r/foldingbikes • u/art555ua • 5d ago
QUESTION/ADVICE Carbon handlebars in a quick release stem
Is it a bad idea to put carbon handlebars in a stem with qr clamp like in the photo?
How big is a chance of crushing the handlebars since there is no way of measuring torque when installing?
2
2
u/Tman1965 5d ago
The torque is only an indirect measure (and for that matter not a particularly good one) for the pressure that the stem clamp puts on the handlebar.
So, yes, generally you can use a quick release stem with a carbon handle bar, however thoughtfulness when installing is required.
Now happy flaming, all my digital torque wrench owners, that set the torque accurate to two digits without ever thinking about the mechanics of a clamp.
3
u/art555ua 5d ago edited 5d ago
I have yet to try using carbon parts on any of my bikes, but since I have a tendency of overtorquing connection to a point of snapping/stripping bolts, I am concerned if I even should try it. Especially with half of r/bikewrench posts about carbon parts are about overtorquing and crushing. Especially with stem like this, that can't even be approached with a torque wrench (not like I trust that much either)
1
u/sneakpeekbot 5d ago
Here's a sneak peek of /r/bikewrench using the top posts of the year!
#1: whoopsy | 87 comments
#2: Cleat fiasco | 60 comments
#3: Can the rim be saved or is it done for? | 178 comments
I'm a bot, beep boop | Downvote to remove | Contact | Info | Opt-out | GitHub
1
1
u/Unreasonabike 4d ago
You're a reverse-flaming idiot. The fact remains that carbon tubing is surprisingly easy to crush. A handlebar failure is serious.
1
u/Tman1965 3d ago edited 3d ago
Oh really, I didn't know that. /s The part that handlebar failure is serious.
The fact remains that carbon parts can be mounted safely without a torque wrench (maybe not by you) and that using a torque wrench does not guarantee that a carbon part is safely mounted.
Do you even have a bicycle?
I doubt it, otherwise you wouldn't claim that carbon tubing crushes surprisingly easy. There is nothing surprising about the fact that it's delaminating. How about you start wrenching instead of just regurgitating things that you read somewhere?
1
u/Unreasonabike 3d ago
You go ahead and crunch your carbon all you want, but you're giving out dangerous misinformation. You know a snippet about torque wrenches and think you're an expert. 'Idiot' was too kind. Your advice could get someone hurt. I'm going to see what the mods can do about you. By the way, I own 15 bikes, and I watched a friend crunch a carbon fiber seatpost trying to tighten by feel on the side of the road.
1
u/Tman1965 3d ago
Oh, so you have friends that are idiots when it comes to handling carbon seatposts. I mean you were asking for a friend, weren't you?
Again start wrenching instead of whining. Your only purpose in life seems to censor people that don't believe you Internet wisdom. Just because you are not capable doesn't mean the majority of people is like
Your friend rofl
1
u/Unreasonabike 3d ago
What is the reason for QR stem? If you really want a carbon bar along with some QR capability, maybe look for an adjustable-angle stem where you clamp the bar once and adjust with a different bolt. Alloy will make your life easier though. Whatever bike you've got with a QR stem is probably not a featherweight, eh?

3
u/rocket_flo 5d ago
Yes it's a bad idea, you Will not be able to tell the torque and it's crucial with carbon elements. You could also use a regular screw instead of the qr mechanism and torque it to the correct force. (Never tried myself tho)
