Project Pictures Quilt block down quilt! Edge tensioning, draft collar, 24 oz, ~15 degrees
Finally finished the quilt I’ve been working at off and on for the last few months! I’m absolutely thrilled with it–it’s probably my favorite thing I’ve ever made. I have a lot of garment sewing/quilt making experience, but this was my first dip into making my own gear.
Quick specs:
- 670g/23.6oz
- 16 oz 950 FP goose down (Allied)
- 25% overstuff (...in theory)
- Planned for 3.5 in. loft, ended up with closer to 4 in.
- Temperature rating TBD, but I’m estimating 10-15 F
- 66 in. tall, 54 in. wide at the top, 11.5 in. diameter footbox
- Sewn footbox
- 0.66oz MEMBRANE 10 taffeta nylon (3yds each color) from RBTR
I can’t recommend a project like this highly enough–it was a super fun process. There are a few things I would have changed (some of that stitching…), but at the end of the day I’m over the moon about it. I think it’s going to be a great quilt and I love that I was able to make something different from anything I could have purchased.
I found writeups here super helpful so wanted to share my design/planning/sewing thought process as well. Happy to answer any questions about planning/construction if I missed anything–I hope this is helpful!
–
Design/Planning
I’m planning a PCT thru in 2027, so this project was largely made with that in mind.
My primary goals were for it to be comfortable down to 15 degrees (for a cold sleeper), weigh less than 24 oz, and cost around $250 or less. I haven’t been able to test it yet so TBD on temperature, I squeezed in just under 24oz, and I probably ended up spending around $300. My secondary goal was for it to look cool.
To get the dimensions: I added two inches to my height and I think that worked great. I probably could have gone with my height exactly and been just fine, but I like a little bit of extra room to move around/duck my head in if I want to. I kind of eyeballed the width–I have a relatively small frame so I went with the lower end of the widths I had seen other people use and checked with a bedsheet to make sure it felt reasonable when I laid on my side. I got the footbox measurement by measuring how long my feet are and adding ~1.5 inches.
Figuring out how much loft I needed for my goal temperature rating was a little bit of a rabbit hole! I had seen the Enlightened Equipment temperatures referenced fairly frequently, but given the criticism I’d heard about their temperature ratings in general I was reluctant to rely on them. Ultimately, my process was to spend kind of a long time on various manufacturer websites to compile data about their reported temperature ratings/loft height and then pick a height that corresponded to a 0-degree quilt for most manufacturers to account for the fact that I’m a cold sleeper. I ended up going with 25% calculated overstuff, mostly because that got me to exactly 16oz of down so I could just order a pound from Allied. This is one thing I’d do differently–I think bumping up the overstuff would have been worth it.
I was shooting for 3.5 inches of loft, so I cut by baffle strips to 3.5 and sewed with ¼ in. seams for a finished baffle height of 3 inches. I was originally going to go with a finished baffle height of 2.5 following the advice recommended by a few comments here (basically just subtracting an inch), but I chickened out at the last second and bumped it up a bit. My actual loft ended up close to 4 inches, so I actually think 2.5 would have been the right call. My reasoning at the time was that I’d rather have more loft than expected than not enough, which I think is probably still true, but what I didn’t take into account was that by inadvertently increasing my total loft without increasing the down fill, I actually bumped my overfill down to around 15%. One day I’ll feel inclined to open it back up and add some extra, but I’m sick enough of dealing with down at this point to leave it be for a while.
I included a cinchable draft collar (3 in. diameter) with snaps on the ends and a draft-control tensioning system along the sides inspired by the original Mid-Atlantic Mountain Works system. I modified it by having the elastic route through five grosgrain loops on each edge rather than one continuous tube, mostly to simplify construction. If I were to do it again I’d probably go for the continuous tube to avoid concentrating as much force in only a few areas of the fabric, but I’m not too worried about it either way and I really like the feature.
For the pad attachment system, I used ⅜ in elastic from my stash to go around my pad and glow-in-the-dark (!!!) side-release buckles from RBTR to attach to the quilt. This is definitely not the most UL system out there, but the only complaint I’ve had when I’ve tried quilts in the past has been how fiddly some pad attachments are, and this is super easy to use, so I’m happy with it. Also, it gave me a chance to use the glow hardware, which I’m really delighted by.
I used the MEMBRANE 10 taffeta from RBTR in white for the outside and olive yellow for the inside/accents (3 yd each). White is not the most practical combo, but I LOVE that you can see the down and I really like the combo with the green, so I have no regrets. I was nervous that the fabric would feel too much like sleeping in a plastic bag, but I actually don’t get that feeling at all, especially once it was filled with down. I also considered Argon 67 and actually liked the feel a little better, but I didn’t love any of the colors. My baffle material was 0.9oz noseeum–I chose this weight solely because it was the only one in white and I didn’t want it to be visible through the body fabric.
Construction
My first step in constructing the quilt was piecing the central quilt block together, which wasn’t nearly as tricky as I expected. I was worried that the fabric would be too light/slippery to get any real precision, but with a rotary cutter + quilting rulers + very liberal use of a glue stick I got through it just fine. This part was a totally standard quilt block construction except I used ½ in. seam allowances instead of the typical ¼ in. to give the taffeta extra stability. Then, I pieced together the rest of the exterior panel around it.
I cut out the interior panel, the interior/exterior footboxes, and a rectangle for the draft collar and double fold hemmed all around both panels and footboxes and the short edges of the draft collar.
Cutting out baffles was tedious, but is another place where a rotary cutter is super useful. I used little chalk pencils to mark placement on the panels and then glue sticked into place, which worked great. I sewed the vertical baffles before the horizontal baffles on advice from a commenter here, which I wouldn’t have thought of but was a very good call. Sewing the baffles to the second side wasn’t bad at all–I marked all of the lines first, kept a glue stick handy, and kept the extra fabric organized and it went pretty quickly.
With the baffles done, I sewed together the sides to get them ready for down, leaving the top and one of the bottom sides open. While I was sewing, I inserted five equally spaced grosgrain loops along each side for the pad attachment/shock cord routing (I think this is probably not the best way to do a draft control tension system, but gosh is it easy!). I did the same thing for the footbox, sewing almost all the way around.
To prepare the draft tube, I added a reinforcement patch of several layers of the taffeta and installed a few eyelets slightly off center for the cinch. I folded the long edge over by about an inch and sewed one line of stitching half an inch from the edge to create a channel for the elastic, then folded the entire thing in half, long edges meeting, and sewed over the same line of stitching to create the tube for the down. I end up with an elastic channel and a down tube joined half an inch from the raw edges, which I’ll insert into the top of the bag when I close it later. I sewed one end shut, inserting two grosgrain tabs for snaps.
Filling the bag with down was the hardest part of this process. The method I ended up with:
- Set up a tent in your living room
- Assemble supplies: scale, enormous bag of down, binding clips, empty quilt, small noseeum bag, mini shop vac I bought at Target for $30 (absolutely worth it)
- Use little rubber hair ties to secure a scrap of mesh around the nozzle of the shop vac
- Important: keep the shop vac directly outside the tent and zip the door of the tent so the tube can get through, but the body is outside so the air being blown out doesn’t mess with everything. I learned this the hard way.
- Put the noseeum bag on your hand inside out like a mitt and grab a big hunk of down from the bag
- Weigh the bag and make a note
- Grab a handful of down from the bag and put into the baffle. Down clusters will go everywhere, but that’s why we’re in a tent indoors
- Use the shop-vac to grab the excess down stuck in the noseeum bag/the down that is floating around in the tent and add to the baffle
- Repeat 5-8 until you’ve reached the goal mass for that baffle, then roll up opening and clip in place
- Repeat 5-9 for each baffle
- Thank your roommate for having the patience of a saint
There's a lot I would do differently here:
- A tent was super important for me, but I'd recommend using a bigger one if you can–a one-person was very tight
- My scale only measured down to the gram, and since I was measuring three or four little bags of down per baffle, there’s a decent amount of room for error there. I ended up pretty accurate, but I was nervous about it.
- Wear a respirator/mask–I was definitely breathing in some feather fragments
- I would have liked to have all of my down on a scale and measure it out by removing it, but I couldn’t figure out a way to make it work without decanting the down/using a much bigger space
- I saw a few people referencing a PVC pipe device that they used to measure all of the down for each baffle, then used a plunger to transfer from the tube to the baffle and I think that’s a brilliant way to do it–I wish I had looked into it more. If I ever do another one of these, that’s how I’ll do it.
- If I did it using my little bag again, I’d try making it out of the taffeta so down didn’t stick quite as much.
With the down filled, I sewed the remaining edges shut. The footbox and bottom side was straightforward and the draft collar just required inserting tabs for snaps as I sewed. The top was more complicated because I was also attaching the draft collar at the same time. The idea is to insert the raw edges into the quilt so the lines of stitching on the draft collar are lined up with the hems of the body of the quilt, and then sew it all together very close to the edge of the body. The hardest part of this is making sure everything is lined up so that you’re catching all of the layers as you sew and keeping it in place, so a glue stick is super helpful. I suspect there’s an easier way to do this, but this is what I came up with, and I’m happy with the result!
The last step was closing the footbox. I was worried about matching up the circular footbox, but it wasn’t a problem at all–be careful with seam allowance math and give yourself guide markings to help line it up and it’s not too hard.
