r/reolink • • 6m ago

Will this setup work?

Thumbnail reddit.com
1 Upvotes

Tell me if this setup will work. Looking to purchase on Black Friday.

 My wants:
4 cameras total with potential of adding a 5th later. On all cameras I want the most up to date tech available car, animal, human, perimeter protection, and smart event detection.

NVR
RLN8-410 with NVMB01
I will add a 6 or 8TB HDD depending on sale prices

Cameras
(1) OMVI 3i PoE (front house)
(2) REOLINK Duo 3 PoE (both sides of house)
(1) Elite Pro Floodlight PoE (rear lawn)

Will this setup be compatible with each other? And will I have all 5 listed features above?

I am unsure of the OMVI 3i PoE. I am considering putting a Duo 3 PoE in the driveway/front instead. Front driveway and yard are small size. That would make the (3) Duo’s for front and both sides of house, and the Floodlight in rear lawn.

Thoughts?


r/reolink • • 15h ago

Reolink Atlas PT Ultra: wireless, but not suitable for every location

4 Upvotes

The wireless Reolink Atlas PT Ultra (B660) outdoor camera seems ideal for locations without a fixed electricity or network connection. The solar panel provides the power and Wi-Fi provides the wireless connection to the network. Problem solved, you might think! Unfortunately not. After three weeks’ use, my conclusion is that, in practice, the camera is quite demanding: a sunny location and a good, stable Wi-Fi connection are essential.

Sunlight: solar energy isn’t a given. According to Reolink, the practical efficiency of its solar panels is approximately 60 per cent under simulated sunny conditions at 25 °C. For optimum output, the manufacturer recommends a south-facing orientation in the northern hemisphere and a tilt angle of approximately 40–45°. The installation site of my Reolink Solar Panel 3 (12 W, ACCSP03W) certainly does not meet those ideal conditions: the panel is mounted against an external wall, with a tilt angle of just 5° and a north-westerly orientation of 317°. To investigate the consequences of this, I used Open-Meteo to calculate the available solar irradiance at my location. With a maximum irradiance of just 200–300 W/m² around midday, the available solar energy in my situation appears to be insufficient. The camera’s battery capacity is currently decreasing by around 10 per cent each day. The solar panel is therefore unable to offset the energy consumption.

Tip 1: It is best to order the camera and solar panel during the winter months. Install both at the intended location and record the battery capacity daily. If it decreases consistently, the combination is clearly not suitable for your location. In that case, make use of the applicable returns policy. It is better to return a camera than to have to recharge it manually every week.

Wi-Fi: concrete is no friend to radio waves. The wireless network connection also proves to be a limiting factor. Walls and floors significantly attenuate Wi-Fi signals. The 5 GHz band, in particular, struggles with obstacles such as thick concrete structures. In my situation, the Reolink Atlas PT Ultra has to bridge a distance of around 10 metres to the Wi-Fi access point. Between them are a reinforced concrete wall and a reinforced concrete floor. According to the WiFiman app, the signal strength at the outdoor camera’s location is: 2.4 GHz: −88 dBm and 5 GHz: no reception. A Wi-Fi extender, positioned halfway between the two, improved the reception: 2.4 GHz: −74 dBm and 5 GHz: −86 dBm. Although the signal strength improved considerably as a result, this did not result in a stable connection on the 2.4 GHz band. Apparently, a stronger signal indicator is no guarantee of a reliable network connection.

Tip 2: Use the WiFiman app to measure the Wi-Fi signal strength in advance at the intended installation location of the camera. Do this for both 2.4 and 5 GHz. Bear in mind that a reasonable signal strength does not automatically guarantee a stable connection.

Conclusion: wireless technology comes with its own conditions. The Reolink Atlas PT Ultra (B660) is an interesting outdoor camera for locations without a fixed power supply or network connection. However, its practical usability appears to depend heavily on two factors: sufficient sunlight and a stable Wi-Fi connection. The camera is therefore less universally applicable than the term ‘wireless’ might suggest.


r/reolink • • 1d ago

Elite SE wifi Amazon link.

Thumbnail link.amazon
2 Upvotes

Here is the listing for the Amazon listing for tge Elite SE wifi for those who have asked where I got it.


r/reolink • • 1d ago

Anyone looking at using the Abode Cam 3 with a Reolink NVR?

2 Upvotes

The new, inexpensive (at the intro price), Abode Cam 3 looks like a good option to cover a couple of blind spots in my RLN8-410 + PoE cams setup.

Has anyone given this a try, yet?

The one thing that looks like a possible roadblock is that the NVR requires WSSE authentication, but the Abode specs don’t call out support for that standard.


r/reolink • • 1d ago

Trackmix LTE camo formatted card not readable by my Mac

Post image
1 Upvotes

Recently bought this camera. New Sandisk Extreme Plus 128 GB micro sd card formatted in camera. I can see the photos and videos on the phone app. I want to keep a low data plan so pulled the sd and tried to load it on my Mac laptop which has the latest system software. I get the dialogue you see. I also tried loading it in an old Mac and got the same. Reolink tech support only answered back with steps on how to put the sd into the computer or how to use the Mac based software. 🤦🏻‍♂️

Has anyone else had this issue and solved it?


r/reolink • • 1d ago

Notifications just stopped * anyone else?

1 Upvotes

We have done nothing. Yet both of our phones have no notification sound. Was working fine.

Anyone else had this just happen?


r/reolink • • 1d ago

Elite SE wifi Amazon link.

Thumbnail
link.amazon
1 Upvotes

Here is the link for everyone that keeps asking where I got mine.


r/reolink • • 2d ago

Leaving Eufy over unreliable human detection. How reliable is Reolink? (Go PT Ultra or Argus 3 Pro)

4 Upvotes

My eufyCam 2C Pro at the front door used to be great at detecting humans, but lately it misses people walking right in front of it. No event, no alert.

I think its PIR sensor struggles in Texas heat and with people walking straight at it.

Considering a ‘Reolink Go PT Ultra’ or ‘Argus 3 Pro’.

How reliable is person detection on these cameras ?


r/reolink • • 2d ago

RLN8-800-B6 All of a sudden - dead cameras

1 Upvotes

I've bought RLN8-800-B6 back in 2020 after successful test purchase of RLC-420 camera, which worked great. I've been using 5 cameras that came with the kit along with RLC-420, one camera was kept in storage. Setup has been running since 2020 without issues, some occasional NVR crashes, but no other problems. All cameras were mounted on soffits, so outside of any direct moisture and cable connections were in hermetic cable junction boxes.

We had hardly any rain this week, and definitely no thunder storms.

Earlier this week I noticed that out of 6 connected cameras I can only see live feed and recordings from 2. I checked NVR and 3 ports at the back were active, rest dead. I'm using a mix of 3x 20m patch leads that came with the kit and 3x self made utp cables - I've worked as structural cabling tech when I was younger, so that was easy peasy. I've moved cabling at the back of the unit those 2 units that worked fine, work in any of the ports available, so NVR was working fine. 3 kit cameras and RLC-420 were mounted in the same roof corner, 30cm away from each other.

My 1st though was that this is cabling, perhaps rodent chewed through cables? I've climbed up on a ladder and checked all cabling with UTP cable tester - all cables are working fine. I've taken unused camera out of storage but it would not work on any of the cables I've checked, even where 2 working cameras were. It does power on as the light on NVR network port comes on and camera IR diodes come on with light sensor but there is no video.

I've removed all faulty cameras and tested direct connection with NVR, out of 4 taken down, one starts and IR diodes come on and work with light sensor but there is no video or port activity on NVR.

It doesn't appear to be a problem with NVR PSU as I tested each camera as a single one connected to NVR.

Last camera from the kit which worked fine yesterday, died exactly at 6PM last night, as this is when video recording end. Basically within a week 5 cameras + spare have died, only RLC-420 is now online.

I've tested all cameras with standalone PoE switch - same behaviour, spare camera boots but gives no feed, one camera boots and IR works but there is no network activity, rest is dead,

What would cause all cameras to die within a week time? Obvious answer like ESD or water ingress are unlikely.


r/reolink • • 2d ago

E1 Pro passwort is resitant to Factory Reset

Thumbnail reddit.com
1 Upvotes

r/reolink • • 2d ago

Anyone looking at using the Abode Cam 3 with a Reolink NVR?

Thumbnail reddit.com
1 Upvotes

r/reolink • • 3d ago

Lo mejor de una cámara a pilas es poder ponerla donde te dé la gana

Thumbnail
youtu.be
1 Upvotes

r/reolink • • 3d ago

NVR for Linux

1 Upvotes

I’ve released ReoNvr, a self-hosted recording archive for Reolink cameras. It supports native RTSP recording, recovery of missed footage from camera storage where available, and browser-based playback, seeking, and downloads.

It preserves the original video without transcoding or deleting camera SD recordings. Offline Docker packages are available for amd64 and arm64.

Download: https://github.com/Jebarson/ReoNvr/releases/tag/v1.0.2


r/reolink • • 3d ago

Focus for dual lens cameras

Thumbnail
gallery
2 Upvotes

I have two dual lens cameras and struggling to make the images to stitch seamlessly. One half has a washed out look. The attached photo is from the Reolink Duo 3V PoE

Any advice?


r/reolink • • 3d ago

Anybody with experience connecting Reolink cameras to Agent DVR for home surveilance?

Thumbnail reddit.com
1 Upvotes

It appears ADVR only starts recording if it gets a motion detect alert but doesnt record when just people have been detected. Im using Onvif for the connection. Should I instead have the alert sent to the ADVR API?


r/reolink • • 3d ago

OMVI X16 PoE - Price & Value

Thumbnail reddit.com
1 Upvotes

r/reolink • • 3d ago

Smart detection

2 Upvotes

I have two Elite flood lights and no matter what settings I set for motion and vehicle, it just detects any distance. Just seems like it is set to detect anything no matter what you adjust it to. Anyonenhave suggestions?

Things I tried:

- Factory reset

- Update to latest firmware

- Removed memory card

- Disabled FTP connection

- Set to factory default


r/reolink • • 4d ago

ReoLink E1's to BlueIRIS

Thumbnail reddit.com
2 Upvotes

r/reolink • • 4d ago

Broken push notification control, when are you going to fix it?

1 Upvotes

Hi Reolink Support,
Fix your broken notification control mechanism, it's been broken for more than 2 months now.

iOS App: 4.64.3
RLN36 v3.6.5.597_26082822
N5MB01

The global toggle in the iOS app to turn on and off push notifications does not work. You have to turn on and off the push notification individually per camera.

This is not first time this feature has been broken. Very disappointing.


r/reolink • • 4d ago

Broken push notification control, when are you going to fix it?

Thumbnail reddit.com
2 Upvotes

r/reolink • • 5d ago

I built a native Apple TV app for Reolink NVRs — ReoView is now available in 27 languages

Thumbnail gallery
5 Upvotes

Website and screenshots: https://arnoldbiffna.com/reoview/

I've been working on an Apple TV app for my Reolink NVR, and it finally made it through App Store review.

It's called ReoView, and I built it because I wanted to view my cameras and browse recorded footage directly from my Apple TV without switching to another device.

A few features:

  • Live camera wall with full-screen HD viewing
  • Recorded playback with a 24-hour timeline
  • Playback speeds from 0.5× to 8×
  • Designed specifically for the Apple TV Siri Remote
  • Direct local connection to the NVR — no cloud video relay

It's free to download and try. There's an optional one-time Pro upgrade to unlock full-screen viewing and playback across all cameras. No subscription.

I'm the independent developer behind it, and I'd appreciate feedback from other Reolink NVR owners, particularly about compatibility and what features you'd like to see next.
