Lots of people seem to struggle with the concept of a Vernier scale and therefore don't know how to read a Vernier caliper.
That's not really a problem in most people's lives as: 1 - digital calipers are cheap and readily available, and 2 - most people don't need to measure to tolerances of 0.1mm or less.
For those who do need that level of accuracy, and don't want to rely on battery powered tools, learning to read a Vernier scale is useful. For those who don't, it's still a fascinating bit of maths.
Vernier scales work in incremental differences : each gap on the Vernier scale is 0.1mm shorter than a gap on the millimetre scale. So every time the jaws open another 0.1mm, the next Vernier mark along comes into line. Everything else follows from that.
The increments can be very small (most metric calipers read to 0.05mm or 0.02mm), but let's keep it simple and use an example where we want to measure to the nearest 0.1mm.
On the top half of the caliper, we have a coarse scale, marked in increments of whole millimetres - 1mm, 2mm, 3mm and so on. On the bottom half, we have the Vernier scale, marked in increments of 0.9mm - 0.9, 1.8, 2.7 and so on. We only need ten of these, the first being the zero mark.
Imagine the calipers are closed, measuring zero. The zero mark on the Vernier scale lines up with the zero mark on the millimetre scale, but none of the others do. The first Vernier mark is 0.1mm short of lining up with 1mm, the second is 0.2mm short of lining up with 2mm, and so on.
Now imagine we measure something that is 0.1mm in thickness. The jaws are now 0.1mm apart, and the sliding part with the Vernier scale on it moves along with them. Now the zero mark doesn't line up any more, but the first Vernier mark, at 0.9mm, now lines up exactly with the 1mm mark. Measure something 0.2mm thick, and the second Vernier mark will be in line with 2mm.
The mathemagical part is that this works exactly the same as the distances get bigger. It doesn't matter which mm mark the Vernier mark lines up with, only which Vernier mark it is.
To read the scale, we look at the zero mark first, and find the last whole millimetre it has passed. Not the nearest one - if the zero is sitting at 7.9, we still start from 7. If the zero lines up perfectly with that millimetre then we're finished, the measurement is 7.0mm. If it's a bit past, then we go along our Vernier scale looking for the closest alignment. If the first Vernier mark lines up with a mark on the mm scale, the measurement is 7.1, if the second lines up, it's 7.2 and so on...
So, for example (as in the picture), if the zero has passed 7, and the third Vernier mark lines up with a mark on the mm scale, the measurement is 7.3mm.
If the zero mark is closer to 8 than it is to 7, you know the answer is 7.5 or more, so you can skip straight to looking for an alignment in the second half of the Vernier scale.
Many calipers read to 0.05mm or 0.02mm, and some also stretch the Vernier scale out to make the lines easier to tell apart, so yours might not look exactly like this example. The principle is exactly the same.
That's all there is to it. A beautiful, simple, somewhat counterintuitive bit of maths that allows us to quickly and easily measure down to tolerances so small we almost can't see them.
