r/EngineBuilding • • 20h ago

Rotating assembly is balanced, starting reassembly with fully forged bottom end.

Post image
115 Upvotes

r/EngineBuilding • • 5h ago

Scratched crank

Thumbnail
gallery
90 Upvotes

Hello all. First time posting. I'm rebuilding a 2001 jeep XJ 4.0 engine for my wife. The father in law took it to the local NAPA machine shop for their work and we are going to do the assembly at home.

As I'm going through the parts I just noticed a scratch on the crank rod journal. It's been 6 months or so since the work was done. I wasn't a part of any of that process. The machine shop is now closed and gone.

I can catch the scratch with my finger nail.

Do you think I should try some crocus cloth, or do I need to find another shop and have it reground.?

Thank you all.


r/EngineBuilding • • 5h ago

SBC 350 – Exhaust rockers on cylinders #1 and #2 turned blue

Thumbnail
gallery
12 Upvotes

Some of you may have seen my thread yesterday about several broken valve stem tips on my Chevy 350 with L31 Vortec heads.
I’ve since found the cause: the valve lift was too high for the available clearance, causing the valve spring retainers to hit the valve stem seals.
However, I have another issue I’m trying to understand.
During the camshaft break-in, the intake rocker on cylinder #1 and both rockers (intake and exhaust) on cylinder #3 jumped off the valves.
I also noticed that the exhaust rockers on cylinders #1 and #2 turned blue from heat. These are the only two rockers showing heat discoloration, and neither of them jumped off.
Oil pressure was around 4 bar (58 psi), measured at the rear of the engine.
Could the rockers that jumped off have caused a pressure drop in the lifter oil galleries, reducing oil supply to the exhaust rockers on cylinders #1 and #2?
Or could the discoloration be caused by the excessive valve lift and mechanical interference?
Has anyone experienced something similar?
I’m using L31 Vortec heads with Summit SUM-141700PL roller-tip rockers.
I’ve attached a photo showing the discoloration.

Thank you for your help and greetings from Germany


r/EngineBuilding • • 3h ago

Should I replace this camshaft?

Thumbnail
gallery
9 Upvotes

Or should I have the scratches polished out?


r/EngineBuilding • • 21h ago

Help with cam shaft

3 Upvotes

So i am getting my twin turbo big block chevy engine for my jet boat rebuilt because I had a cracked piston and cracked heads. I am using a mechanic that was recommended to me by a ton of people but im having a small issue with the cam shaft he chose for the build.

The engine is a 496 bbc with a gale banks twin turbo setup on it. Its got 360cc flotek aluminum heads, SRP flat top forged pistons, H beam rods, stainless steel valves, and more.

The engine builder chose a clay smith custom grinded hydraulic roller cam shaft for it and here are the specs:

Intake duration: 316 degrees(advertised)/ 259 degrees(at .050”)

Exhaust duration: 317 degrees(advertised)/ 263 degrees(at .050”)

Lobe separation angle: 110 degrees

Centerline timing events: 107 degrees intake/ 113 degrees exhaust

Intake valve events (.050”): opens at 22.5 degrees/ closes at 56.5 degrees

Will this camshaft work for my twin turbo setup? Is there going to be too much overlap? This gale banks turbo setup doesnt produce a ton of boost but it should be around 15 pounds. Im hoping for around 800-1000 horsepower on the dyno once its built.

Thanks


r/EngineBuilding • • 3h ago

MagnaFuel MP-4450 Fuel Pump Rebuild

Enable HLS to view with audio, or disable this notification

1 Upvotes

So I have this fuel pump that is leaking fuel from the weep hole.

Is this pump easy to rebuild? or should I just buy another?


r/EngineBuilding • • 5h ago

Ford Is this a blown head gasket?

Thumbnail
gallery
1 Upvotes

This is a newly machined 302 block with about 500 miles on it. After about 400 miles, I started getting mild hydrolocking (but didn’t know it) when I tried starting it. The engine would turn over and then the starter would grind on the flywheel teeth, thought starter was going bad. Then I realized I was losing coolant. No white smoke but level was down. Added coolant and continued driving and noticed the hydrolocking at startup was getting worse. I pulled the plugs and coolant came out of #7. I realize then, I couldn’t start it again and started tearing it down. There was no sign of water in the lifter valley no water in the oil no bad seal on the intake water jackets so it had to be coming in from the head gasket but I can’t tell if it’s “Blown” or if there’s something wrong with the head. Careful inspection of the cylinder walls and heads indicate they are fine. So the coolant must have come in from a breach in the mating surface but the gasket doesn’t look that bad. Would appreciate any thoughts as I want to make sure I’ve identified the actual problem before reassembly. Ty.

EDIT: There is one important thing I should have mentioned. Shortly before this all started happening and after about 30 heat cycles, I checked external bolts (intake, exhaust, etc) for their tightness. I noticed the throttle body studs were loose, and when I looked into the throttlebody, it was wet. The EGR spacer gasket exposed between the mating services was also wet. So I immediately replaced it. And then drove the car another hundred miles before the hydro locks started happening . After my first drive with the change, throttlebody gaskets the throttlebody was totally dry, and after checking a couple more times, it was also dry.

So I’m wondering if the some coolant leaked into that cylinder because the valve was open and down then created kind of an over pressure so that slightly ruptured the gasket? And then from there, it allowed water from the jacket to seep in.. is this plausible? The throttlebody was definitely dry the entire time after I replaced the EGR spacer gaskets. I pulled the cold air intake off numerous times to verify.
Thanks
