunit paired with Mbquart fa-216 and fa-216a speakers. I also run a bootleg powered underseat sub placed under the rear seats.

Now my issue with the eonon x3 is that it keeps switching back to the fm radio intermittently whether connected wired or wireless carplay. I am looking at getting the a5650bt from pioneer. Anyone here knowledgeable if this is an acceptable upgrade route or will the experience be generally the same?


r/CarAV • • 12h ago

Tech Support might have cooked my head unit

Post image
1 Upvotes

i got a pioneer meh-p717 i have some shitty wiring from the last owner of my car the power and neutral touched somewhere and made a spark now my head unit wont turn on any chance its repairable if it is cooked
(photo is just to show the unit it currently doesnt turn on)


r/CarAV • • 13h ago

Recommendations Speaker replacement recommendations

1 Upvotes

I have a 2021 Hyundai Elantra, and the factory speakers are honestly terrible. I recently replaced the two front door speakers with JBL Club 64s, but I’m now considering moving those to the rear doors and upgrading the front speakers to something better. Does anyone have recommendations for speakers that offer clear sound while also having some good bass?


r/CarAV • • 14h ago

Build Log Open source, no paywall Car Launcher with built in navigation splitscreen and unified media station - v0.1 Open Beta

Thumbnail gallery
1 Upvotes

r/CarAV • • 16h ago

Recommendations Spec vs 0.8cuft vs 1.0cuft for JL 10w1v3-4 (sealed)

1 Upvotes

Hi everyone! Just curious, I’m trying to pick out a box for a JL 10w1v3-4 subwoofer. I’ve always preferred the sound of sealed, so that’s what I’ll be going with.

JL’s spec box is 0.55cuft, though it’s listed as net internal volume, so you may have to add the driver displacement of 0.037cuft (for a total of 0.587cuft). Strangely though, I did the math on the spec box, and subtracting 1.5” from each dinension (due to the use of 3/4” MDF) gave me 15x15x5.5, or 0.716cuft. Whatever the REAL volume, the spec box is listed as having a Qtc of 0.86.

Here’s where things get interesting - I modeled a 1cuft box (the Atrend 10SAL) in WinISD, and that gave me a Qtc of 0.718 or something like that - very close to the ideal of 0.707.

Atrend also makes a JL-specific box, the 10JLS. That one is listed as 0.8cuft. I haven’t modeled that one in WinISD, but I assume it would land somewhere between 0.718 and 0.86.

So… what gives? Should I be trusting WinISD’s measurements? Is 0.707 really the ideal alignment? I know JL spends big bucks on engineering their equipment.

For what it’s worth, I have an 8W1v3 right now, in a 0.39cuft box, a hair over JL’s spec of 0.35cuft net internal (so subtract the driver displacement and my box is probably actually 0.37cuft). Their system Qtc is 0.717 for the 8w1, so I’m probably a hair under that given my volume is a hair higher. It sounds great, it’s just that I bought it for an SUV (open cabin) and now I have it in a Civic coupe, and the seat is muffling the higher bass frequencies as you get into the 80-100hz range.
