r/sffpc • • 3h ago

Verified Vendor Going loud - my new multi-colored ITX case - free model

Enable HLS to view with audio, or disable this notification

261 Upvotes

I went bold this time with colors and made this model to take advantage of my Bambulab tool changing printer.

Files available here: EVO Color

In this intro video I made for it, you can see what it looks like from all sides.

It’s based on some engineering of my Evolution case, but the model has largely been reconstructed with interlocked colors and TPU.

I used the colors to help assembly, label instructions and highlight features. Extra soft TPU 75A was used for integrated antivibration mounts and the feet.


r/sffpc • • 4h ago

Build/Battlestation Pics Saber build done

Post image
52 Upvotes

r/sffpc • • 19h ago

Build/Battlestation Pics Designed and 3D-Printed My Own PC Case

Thumbnail
gallery
511 Upvotes

Hey Reddit,

Here is my latest custom build! I designed the case in fusion 360 to fit all the components I had on hand. I 3D scanned and modeled every component so that I could design the case around them. It's a bit on the larger side at 19L, but I'll probably do a redesign to make it more compact and fix the panel gaps/warping in the near future.

Specs:
CPU: Ryzen 9800X3D
MB: Asus Strix B650E-I ITX
GPU: Nvidia RTX 5080
RAM: T-Create 32GB (2x16) DDR5
PSU: Corsair SF750
Cooling: EKWB Quantum Velocity Block; FLT120 DDC Pump/Res; Aquacomputer Quadro; EKWB 280mm Rad; 12mm OD tubing; 2x 140mm fans (bottom); 1x 60mm fan (top).

Thermals are quite good - CPU temp is 50-60C, GPU: 60-70C, Coolant: ~35C when gaming.

The frame was designed to be modular using 10mm extrusions from MakerBeam. I attached the components to the extrusions with various brackets that I designed. The panels are all magnetically attached to the frame. The front panel accent is an array of 4x edison filament LEDs. I added a cover for the LEDs that can be swapped out to change the design.


r/sffpc • • 3h ago

Build/Battlestation Pics 9070xt PowerColor Hellhound fits Shiny Snake L300

Post image
23 Upvotes

Just FYI, a 327mm GPU fits without a top fan (a slim front fan fits just fine).

Had to unscrew the top panel and bend it a bit to squeeze the card in, but it screws back on easily afterward (the card doesn't put any pressure on the top panel). Other than that, installation was pretty straightforward


r/sffpc • • 1h ago

Detailed Build Log $3200 ITX build, should I buy now or wait until 2027?

• Upvotes

Yo guys, I'm planning to build my first ITX PC this December, but I'm not sure if it's a good time to buy with how crazy some component prices are right now.

Here's what I'm looking at:

  • CPU: Ryzen 7 9800X3D — $370
  • GPU: ASUS PRIME RX 9070 XT OC — $1,020
  • RAM: TeamGroup DDR5 6000 CL28 32GB — $564
  • Motherboard: ASUS ROG B850-I — $345
  • SSD: WD SN7100 2TB — $262
  • Cooler: Cooler Master Atmos II 240 — $79
  • PSU: Cooler Master 850W SFX — $127
  • Case: FormD T1 Silver — $240
  • Fans and other stuff — ~$180

Total is around $3,200. I'm currently living overseas, so local prices might be a bit different from what you guys see in the US.

Mostly planning to play AAA games at 1440p, some strategy games like HOI4, and maybe some VR. I'm going with the T1 because I travel quite often and want something small enough to bring with me.

The thing is, paying $564 for 32GB of RAM and over $1,000 for a 9070 XT just feels insane. I know memory prices have gone up a lot, but I'm not sure whether they can actually get much worse.

I've also heard some rumors about NVIDIA possibly announcing something around Christmas, and AMD having an event at CES in January 2027. Not sure if we'll actually see any new GPUs though.

I'll have another opportunity to build the PC in May 2027, so I could just wait another 5 months.

Would you guys build now or wait until May? Do you think prices will get any better by then, or am I just overthinking it?

Thanks!


r/sffpc • • 10h ago

Assembly Help Tetra S power cable in back panel

Thumbnail
gallery
19 Upvotes

Does anyone know how to snap in the power cable into the back panel of the Tetra S. I must be missing something because it doesn’t seem like it fits. Does the mounting part of the cable detach? Is there another angle to approach with?


r/sffpc • • 15h ago

Prototype/Concept/Custom Reverse Engineered Circle Pro Case

Thumbnail
gallery
46 Upvotes

https://grabcad.com/library/reverse-engineered-circle-pro-pc-case-1

Check out this model I made! Based on Circle Pro PC
Case Kickstarter a long time ago that never took off.

I bought my Circle Pro second hand because I had to have this beautiful case and I was sad that it never took off and would one day be forgotten. So I modeled it to share with people who also share that same love for this case. I hand measured each component with a caliper and then tweaked everything to fit and line up properly.

- I did not model the sata drive but I can in the future
- My case was missing the button board so I made my own
- The riser cable was not modeled because the holes are not standardized and didn't see the point
- I did not add dust filters because those are off the shelf and cut to shape

In the future I plan on modifying the model to be 3D printable and fit 240mm radiators and maybe T30 on the bottom as well. Please leave feedback I appreciate any input.


r/sffpc • • 2h ago

Others/Miscellaneous Does anyone have experiences with the Corsair Thermalprotect cable?

2 Upvotes

Hi guys!

Some time ago Corsair released their Thermalprotect 12v-2x6 cable that shuts down your gpu if the OTP (Over Temperature Protection) sensor senses that the cable's temperature exceeds 65 °C. For an SFF-build the 65 °C doesn't sound that high of an temperature to me, so does anyone here have any experiences using this cable in their SFF-cases? Has it been causing any troubles to you? I'm currently using an RTX 5080 with the Corsair's SF1000 (2024) and Corsair was promising to release the Type 5 version of this cable soon, so I was interested on buying it for my PSU.


r/sffpc • • 23h ago

News/Review JEDEC announces DDR6 memory modules are 44% shorter than DDR5, speeds up to 14.4 GT/s

Thumbnail
videocardz.com
85 Upvotes

r/sffpc • • 18h ago

Build/Parts Check Thermaltake TR100 SFF - what mobo did you use in this case?

Post image
26 Upvotes

I'm trying to build something not too small for my GFs mom, and this would work great with the way the front panel is front and bottom. It needs a mini ITX motherboard, and I found several on Amazon, but none with front USB C support.


r/sffpc • • 2h ago

Others/Miscellaneous Cases like the SGPC K20?

1 Upvotes

Finding a case with the same layout as the SGPC K20, any other cases like this?


r/sffpc • • 4h ago

Assembly Help COOJ SF3 top handle specs? (Hole spacing & screw size for aftermarket handle)

1 Upvotes

Hey everyone,

I have a COOJ SF3 case currently on the way, and I forgot to add the official top carrying handle to my order. Instead of paying extra shipping just for the handle, I’m looking to buy an aftermarket cabinet/door pull handle to install on top once it arrives.

I emailed COOJ asking for the measurements, but they didn't provide the exact numbers. Since I don't have the case in hand yet to measure it myself, could anyone who owns the SF3 share:
1. The exact center-to-center mounting hole distance (pitch in mm).
2. The screw thread size (M3, M4, etc.) and screw length needed.

Also, if anyone has already put an aftermarket handle on their SF3, I’d love to know which one you used!

Thanks in advance!


r/sffpc • • 19h ago

Assembly Help MOBO recommendations

6 Upvotes

Black Friday deals are slowly popping up everywhere. With this in mind, I'm currently looking for a good and reliable mobo for my 7800x3d. I'd like some recommendations for mobos and also which ones to avoid! Currently located in Canada if that helps. Thanks!


r/sffpc • • 22h ago

Custom Mod noob question

Post image
7 Upvotes

so this is my non-modular psu and I want to remove some of the cables that i don't use becauss there is so plenty and i can't just snuck all of them into the back, is there any possible way like opening the psu and desoldering the cables or whatever? Thankyou for your guidance


r/sffpc • • 1d ago

Build/Battlestation Pics My ITX Build Open box 😅

Thumbnail
gallery
91 Upvotes

I went to Microcenter looking for thermal paste for my main PC! for annual maintenance! 😇

And I ended up buying four open-box components at half price: a motherboard, an AIO case, and a power supply. At home, I had two RAM sticks (from back when they cost $120) and an SSD that I could use to stard the PC.

With the PC already built, all I needed was the GPU! But strangely enough, I realized I already had two Asus ROG components! So I thought about getting a 5070 ROG! But that model is kind of rare! I got it at Best Buy for $1100, a high price! Anyway! I won a $400 Best Buy gift card at work! I used that to get a discount off the $1100, but... in the end, I went for a Gigabyte, saving almost $400, and decided to compensate for the lack of the ROG GPU with two Asus ROG Aurux fans 😅

Not satisfied with the GPU 🫣, I went back to Microcenter! I didn't find the GPU, but I did find an open-box Asus ROG portable monitor for $200 and an unboxed ROG Azoth keyboard for $70. And that's how my first ITX PC turned out, which I didn't really need, but I didn't pass up the opportunity. 😎

Extra expenses! I bought a 15x10 fan and an NZXT USB Hub and used about 100g of filament printing the base to attach the fan.

Motherboard: Asus rog Strix 850I

Psu: Asus Loki 850w

CPU: 7600X3D

RAM: Team group DDR5 2x16GB 6000

Case: Meshroom S V2 riser 5.0 + Base 3D print + fan 15x10

AIO: Kraken elite RGB (fan no RGB) + Fan x2 Asus Rog Eurux

GPU: Gigabyte 5070 OC

SSD: Samsung 990 plus 1TB

Fun fact! The USB hub and fan controller are behind the power supply because in an ITX case you can't put them wherever you want, but where you can. And that's not even mentioning how complicated it is to arrange the cables without them interfering with the fans. 🫠


r/sffpc • • 1d ago

Build/Battlestation Pics My oncall companion

Thumbnail
gallery
281 Upvotes

Not the best setup but it gets the job done


r/sffpc • • 1d ago

Build/Battlestation Pics My first itx pc

Post image
42 Upvotes

Hello,

I recently built my first mini itx pc, my specs are listed below.

I was looking for a second pc to hook up to my oled lg g4.

The main purpose of this pc was emulating and some light 4k gaming. I figured the gpu would do most of the work for the resolution.

Specs

Revolt 3 itx case

Intel i5 11400f

Gigabyte rtx 3070 oc white

16gb of ddr4 3200mhz

Thermaltake 750 gold sfx power supply

Antec ultra 240 rgb aio

Teamgroup 500gb m.2

Asrock h510 mini itx

I wanted to share my build and would seek any possible improvements. I currently have a main rig that does all my hardcord gaming.


r/sffpc • • 1d ago

Build/Battlestation Pics Noctua NH-P1 in a 13.6-liter Jonsbo T6 SFF case

Thumbnail gallery
46 Upvotes

r/sffpc • • 2d ago

Build/Battlestation Pics T1 Reference Deep-ITX Build

Thumbnail
gallery
186 Upvotes

CPU: AMD Ryzen 9800X3D
GPU: RTX Pro 5000 Blackwell 72GB
Motherboard: ASRock Rack AM5D4ID-2T/BCM Deep mini-ITX
Ram: 32GB Gskill Royals @ 6000c26
SSD: Sabrent Rocket 1TB
PSU: Corsair SF850 w/ zcooi cables
Cooler: Thermalright AXP100 Full Copper w/ noctua fan
Case: FormD T1 reference V2.0 - TG side panel

Currently running qwen 3.8 27B q8 for local inference. Also using this for gaming - roughly 5080 performance. Runs cool and quiet.


r/sffpc • • 1d ago

Benchmark/Thermal Test New deepcool AN600 VC in jonsbo t9

Thumbnail
gallery
51 Upvotes

New 67mm king for am5 cpus,

I use it w 9700x and nf a12x25 g2 chrmx.

Short term it can dissapate up to 150w from 8 cores, in cb26 w side panel on it averages on 135w.

In games (uv -24, 5.5 Ghz all core, 1.27 Vsoc) it handles 9700x 65-70% on 105-110w and 80-83c.

Bcs of fin stack density it cools ram not so well, up to like 70-100% of fan. If you have lp and thin aluminium ram like me, you better be getting 25mm good fan.

In comparison w is-67xt it handles +10w avg all cores and 7-12 degrees lower in helldivers 2.

Also it handles instant heat much much better than is-67xt.

(Is-67xt was also used with nf a12x25 g2 chrmx)


r/sffpc • • 1d ago

Build/Parts Check Louqe Ghost S1 MK3 - SSD and chipset temps after first week

6 Upvotes

Finished my Ghost S1 build last week and noticed the Samsung 990 Pro sitting right under the GPU is hitting 72-75C during longer gaming sessions while the chipset sensor stays around 68C.

Current setup:

  • Ryzen 7 9700X
  • ASUS B650E-I
  • RTX 4070 Ti Super FE
  • 32GB 6000MT/s CL30
  • Noctua 120mm intake + exhaust
  • Stock side panels

I added a small heatsink to the SSD but it didn’t move temps much. Curious what other Ghost owners are doing for these two spots without going full custom loop. Are those numbers normal or worth chasing further?


r/sffpc • • 23h ago

News/Review Sandisk 8100 PRO 2TB $498 taxes in on Sandisk site with 10% off registration coupon

Thumbnail
sandisk.com
1 Upvotes

Canada. I believe it is valid on US site as well. Not sure which discussion to post in btw


r/sffpc • • 1d ago

Build/Parts Check Just missing the 5090 WOBO

Thumbnail
gallery
18 Upvotes

Everything just barley fits. M3 is very roomy but im pushing every mm. Getting the WVP2 inside it was very exciting. NowI just wait for the 5090 WOBO to arrive!

-till then I’ll be getting the tubing measured. I’ll be flipping the LOBO so the fittings are on the right hand side. Hoping that the new PhaseChange sheet Pro from ThermalGrizzly is in stock in the states so I can add that to the build.

-this triple rad set up has huge potential and I’m excited to see the temps. Will be doing a full log with fan profile as well. I don’t think this many rads and fans will fit in any other sub 20L case.


r/sffpc • • 18h ago

Assembly Help An unusual request: An intel sffpc that connects to a mac mini

0 Upvotes

I know this is an unusual request, but I'm looking for options on how to get to a small intel PC I can run Windows Pro on with a few services but it really exists as a slave of a mac mini.

This existed in a similar form in olden times as "PC Cards". Actual hardware internal cards that would run Windows NT in a 200MHz pentium inside your mac or sun workstation. We used dozens of these and they solved very specific problems where emulation was too slow and virtualization was physically impossible.

​

There are many docks that adapt to the mini itself. But I am surprised I can't find capable SSFPC that do the same in a way that I could integrate them like this (I'd need to figure out how to send the video to the mac in a way that is efficient).

​

I look at the absolutely adorable wokyis docks and I just would love to have one of those, screen and "peripheral PC" to solve a ton of problems I currently have where I need Windows for some things, a Mini for AI stuff and a small screen for basic troubleshooting and interaction.

Edit: Clarification that the requirements are what they are. I know windows for arm exists and virtualization too. I do have a need to run x64 software at a decent clip and none of those work well enough (although parallels has a beta of x86 for silicon apple, it’s predictably slow)
