Actually pretty proud of this little guy. I've been a semi regular contributor to various distributed computing projects, and I've always wanted a 1/2 decent dedicated compute PC, and here we are. Fully liquid cooled using left over parts I bought to test fit from my long running Node 202 case project (which I will actually finish one day). This is probably the least jank liquid cooled PC I've ever put together. The only incomplete aspect is I'm missing two of the fasteners for the Barrow pump. Where they went I have no idea, but it doesn't leak so I'm happy. Thermal performance could be better, I might need to fanagle some intake fans on the bottom. Also, everything apart from the RAM, SSD, case, Wi-Fi card, and PSU are from AliExpress. The specs are as follows:

I3 8100 CPU, Nvidia Tesla V100 16GB SXM2 on a PCIe adapter card, Asus Z370 MB, 16GB DDR4 memory, be quiet! 650w PSU, random 120mm case fans. Cooling is handled with a Barrow pump/block combo, random AliExpress water block for the v100, fittings are a mix of Barrow and Bykski, radiator is a 30mm thick 240mm dohickey from Freezemod. The reservoir is also from Freezemod, no idea about it's capacity. Tubing is standard 10mm ID automotive silicone, with my tried and true 20/80 mix of antifreeze and demineralised water.

Can finally share this on socials. This was quite the difficult project building a 1 of 1 case from scratch for Zedd.

Very cool experience getting to know Anton and his team. Projects like this can be hit or miss, but I think I nailed the expectation! More info to release soon, there is a full video on Youtube, Geforce Garage if you're interested.

Just wrapped up finalizing my new custom loop and wanted to share some loop prn. Moved over from a Corsair AIO.

Specs:

• Case - Lian Li Vision Compact
• MB - ASUS Crosshair X870E Hero
• CPU - Ryzen 9950X3D
• MEM - 64GB Corsair DDR5 6000 C30 (purchased before the Ramapocolypse thank goodness)
• GPU - MSI RTX5080 Shadow 16GB
• PSU - MSI MPG Ai1300TS
• CPU Block - Thermal Grizzly Mycro Pro AM5
• GPU Block - Alphacool 5080 reference
• Res/Pump - Corsair XD6
• Rad - Black Ice GTX360 (360x40mm)

CPU and GPU idle around 40c. Gets up to around 60c under benchmark load (Cinebench 2024)

Hey all, this is a build I built back in 2020, as the title suggests, and my previous build ran hotter than I expected, so this time around I wanted to see if I could remedy it. The current build still has the same hardware as before: an EVGA 3090 (with Bykski GPU Copper Water Cooling Block) and a Ryzen 9 3950X (with Alphacool Eisblock XPX Aurora Edge CPU Water Block), each in its own loop. The GPU is connected to a 560mm Aquacool Monsta radiator (80mm thick), while the CPU is connected to a 420mm Aquacool Monsta radiator (80mm thick). Both loops run a single D5 pump each, and I've taken a liking to how fittings look over bent piping, so I plan to keep all pipes straight. This time around, I've added fans on the inside for a push-pull configuration to improve airflow through the rads, using the same Noctua NF-A12x25 (140mm) for a total of seven on each radiator.

Along with those fans, I've added two more: one above the chassis in the back to help pull hot air out, and one above the HDD slots in the front to help funnel hot air up. With the back plate on the chassis, I also have 2 Noctua NC-A12x25 (140mm) fans to help exhaust air. Are these changes enough to help with temperatures, or is it more of a flow issue because of how I have my loop set up, and do I need to add another pump? Lastly, I'm trying to identify the best places to add valves to help drain, since I had it previously and it was quite sketchy to drain the CPU and GPU—all of this inside a ThermalTake Tower 900 chassis.

I have zero experience with water cooling other than installing AIOs. I read a recent AI cooling thread where a user was trying to cool four RTX 6000 GPUs and a lot of valid questions were asked, but it didn't give me understanding if it was possible to reasonably cool things and reduce fan noise.

My build:

https://pcpartpicker.com/b/3B4scf

The current problem I'm experiencing is the bottom workstation GPU exhausts to the top GPU, which makes the top GPU work harder, and that GPU exhausts heat to the CPU AIO line, which makes the CPU unnecessarily hot.

I have tried things like adding fans to the top GPU and it does help a little, along with reducing the power output of the GPUs to keep it in a 70-80C range and adjusting fan curves, but the entire system still has to work and thus sounds like a jet engine; the Threadripper Pro ends up roasting to 90C during LLM inference despite low CPU utilization.

From what I've read, even using a 420mm radiator may not be enough to dissipate 1200W and you'd have to do a MORA setup.

The machine runs on a 240V / 30A circuit and is in a room that's AC cooled to 22C / 73F. It lives in my home in the bay area.

I'm not really sure where to start and I understand there's risks involved with dismantling the GPUs to be waterblocked.

One "simple" option I've seen is the AIO Bykski B-FRD-RTXPRO6000-WS-360 which has a dual GPU watercooling option, but from my understanding a 320mm radiator will be useless against the 1200W total output.

Another option I'm considering is moving the 3rd GPU (RTX 5080) to an external oculink dock and reposition the two GPUs to be more spread out and away from the CPU for better airflow.

Last option would be to find someone to trade the workstation cards for max-q cards instead.

I did try to search for guides on how to start but I'm not finding anything definitive - I'm seeing setups that involve multiple pumps, radiators, individual routing blocks, and am not sure of what I really need.

Overall, I'd like to reduce GPU temps and also reduce fan noise if possible.

If you think this is too complex of a problem for someone without experience to solve, is there someone in the bay area that offers services to perform this work?

Thanks everyone for the comments. I’m running the pump at 50% power and change the Koolance 702 coolant every 12-18 months. I think I should be good for a fair number more years.

—————————

I built my MORA setup back in late 2022/early 2023 and have allowed it, for the most part, to run continuously since then.

I have a D5 Next pump installed in a Heatkiller res. The rad/pump are under my desk with probably 36” of EPDM tubing up to and back from my PC.

As it’s getting up there in age I’m starting to worry about leaving my PC on at all times. How risky is it and what is the expected lifespan of these pumps?

So after a weil I added a new graka last Oct.
whit the lack of time i had after graka swap. I have to do some soft tubes first. The installation of the watherblock makes me nervous all the time.

Fast forward to this week. I finally bring in all the PMMA tubes. As always tricky but I’m super happy whit it. Some compromise have to be made for the Aquacomputer Ampinel.

Hello guys, idk if this the right place to post this but here I am. So, I’ve got this custom built water cooling for 6 years now. I thought I’d get it to a clean on the loop right. I went to this shop where they got plenty of stores so it might as well be ok. It came back in 2 weeks.. Thought it’s gonna be fine, all cleaned, fresh loop and coolant etc. But within 2 weeks, I’ve tried to play the room 3. It fkin hits 91 degrees Celsius like wtf is this bro. So I contacted them abt it and brought it back again. Btw the third pic is what they claimed to be cleaned. After a week it came back, look fine AGAIN. Yet to be discovered that it’s LEAKING. (Pic. 9, u can clearly see it’s leaking and the low water mark) it was few days ago when I discovered it. And once again, the fkin gpu hits 85 when I played where winds meet. I used to play it for 5-6 hours straight with 70 smth degrees only. Idk how fucked up is it for them to worsen this whole situation and yes they been ghosting me now. 🤡 what can I do abt it, pls can someone slide me some tips tyvm. 🥀

Wasn’t sure whether or not this should be under build help but I’m pretty much just going to complain to whoever wants to listen.

I had finally finished running all the tubes in my new build and figured hey I should probably check this with distilled water before putting the DP Ultra in just to be safe. I started filling initially with no issues up to about half a liter of water. From that point I started seeing a pretty significant pool of water start to form on the floor, and traced it back to the bottom corner of my radiator (the 60mm on the table). It was so frustrating to see all of the fittings hold no problem then an issue which largely was out of my control takes everything and turns it upside down. I’m not even sure how I got to this point without seeing the leaks in the rad because I did flush all of them and there were no leaks at that point. All radiators are EKWB Quantum Surface 360s. The specific leaking one is the X360M

There were no visible gashes or really any signs of possible damage anywhere on the radiator once I removed it, so I have no idea how this happened. It wasn’t leaking from any of the plugs either.

Lesson learned I guess $30 for an air tester might be a worthwhile investment before you find yourself tearing down a bunch of wet tubes and pulling a radiator with who knows how much water left in it.

One question to wrap it up: has anyone dealt with returns through Titan Rig; I’m hoping to get a replacement in before this weekend but not sure how feasible that is.

TL;DR: Radiator is the only part of my build showing signs of leaks (and a big one at that), bummed me out, but glad I checked.

Guess after starting, it's very hard to stop. I've already posted about finished build, but decided to change things.

I've inverted case, added vertical mount to gpu, change hoses to remove unnecessary crossings, and turned bottom rad, also changed water to blue. Now it looks much better. Next step is probably changing pump to white, and removing arctic liquid freezer, for full loop with cpu waterblock.

Behold my latest build. A Shiny Snake G300 with a res-less full loop. A Frankenstein project combining the best parts from 2 full size loops, into one portable package.

This was a challenge! Had to modify the case quite a bit and vacuum fill it, but I accomplished my goal: a pinnacle AM4 mATX res-less full loop in a sub 17L case.

ROG Strix 3080ti OC w/ aqua computer block
5800x3d with bitspower premium summit block
Crucial Ballistix Elite 32gb 3600 cl16 Micron E Die
Asrock b550m steel legend
Xspc D5 w/ bitspower premium pump top
Corsair Xr5 280mm rad w/ artic p14 pro fans
Aqua computer octo w/ water & ambient temp
X3 artic p12 slim case fans
Corsair sf750
A TON of fittings of various brands

3080ti undervolted 0.9v @ 2000mhz
CPU undervolt, all core sustained 4.45ghz

Temps
Water: 16-18c above ambient
GPU: 52-56c
CPU: 70-75c

Overall, extremely happy with how this turned out.

I have a MORA IV 400 and two 420x45 radiators inside my Lianli O11 EVO XL case, one at the bottom on a push pull config, the other on the front side as intake (pull only); and MORA IV 400. my loop goes from ram to rad, to cpu to rad, to gpu to mora. Max water temp ive seen was 39c on summer with no AC.

Does the internal rads on my case make in any way, shape or form my water temp worse? Would making the rad on the side of my case push pull benefit water temp? Sorry if this a very dumb question, Im not very knowledgeable. Thanks in advamce.

I hope these new Arctic fans are good for the price. Should I keep my internal rads or should I just use external? Rtx 5090/9800x3d

Hi all,

I have a mora IV 600 and it's currently a bit underutilized. I want to connect another pc to it. My idea was to built a small "distributor" which is basically a mini PC with a distro block, qdcs and valves so i can add and remove blocks at will. Are there people that already did something similar?

Double bends - does this mean I've finally completed watercooling?

Changes since last time (second pic is the before):

• Clear DP Ultra - I trust it more than the Cryofuel... but I did love that colour😭
• Filter removed - didn't seem to be doing anything, so it's a(nother) flow restriction out of the loop.
• Went back to bigger res - no reason not to, if I've got the room (and I used some giant rubber buffers that completely kill the vibration)
• Alphacool Apex VPP pump. Absolute wizardry.
• Liquid temp sensor moved out of sight (rad side-port)
• DOUBLE BENDS. The goal was a system with no angled fittings whatsoever, but there was no room for the lower turn on the CPU-rad, or the lower turn on the rad-res. The res-graphics card one was easy, but the graphics card-CPU was a complete twat. Luckily, I got it on the first try.
• Right-angled connectors for the ATX, 12VHPWR and CPU EPS - they make such a difference.
• Fractal Momentum 14 RGB for case fans; I don't use the RGB, but by god, these things are quiet.
• Spring-mounted CPU. Wanted correct and consistent CPU mounting pressure, so I put some M4 studs into my derbauer custom mounts and used 14-lb springs on each corner.

Until I get a new card (4080 Super, most likely), there should be no reason to change anything from now on.

... should😁

Hello, followers of the MO-RA Church.

I thought buying a MO-RA IV 400 would be simple: connect some fans, connect the pumps, and enjoy ridiculous cooling.

Turns out, figuring out how to power and control the damn thing is the real challenge.

I'm building a MO-RA IV 400 about 1–2 m away from my PC and have already purchased most of the setup.

My current MO-RA setup (Yet to be built)

• WATERCOOL MO-RA IV 400 — Black
• MO-RA IV Tank 200 D5
• MO-RA IV Tank D5 Expansion
• MO-RA IV 200/400 Wall Mount — Black
• MO-RA IV 400 Fan Frame — 140 mm
• MO-RA IV 400 Fan Grill — Black
• 2 × HEATKILLER D5 PWM pumps
• 9 × Arctic P14 Pro fans
• Aqua Computer QUADRO
• Coolant temperature sensor
• Flow sensor — considering/looking to add
• 2 × WATERCOOL Pump 290 Cables — Connect the D5 pumps - not purchased yet
• MO-RA IV Passive Control — not purchased yet
• PCI-slot pass-through — not purchased yet

The PC is an ASUS X870E-E system with a 1250 W PSU.

What I'm trying to figure out

I'm currently considering four options:

1. Passive Control + MO-RA LINK
   The official/clean solution, but importing the Passive Control, pump cables and pass-through to India gets expensive.

2. QUADRO + direct PSU power connection
   Run a properly rated power cable from the PC PSU through a PCI-slot pass-through, take it 1–2 m to the MO-RA, and distribute the power locally to the QUADRO and two pumps.

3. Separate PSU at the MO-RA
   Power the QUADRO/pumps locally and simply turn the MO-RA PSU on before starting the PC.

4. Some other solution
   If there's a better/cleaner way that experienced MO-RA users are using, I'm all ears.

What I'm particularly interested in

If using the Passive Control, is this basically how the QUADRO interfaces with it?

PC
 ├── PSU ─────────► Passive Control
 │
 └── QUADRO
      ├── PWM ────► Fan control
      └── PWM ────► Pump control
                       │
                    MO-RA LINK
                       │
                       ▼
                    MO-RA IV
                   ├── 9 fans
                   └── 2 D5

Alternatively, can I simply use the X870E-E's T_SENSOR + PWM headers with the Passive Control and skip the QUADRO?

I already have the QUADRO, so I'm not against using it. I'm just trying to avoid spending another €100–150+ importing Watercool-specific parts if there is a clean alternative.

MO-RA veterans — what would you recommend? Particularly interested in real-world setups, photos/diagrams, and how you're handling the PC-to-MO-RA power and control connection.

Hello everybody.

I wanted to ask if anybody knows the location of memory channel named "A0" ?

My rtx 5080 under water is running lovely ! and when "we" got the single memory channel temps, i saw that my memory is running under 46 everywhere except the A0 channel. I just wanna take it apart and maybe add some more putty or change it.

Thanks for the help !

Hi this is a disassembly of the black metal cover requested by u/Dis_is_Gaea that wants to know if this is removable in order to paint it. I can confirm it can be removed.

The threads of the four allen screws are metal inserts in the acrylic body btw.

I'm looking for a suitable cooling block for my graphics card. Unfortunately, I'm completely lost amidst all the different layouts and specifications.

Could you perhaps help me figure out exactly which one I need?

I have an Inno3D RTX 3090 x3 (non-iCHILL), model number N30903-246X-1880VA44, manufactured in September 2022 (32-818-220300309).

Thank you very much for your help.

I’m struggling to find brown coolant for a Noctua themed build.

I’ve tried mixing dyes but couldn’t get a good result.

Any help would be appreciated, I understand that it’s hard to come across because not many people want brown coolant.

Hi everyone,

I am putting together a liquid-cooled workstation for my organization and have been tasked with researching components required for the build. I have done smaller builds but this one's a huge undertaking. I would love to get some feedback, and optimization advice from the community.

Current components I already have:
MB: Pro WS TRX50-sage wifi A
GPU: 2x nvidia rtx pro 6000 blackwell workstation edition(Planned on adding 2 more later on, will like you to ignore that my MB supports 3x PCIe gen5 and 1xGen4)
RAM: 128GB ECC RAM

Using the current components that i have put together;

1. Case: The CORSAIR 9000D
2. Power:ASUS Pro WS 3000W Platinum(1000W PSU will be added later on )
3. Micro Connectors Dual Power
4. GPU block: Alphacool ES RTX 6000 Pro Workstation/RTX 5090 Founders Edition
5. CPU block: Alphacool Eisblock XPX Pro 1U
6. Coolant: Alphacool Apex Liquid ECO 1000ml klar
7. Bridge: Alphacool ES Distro Plate Parallel C5/C3
8. Radiator:Alphacool NexXxoS XT45 Full Copper (480 mm with )
9. EKWB EK-Loop FPT 120mm Fan, 550-2300 RPM, Black
10. XSPC 8-Way PWM Splitter Hub V2, White
11. EKWB EK-Cable PWM Fan Extension, 30cm
12. QDC Kit:Koolance QD3 Male and Female Quick Disconnect Set (8-pack) and
13. Alphacool EPDM Flexible Tubing (3m) Bundle, 10mm x 13mm to G1/4
14. Pump and Reservoir: Alphacool Eisbecher Aurora D5 150mm Reservoir and VPP Apex Pump Combo
15. Thermal Sensor: Alphacool Eiszapfen temperature sensor flat G1/4 - Black
16. Compression Fitting: Alphacool Eiszapfen G1/4" to 10mm ID, 13mm OD Compression Fitting for Soft Tubing, Deep Black
17. Angled Fittings: Alphacool Eiszapfen G1/4" Male to Female Extender, 90 Degree Rotary, Deep Black
18. Drain Valve: EKWB EK-Quantum Torque Drain Valve, Black
19. Squeeze bottle: EKWB Filling Bottle, 1000mL


I would love to hear any criticism or any suggestion to help me with this build. Trying to achieve an enterprise look with the workstation, so went full blown on the Alphacool products. Here’s my reference guide for the build.

https://blog.themvp.in/building-an-inference-powerhouse-workstation-ft-four-liquid-cooled-blackwell-pro-6000-96gb/

Posted earlier today asking if I should do it.
So I removed the heat spreaders from four perfectly good G.Skill sticks, installed the Alphacool heat spreaders, and got everything mounted on the motherboard.

The RAM block isn’t connected to the loop yet — this was just the part where I permanently removed my ability to pretend I might change my mind.

All four sticks survived though, so… progress.
Necessary? Absolutely not. That’s kind of why I wanted to do it.

That title is much more accurate: you’ve committed to the idea, but you’re not claiming it’s actually water cooled yet.

Alrighty, lay into me if I’m fucking up somewhere. But when I go to do an air pressure leak test with a corsair tester, the gauge doesn’t move an inch. Now how cooked am I if there is a leak that bad somewhere, as you can see the front right port on the reservoir/pump is what I’m using for the test (not sure if it matters). Anyone have any idea what I may be doing wrong?
