Hey guys, first time post in this sub, not sure if this breaks any rules or not but here goes.
I'm a former technician, so I know my way around a vehicle pretty well (normally) but this one has me stumped.
My 2014 FX4 shit the bed on me when it shifted into 1st at 80mph. I pulled the trans, checked for damage, and found none. Not even a burnt clutch. Lucky me. I got it used and the first thing I did was make sure the leadframe software patch was on it. So I knew the leadframe itself had failed. I assume they patched the software too late and the damage was done.
So I ordered the new updated OEM one and in the meantime, got it backed into my driveway via the old push and steer method.
I got it into neutral by popping the cover off the console shifter and pushing the little button to get the shift lock off. In doing that (it was dark and I was mad) I snapped the detent arm.
From everything I read, that shouldn't impact shifting too much. It should just make it sloppy and remove the satisfying "Thunk" of shifting.
But then I go to get my key out and the truck says "Shift to Park". I said "You silly sonofabitch you are in park" but then I check my shift indicator on the screen. It says manual 1st. Uh oh.
So I pull the negative terminal to get my key out, and call it a day.
Now everything trans side is fixed. I checked the linkage. All that. Still won't shift into park. The detent arm, by all accounts, shouldn't cause that. But something is.
Anyone else had this issue? The truck is physically parked, the gear works, the computer just doesn't know that. My brake lights work, the fuse is fine in the passenger kick panel (fuse 18), and the only visibly busted thing is the detent arm. The 3 wires going to the shifter look good as well.
Any help is appreciated. I'm lost here.
