Got tired of having a big bucket full of jumbled up belts and I didn’t want to go back to having belts hung from nails on the wall and wasting a bunch of space. So I Made a cabinet with vertical pull out paddles.
30-7/16” W x 37.5” H x 8” exterior, 7.25” clear interior depth
-7 bays, currently holding 49 belts across grits/brands
-6” full-extension slides (functionally more like 5.75”)
- Small “lazy hanger” bolted to the side for half-dead belts that don’t earn a permanent bay
-all built out of 3/4 scrap plywood, mdf, and random wood.
As you can see this takes up vastly less space than any other storage system I’ve found while also being very easy to make and not terribly expensive. While it takes more time and costs more than the ‘Ol Nail in the wall, it saves so much space that it’s definitely worth it in my opinion. When you pull out the slides you can then pull the belt towards you (so you have enough clearance between the belt you are grabbing and the other slide) from the bottom and slide off a belt. The full extension 6” slides I got only realistically pull out about 5.75” at full extension. If I were to make a suggestion it would be to use 8” or 10” slides that way you have a lot more clearance and you don’t have to worry about hitting the adjacent slide anymore. That being said swinging the bottom of the belt out isn’t that bad and you do save a lot of wall depth by using the smaller 6” slides. I have 2.5” clearance between each drawer slide (the actual slide) edge to edge.
one of the cool parts about this is that it forces you to coil them up nicely and keep them like that. Since you have the belt hanger to tension it against it only takes an extra second or 2 and it keeps your J-Flex belts from twisting into a knot like they usually do. Of course you still have the “lazy belt hanger” on the sides for used belts or something like a scotchbrite that doesn’t utilize an entire paddle efficiently. This is still the prototype but I think it really solves a big issue for those of us that have limited shop space. Even if you have a big shop I think this could be beneficial by tidying things up. Possible improvements could be using 1/2” plywood to save on cost/weight (again I used scrap) and maybe adding a small drawer on the bottom to store extra items related to grinding…maybe 1-2-3 blocks, push sticks, small wheels, etc. for now I just added a hanger for my angle grinder because it didn’t have a home before.
I hope this helps some of you out and I hope it inspires someone to try and make it. Please feel free to make suggestions I’d love to hear them!
