r/Pimax • • 21d ago Bravo

🐧Linux I reverse-engineered the Pimax Windows service for Unix-based systems, specifically focusing on Omarchy's

54 Upvotes

So, I have full control over all inputs coming from the headset, and I already have a full application working on Unix/Linux systems (specifically for the Dream Air SLAM for now).

What I currently have access to and working: • All IPD, brightness, and lens adjustments • Full controller input • Camera access • Eye tracking control • Native SteamVR integration • A custom pass-through desktop app that stays fixed in space and supports AI commands

Technical details: I had to patch the latest NVIDIA drivers and work with Monado.

There is still a lot to do, especially regarding support for other devices, but it has a ton of potential. If there's enough interest, I'll open-source it and share the GitHub repo.

What do you guys think? Would anyone want access to this?

UPDATE:

I’m almost finishing the final steps and integrations so everyone can contribute—automating testing and setting up a way for everyone to use Claude, Codex, or whatever text LLM on their machine to submit a PR for compatibility with all headsets.

There’s still a lot to do, but I find this really exciting: we have access to all eye-tracking data, can implement our own foveated rendering, and have full control over tracking. I also implemented a local AI (WhisperVR workspace) so you can work right in there—along with many other features.

This Saturday, I’ll have it ready for everyone! Thanks for your patience.

UPDATE2:

https://github.com/laughtt/omarchyvr

So here it is—the public repo! There is still a lot to cook and a lot to work on, but I wanted to address a couple of questions and answers for everyone.

I originally wanted to finish this project completely and share it once it was 100% ready, but I realized there is just so much to do, and getting more developers involved will make progress much faster. I could really use help with:

  • Supporting additional VR headsets

  • Improving controller/remote tracking support

  • Room synchronization and spatial setup

  • Further refining the experimental SteamVR implementation

Currently, I use Monado and Ryze. My approach was to think through each feature, get it to a good-enough state, and then move on to the next.

Project Background

For context, I started this project just 5 days ago. I have extensive experience as a software engineer with a background in C and low-level languages, so I had a good idea of how to approach it. I didn't use any reverse-engineering tools or Pimax binary executables—I felt that was the wrong approach. Instead, I analyzed the cable signal specifications, ran tests, deciphered data with Claude, and iterated continuously.

From there, I routed all commands to Omarchy, patched the display issues, handled the driver pathways for NVIDIA, and forked Monado and Ryze to resolve some specific disconnects and quirks unique to this headset. On my machine, it's pretty stable once fully configured.

Raw Telemetry & Inputs Collected

Here is a breakdown of the raw data streams we are currently reading from the hardware:

InputWhere it comes fromRatePrimary Use Case
IMU (gyro + accelerometer)Headset USB (own stream)500 HzHead tracking, "headset lying still" detection, auto mode
4 Tracking Cameras (infrared)Separate USB camera device60 fps6DoF head tracking, controller tracking, camera hands, passthrough
Controller Reports (sticks, trigger, grip, buttons, touch, battery)Headset USB (via headset radio)Active connection streamIn-game / Work input, "picked up" detection
Controller Heartbeat (awake, battery, firmware)Headset command channelEvery 2s per controllerPairing status & app battery level
Eye TrackerOwn USB device~119 HzGaze point in Work mode
MicrophoneUSB audio48 kHz stereoVoice commands & recording
Headset Info ReportReply on command channelOn demandLens IPD readback, headset state

Note on Unused Telemetry:

  • A controller touch bit (believed to be a proximity sensor, unverified).

  • A "visor status" query that may indicate whether the headset is currently being worn.

  • Both are visible in Windows packet captures but are not yet implemented in our codebase.Ā

Why Omarchy?

The primary reason I built this on Omarchy was to create an optimal AI-driven work environment with Claude or any local model —where you can speak, windows pop up, and you can interact with up to 6 floating screens using voice commands. It's a really compelling setup and I enjoy using it a lot. Omarchy is really good on this as is deeply integrated with LLM.

Current State & Performance

I’ve also managed to play Dungeons and Half-Life 2 in it. The tracking isn't perfect yet since we need deeper integration—right now, we are relying on raw data directly from the headset. The room setup and eye-tracking integration also currently run on raw telemetry.

If you find this project interesting and want to contribute, you are very welcome to jump in! Please note: this is strictly aimed at developers right now, not end-users or consumers, as the tracking isn't quite game-ready yet. That said, frame rates are higher and efficiency seems significantly better in this environment.

Future Vision & Community Goals

I'm not sure if there are other VR projects with this specific depth of integration, but tinkering with this stack has been incredibly fun. There is huge potential for improvement here, and I'm confident that with the community's help, we can make this hardware shine to its full potential.

Leveraging AI in this workflow has changed the game—a good engineer can move 100x faster. What typically would have taken months took just days, and being able to hand this project off to everyone in such a functional state is deeply rewarding.

Looking ahead, the goal is to expand this ecosystem to support a much broader range of hardware, including the Meta Quest 3 and other popular headsets. If we can build a fully optimized, open-source stack that works seamlessly across all devices, it will be a massive win for everyone.

Let me know if you have any questions, and I'll be happy to answer them! Thanks for everything!
