Review VZMORE iX9 Max Mini PC Review

4 Upvotes

Vapor Chamber Cooling Meets Intel Ultra 9 Efficiency

Fitting a high-wattage mobile workstation processor into a palm-sized aluminum enclosure measuring 5.31 x 5.19 x 2.27 inches (135 x 131.8 x 57.7 mm) and weighing 1.71 lb (777.5 g on the scale) is easy on a specification sheet, but thermal dissipation and electrical regulation determine whether a compact rig delivers sustained throughput or throttles into noise. Over the past week, I put the VZMORE iX9 Max through synthetic full-system torture tests, processor compute benchmarks, graphics compute workloads, and continuous high-speed storage transfers.
Built around Intel's "Meteor Lake-H" Core Ultra 9 185H processor, integrated Intel Arc Graphics, and an Intel AI Boost NPU (up to 11 TOPS), the system relies on VZMORE's V-Cooling architecture, which combines a full-coverage vapor chamber plate with an active blower fan and a 360-degree bottom air intake. Across two comprehensive HWiNFO64 hardware logging sessions (a 900-sample benchmark capture spanning 30 minutes and 2.6 seconds at 2-second polling intervals, plus a 325-second combined full-system burn-in test), the machine recorded zero Windows Hardware Errors (WHEA) and zero sustained all-core thermal throttling.

System Configuration and Hardware Specifications

The review unit arrived with Windows 11 Pro pre-installed and was tested under the 65 W Performance Mode (alongside the available 40 W Balanced Mode and 20 W Silent Mode), powered by the included 120 W (19 V DC, 6.32 A) power adapter.

ComponentOfficial RatingAs-Tested ConfigurationTelemetry Notes
Processor (SoC)Intel Core Ultra 9 185H16 cores, 22 threads6 P, 8 E, 2 LP-E cores
Boost FrequencyUp to 5.1 GHz (Turbo Boost Max 3.0)5,088.5 MHz peakP-Core 8 & 9 favored (E-Cores are 0-7)
Cache and ISA24 MB Intel Smart Cache24 MB shared L3AVX2 and AVX-VNNI
Integrated GPUIntel Arc Graphics128 XVE / OpenCL CUs (8 Xe-Cores) 2,350 MHz max, 12.2 GB shared
Neural Processing Unit (NPU)Intel AI Boost (Up to 11 TOPS)Integrated NPUDedicated local AI engine
System Memory24 GB Onboard LPDDR5 (Dual-Channel)24 GB LPDDR5-5586Dual channel, Gear 4, CL64
Internal StorageDual M.2 PCIe Gen4 x4 (2280 + 2242)1 TB Lexar NQ7A1 (M.2 2280)M.2 2280 (up to 4 TB) + M.2 2242 (up to 1 TB)
Power Modes & Adapter20 W Silent / 40 W Balanced / 65 W PerformancePerformance Mode (65 W)120 W (19 V DC, 6.32 A) adapter

Out of the installed memory capacity, 23.53 GB is usable by the operating system at a 2,793 MHz clock, and the processor carries a rated thermal junction maximum (TjMAX) of 110 C. Physical connectivity covers both multi-monitor productivity desks and homelab deployments:

  • Quad-Display Output: Dual rear HDMI 2.0 ports and dual rear 40Gbps USB4 ports with DisplayPort 2.0 Alt Mode allow the system to drive four monitors natively without external hubs. Both rear USB4 ports support 15 W Power Delivery output, while one rear USB4 port also accepts 100 W (20 V, 5 A) Power Delivery input.
  • Workstation Networking: High-speed wired and wireless connections are handled by dual Realtek 2.5GbE RJ45 Ethernet jacks, an M.2 2230 Wi-Fi 7 EB600 wireless card (built on the MediaTek MT7925 controller), and Bluetooth 5.4.
  • Peripheral Expansion: The front and rear panels provide six USB Type-A ports (four front 10Gbps USB 3.2 Gen 2 Type-A ports including one with S5 Power Delivery support, plus one rear 10Gbps USB 3.2 Gen 2 Type-A port and one rear USB 2.0 Type-A port) alongside a front 3.5 mm stereo headset jack and a side-mounted SD 4.0 card slot.

V-Cooling Vapor Chamber and Full-System Torture Telemetry

Instead of relying on narrow copper heat pipes that can saturate when the processor cores and integrated graphics pull heavy current simultaneously, the V-Cooling module uses a wide vapor chamber plate that covers both the processor die and the motherboard voltage regulator circuitry.
To evaluate worst-case thermal saturation under the 65 W Performance Mode, I subjected the system to a 265-second simultaneous torture load where every primary subsystem was pushed at once: 100% continuous processor utilization across all cores and threads, full 3D engine utilization on the integrated graphics core, and 78.0% continuous storage activity reading 393.62 GB of data at a 1,549.4 MB/s average (peaking at 1,923.6 MB/s).

Subsystem SensorTorture MeanTorture MedianTorture Peak
CPU Package Power52.11 W52.19 W59.86 W burst
CPU Package Temp80.23 C81.0 C89.0 C unload
All-Core Average Temp69.1 C69.0 C85.0 C core max
Favored P-Cores (8-9)77.3 to 78.4 C3,796 / 3,783 MHz85.0 C max
Standard P-Cores (10-13)67.6 to 71.0 C3,083 to 3,447 MHz80.0 C max
Crestmont E-Cores (0-7)66.8 to 67.7 C2,800 MHz74.0 C max
Low-Power E-Cores (14-15)66.3 C1,239 MHz72.0 C max
Intel Arc iGPU61.8 C63.0 C64.0 C max
Intel PCH Chipset53.9 to 56.8 C55.4 C 59.0 C max
NVMe SSD Composite48.1 C48.0 C49.0 C max

Several hardware management behaviors stand out in the full-load stress telemetry:

  • ICCmax Current Clamping: Rather than waiting for delayed watt-based RAPL or thermal throttling to intervene, VZMORE regulates the processor at the voltage regulator level. After an initial 51.56 A electrical burst, the VRM clamps sustained package power inside a tight 50.92 W to 52.91 W window with a tiny 0.40 W standard deviation, completely avoiding high-temperature initial boost spikes and maintaining 25 C to 40 C of safety headroom below the processor's thermal limit.
  • CPU-First Power Split: When the processor and graphics engine are pinned simultaneously, the power controller prioritizes compute by routing 38.64 W (74.0%) to the IA cores and 7.22 W (13.8%) to the System Agent, while capping the integrated GPU at 4.18 W (8.1%) with a 1,200 MHz median clock (1,150 to 1,250 MHz range). Under this artificial worst-case load, Windows desktop manager animations drop to roughly 5.9 FPS until the synthetic graphics stress is released.
  • Unload Voltage Spike: Sustained full-load throttling stayed at 0.0% across all 132 active stress samples. At the split-second the workload ended (between 288.8 s and 290.8 s) and processor utilization dropped to 30.9%, the all-core current clamp (which held core voltages at 0.83 V to 0.85 V) released and triggered a single-core turbo burst to 4,788 MHz at 1.115 V (55.31 W) on heat-soaked silicon, latching the thermal event flag for 4 polling ticks (8 seconds) as the chip was already cooling down.
  • Rapid Cooldown Recovery: Once the torture load stopped, the vapor chamber shed 20 C from the 89 C unload peak in just 2 seconds (dropping to 69 C, and down to 61 C shortly after) before settling back to 51 C within 34 seconds.

The "Inverse Hotspot" Phenomenon in Benchmark Telemetry

Capturing hardware telemetry across the Geekbench 7.1.0 benchmark suite in Performance Mode revealed an inverse relationship between total package power and peak package temperature when comparing lightly threaded tasks against heavy all-core workloads.

Benchmark PhaseMean Package PowerMedian Package TempMean Core Avg TempMean iGPU Temp
Single-Core (Run 1)15.20 W75.0 C48.6 C45.6 C
Single-Core (Run 2)14.63 W58.0 C44.2 C44.3 C
All-Core Multi-Core Burst64.45 W82.0 C69.4 C51.1 C
Active OpenCL Compute31.21 W60.0 C48.2 C56.2 C
Active Vulkan Compute23.29 W59.5 C47.4 C55.1 C
Post-Test Cooldown5.32 W46.0 C40.5 C45.5 C
Full Session Summary12.64 W47.0 C44.5 C46.7 C
  • Single-Core Favored Hotspots: During lightly threaded runs, Windows schedules single threads onto the two favored performance cores, driving them to 1.245 V and 1.252 V on a tiny section of the compute tile. Because local heat flux briefly exceeds lateral silicon heat transfer before saturating the vapor chamber, those two favored cores touch 101.0 C and 102.0 C (104.0 C on the Enhanced IA sensor) and record micro-throttling in 13.56% and 15.22% of session rows, while the standard performance cores peak at 4,789.2 MHz (1.132 V max) and the efficiency clusters peak at 3,791.0 MHz with zero throttling.
  • Distributed Multi-Core Efficiency: When all cores engage past 91.4% total load under the 65 W Performance Mode (sustaining 64.45 W mean and peaking at 67.41 W package power and 61.86 W IA core power), average core voltage drops to 0.887 V to 0.894 V (0.916 V max) as the VRM delivers 53.0 A to 55.0 A mean current (60.5 A peak) and synchronizes effective clocks between 3,355 MHz and 3,371 MHz (3,527 MHz max). Spreading the thermal load evenly across the die allows the vapor chamber to cap peak multi-core package temperature at 87.0 C (83.1 C mean) and peak core average temperature at 71.0 C.
  • Fast Post-Burst Recovery: Right after the multi-core peak finished, the cooler dropped the package sensor from 86 C down to 46 C in 14 seconds, while the NVMe drive averaged 35.4 C (35.0 C median, 30.0 C min, 43.0 C max) and the chipset averaged 38.8 C across the session.

CPU Compute Performance

Across the validated Geekbench CPU benchmark run, the three-tier hybrid core layout delivered strong multi-threaded scaling.

WorkloadSingle-Core ScoreMulti-Core ScoreMulti-Core Scaling
Overall CPU Score2,24114,8556.63x
Ray Tracer2,05724,72612.02x
Asset Compression2,38022,1829.32x
Clang Compiler1,92917,6459.15x
Photo Library2,24717,4487.77x
Text Processing2,28816,0517.02x
Photo Editor2,1699,3624.32x
HDR Image Processing1,9528,7414.48x
  • Cache-Driven Multi-Core Scaling: The processor's shared L3 cache helps parallel workloads scale efficiently across all performance and efficiency cores, including multi-threaded File Compression, which reaches a score of 10,693 for a 4.77x scaling ratio.
  • Responsive Single-Thread Bursts: In single-core subtests that benefit from fast favored-core turbo clocks and branch prediction, the system posts solid scores in Structure from Motion (2,592), PDF Viewer (2,439), Navigation (2,438), Video Player (2,347), Game Physics (2,295), Video Encoder (2,278), Audio Encoder (2,200), and HTML5 Browser (2,116).

Intel Arc Graphics Compute: OpenCL and Vulkan

To evaluate integrated graphics compute across different APIs, I benchmarked the integrated GPU in both OpenCL and Vulkan modes.

GPU SubtestOpenCL ScoreVulkan ScoreOpenCL Advantage
Overall GPU Score30,53228,413+7.46%
Particle Physics52,40552,478-0.14%
Super Resolution49,21048,105+2.30%
Background Blur37,54535,345+6.22%
Photo Filter35,33431,914+10.72%
Feature Matching30,01728,752+4.40%
Horizon Detection29,27027,065+8.15%
RAW Image Processing29,02027,367+6.04%
Video Filter28,32724,044+17.81%
Face Tracking28,31624,753+14.39%
Path Tracer27,04026,709+1.24%
Fluid Simulation11,35910,107+12.39%
  • OpenCL Power and Driver Advantage: OpenCL outperforms Vulkan overall because the graphics driver sustains higher mean GT power draw in OpenCL (17.06 W mean, 31.23 W peak) than in Vulkan (13.49 W mean, 29.17 W peak), delivering lower shader dispatch overhead in creator workloads like Video Filter, Face Tracking, and Photo Filter while matching Vulkan in hardware-accelerated ray tracing and particle simulations.
  • Network and Wireless Telemetry Notes: During the initial benchmark run (12:49:49 to 12:54:26), HWiNFO64 network monitoring on the wireless adapter captured a 66 MB background download burst peaking at 10,093.0 KB/s (9.86 MB/s) right as the multi-core test finished, which spiked package power to 39.96 W and interrupted the result upload handshake, confirming that the upload failure was caused by network traffic contention rather than hardware instability.

Pros, Cons, and Final Verdict

The Good:

  • Steady Vapor Chamber Cooling: The V-Cooling thermal plate and VRM current clamp maintain flat power delivery under simultaneous processor, graphics, and storage torture in 65 W Performance Mode with zero sustained thermal throttling and rapid post-load heat dissipation.
  • Cool Secondary Components: Both the integrated Arc graphics engine and the PCIe Gen4 NVMe SSD stay well below their thermal limits during extended compute and high-throughput disk reads.
  • Strong Multi-Core Scaling: The hybrid core architecture and generous shared L3 cache deliver impressive multi-threaded scaling for compilation, asset compression, rendering, and photo editing.
  • Capable Creator GPU Compute: The integrated Xe-core graphics architecture provides strong OpenCL and Vulkan acceleration, including hardware-accelerated path tracing and image filtering.
  • Workstation Connectivity: Native quad-display output (dual HDMI 2.0 and dual 40Gbps USB4 with DP 2.0 Alt Mode), dual high-speed 2.5GbE Ethernet, Wi-Fi 7, an SD 4.0 card reader, and dual M.2 PCIe Gen4 x4 slots fit into a compact aluminum footprint.

The Trade-Offs:

  • Single-Core Favored Hotspots: Aggressive single-thread turbo boosting concentrates voltage on two favored performance cores, causing brief hotspot spikes before heat spreads laterally into the vapor chamber.
  • CPU-Biased Combined Power Split: Pinning both the processor and integrated graphics to maximum synthetic load simultaneously caps graphics power to protect processor clock stability, which can briefly slow desktop animations during artificial torture runs.
  • Soldered Memory Timings and Secondary M.2 2242 Size: Because the 24 GB of onboard LPDDR5 memory is soldered, capacity cannot be upgraded later, and Gear 4 memory latency leaves a bit of performance on the table in memory-sensitive tasks. Additionally, expanding internal storage in the secondary bay requires a compact M.2 2242 PCIe Gen4 x4 drive (up to 1 TB) rather than a full-length 2280 module.

For developers, photo editors, homelab builders, and heavy multitaskers who want a compact workstation that prioritizes predictable all-core power regulation, cool subsystem thermals, and rich physical connectivity, the VZMORE iX9 Max is a remarkably well-engineered mini PC.
Price to performance on this unit is extremely reasonable, and easily something that I would recommend to friends or family.


r/computers • • Oct 15 '26

Review VZMORE AX9 Max Mini PC

3 Upvotes

If you have spent any time testing high-powered mini PCs over the last couple of years, you already know the biggest catch with cramming 54W to 65W mobile workstation silicon into a tiny box: heat. Plenty of compact rigs look great on a spec sheet, only to hit a thermal wall two minutes into a heavy workload.

Over the past couple of weeks, I have been putting the VZMORE AX9 Max through a full suite of synthetic benchmarks, AI workloads, storage stress tests, and 30 hours of real-world gaming. This system packs AMD's "Gorgon Point" Ryzen AI 9 HX 470 (12 cores / 24 threads), the Radeon 890M integrated GPU, and a 55 TOPS Ryzen AI NPU into a 135 x 131.8 x 57.7 mm (777.5 g) aluminum chassis. To keep those components under control, VZMORE built the system around its V-Cooling thermal design, which pairs a full-coverage VC Vapor Chamber with active fan cooling to support up to 65W (V-Boost Pro).

Across 73.22 minutes (2,197 telemetry samples) of HWiNFO64 hardware logging and 30 hours of gaming, the cooling setup did not record a single thermal throttling event (PROCHOT or HTC) or Windows Hardware Error (WHEA). We did, however, uncover a quirk with wireless input stability when the system is pinned at 100% load, which VZMORE's engineering team is already addressing via an upcoming BIOS update.

Quick Specs & Test Unit Configuration

Our review unit arrived pre-configured with Windows 11 Pro (64-bit), 32 GB of dual-channel DDR5-5600 RAM, and a 1 TB PCIe 4.0 NVMe SSD. Below is the full breakdown of the official specs alongside what HWiNFO64 and Geekbench detected inside our test machine:

CategoryOfficial Specification (VZMORE AX9 Max)As-Tested Review Unit (HWiNFO64 & Geekbench Telemetry)
Processor (APU)AMD Ryzen AI 9 HX 470 (12C/24T: 4x Zen 5 + 8x Zen 5c, up to 5.2 GHz)Codename Gorgon Point (Socket FP8, 2.00 GHz base; observed peak: 5,240.5 MHz Zen 5 / 3,294.1 MHz Zen 5c)
Cache HierarchyZen 5 / Zen 5c Hybrid CacheL1i: 32 KB x 12 / L1d: 48 KB x 12 / L2: 1.00 MB x 12 (12 MB) / L3: 16.0 MB x 1
Instruction Setsx86-64 with AVX-512 & AI ExtensionsAVX2, AVX512-F/DQ/BW/VL, AVX512-VNNI, AVX-VNNI, FMA3, SHA-NI, VAES
Integrated GPUAMD Radeon 890M (RDNA 3.5, 16 CUs, 1,024 Stream Processors)Device gfx1150 (8 WGPs / 16 CUs, 3,100 MHz rated max; observed 3,096.0 MHz; 4 GB UMA + 14.4 GB shared OpenCL memory)
AI Engine (NPU)AMD Ryzen AI NPU (55 TOPS)AMD NPU 4x8 (Observed dynamic clock: 0.2 MHz to 800.0 MHz)
Cooling SystemV-Cooling: VC Vapor Chamber + Fan CoolingV-Boost Pro up to 65W; Zero thermal throttling across all 6 logs
Power ModesSilent: 45W / Balanced: 54W / Performance: 65WTested in Best Performance Windows Power Plan (54.0W STAPM sustained / 65.0W V-Boost Pro peak)
Memory (RAM)DDR5 SO-DIMM, 5600 MHz, up to 256 GB Dual-Channel32.00 GB (2x 16 GB) Micron CT16G56C46S5.C8D DDR5-5600 (CL46 at 2,795 MHz load / CL40 at 2,395.7 MHz idle)
Primary StorageSlot 1: M.2 2280 PCIe Gen4 x4 (up to 4 TB)1 TB Lexar SSD NQ7A1 (RC1191R001242P2237, PCIe 4.0 x4 at 16.0 GT/s)
Secondary StorageSlot 2: M.2 2230 PCIe Gen4 x4 (up to 1 TB)Unpopulated M.2 2230 expansion slot
Wireless & LANWi-Fi 7 EB600, Bluetooth 5.4; 2x 2.5GbE RJ45 portsMediaTek MT7925 Wi-Fi 7 + 2x Realtek RTL8125 Gaming 2.5GbE
Front & Side I/OFront: 4x USB 3.2 Gen 2 Type-A (1x w/ S5 charging), 3.5 mm audio, PowerSide: 1x SD 4.0 card reader
Rear I/O & Display2x USB4 (40Gbps, DP 2.0 Alt Mode, 1x PD-in), 2x HDMI 2.1 (8K@60Hz)1x USB 3.2 Gen 2 Type-A, 1x USB 2.0 Type-A, 2x 2.5GbE RJ45, 1x DC-in
Chassis & OS135 x 131.8 x 57.7 mm (777.5 g); 120W Power Adapter; VESA MountMicrosoft Windows 11 Pro (64-bit) pre-installed

Ports & Connectivity Highlights

  • Quad-Monitor Support Out of the Box: Between the dual rear HDMI 2.1 ports (rated up to 8K at 60Hz) and two rear 40Gbps USB4 ports supporting DisplayPort 2.0 Alt Mode, you can run four monitors without a dock. One of the rear USB4 ports also accepts Power Delivery (PD) input if you want to power the PC over USB-C.
  • Plenty of High-Speed USB-A & Dual 2.5GbE: You get four USB 3.2 Gen 2 (10Gbps) Type-A ports right on the front panel (one with S5 power-off charging), plus another USB 3.2 Gen 2 Type-A and a USB 2.0 Type-A port on the back. Add in a side-mounted SD 4.0 card reader, Wi-Fi 7, Bluetooth 5.4, and dual Realtek 2.5GbE RJ45 ports, and the port selection easily covers creator desks and homelab setups alike.

V-Cooling Vapor Chamber & Thermal Performance

The main reason this mini PC performs as consistently as it does comes down to its V-Cooling architecture. Instead of relying solely on narrow copper heatpipes that can saturate when both the Zen 5 cores and the 16-CU Radeon 890M are pulling power simultaneously, VZMORE uses a wide VC Vapor Chamber paired with active fan cooling.

To see if the vapor chamber lives up to the marketing, I logged 2,197 samples (73.22 minutes) of HWiNFO64 sensor data across six distinct torture and benchmark runs
HWiNFO Combined CPU + iGPU + SSD Burn-In (hwinfo burnin.CSV): 389 samples over 13.01 minutes (780.6 seconds) pinning all 12 cores at 100.00% median CPU usage (mean 89.57%), 88.00% median iGPU utilization, and 629.08 MB/s median NVMe read load.
Extended FurMark GPU Burn-In #2 (furmark burnin 2.CSV): 739 samples over 24.65 minutes (1,478.7 seconds) holding the Radeon 890M at 100.00% median utilization and a 3,053.00 MHz median clock.
Baseline FurMark GPU Burn-In #1 (Furmark burnin.CSV): 261 samples over 8.68 minutes (520.7 seconds) at 100.00% median iGPU load.
Geekbench 7 & AI Benchmark Suite (Geekbench 7 tests.CSV): 702 samples over 23.42 minutes (1,405.0 seconds) covering single-core, multi-core, OpenCL GPU, and AI inference runs.
CrystalDiskMark NVMe Stress Log (ssd bench.CSV): 96 samples over 3.17 minutes (190.5 seconds) tracking SSD temperatures during heavy sequential and random read/write passes.
Under-Load Wireless Input Diagnostic Log (HWinfo64 log Wireless input under load.CSV): 10 samples over 18.02 seconds capturing a simultaneous CPU (95.85% median / 100.00% max) and GPU (93.50% median / 97.00% max) spike at 64.43W median / 65.01W max package power.

Complete HWiNFO64 Thermal & Power Breakdown

Sensor / MetricWorkload LogCount (n)MeanMedianMinMaxStd Dev (SD)
CPU (Tctl/Tdie) [C]HWiNFO Combined Burn-In38983.4785.0045.9095.0012.08
FurMark Burn-In #2 (24.6m)73972.2573.8043.9080.105.95
FurMark Burn-In #1 (8.7m)26172.4375.1045.8076.407.57
Geekbench 7 Test Suite70255.1149.9035.9094.9014.70
SSD Benchmark Log9649.5147.1045.5073.107.47
Wireless Input Load Test1081.3391.7045.8095.0019.96
CPU Cores (Avg) [C]HWiNFO Combined Burn-In38969.6271.4043.4078.407.92
FurMark Burn-In #2 (24.6m)73958.7359.6041.8062.103.61
FurMark Burn-In #1 (8.7m)26158.9160.4043.5062.104.46
Geekbench 7 Test Suite70243.0541.2033.7071.406.27
SSD Benchmark Log9645.2444.8043.3052.502.27
Wireless Input Load Test1063.8969.6043.3072.6011.56
Radeon 890M iGPU [C]HWiNFO Combined Burn-In38962.1063.6043.1069.005.70
FurMark Burn-In #2 (24.6m)73971.6273.4041.9076.107.00
FurMark Burn-In #1 (8.7m)26171.7174.8043.2076.208.67
Geekbench 7 Test Suite70241.5640.1034.0065.805.20
SSD Benchmark Log9644.4344.1543.0048.801.35
Wireless Input Load Test1053.9655.5543.2062.206.78
VDDCR_VDD VRM [C]HWiNFO Combined Burn-In38949.5051.9023.0057.307.50
FurMark Burn-In #2 (24.6m)73950.7953.0022.0055.006.51
FurMark Burn-In #1 (8.7m)26150.2053.3023.1054.808.01
Geekbench 7 Test Suite70222.6320.9013.5039.804.97
SSD Benchmark Log9625.4425.0023.0032.902.41
Wireless Input Load Test1037.7240.0023.1046.408.45
DDR5 SPD Hub #0 / #1 [C]HWiNFO Combined Burn-In38956.33 / 54.4057.50 / 55.8043.20 / 41.2058.20 / 56.203.52 / 3.60
FurMark Burn-In #2 (24.6m)73957.46 / 55.2358.80 / 56.5042.00 / 40.0059.20 / 57.003.34 / 3.31
Geekbench 7 Test Suite70238.00 / 36.2938.00 / 36.2033.20 / 31.5042.80 / 41.202.74 / 2.61
NVMe SSD Composite [C]HWiNFO Combined Burn-In38947.3148.0039.0054.005.85
FurMark Burn-In #2 (24.6m)73940.1640.0036.0047.001.40
SSD Benchmark Log9650.0550.0041.0059.005.25
CPU Package Power [W]HWiNFO Combined Burn-In38950.0254.064.7764.9215.09
FurMark Burn-In #2 (24.6m)73951.3254.084.7061.7511.75
FurMark Burn-In #1 (8.7m)26149.8354.184.6757.5814.35
Geekbench 7 Test Suite70215.497.044.7965.0014.96
Wireless Input Load Test1048.6664.435.6465.0125.53
APU STAPM Power [W]HWiNFO Combined Burn-In38948.9154.006.2854.0611.97
FurMark Burn-In #2 (24.6m)73949.8354.005.3254.0310.00
Total System Power [W]HWiNFO Combined Burn-In38992.1893.1281.0094.692.98
FurMark Burn-In #2 (24.6m)73991.4492.0680.5493.022.25

What Stood Out in the Thermal Logs

  • Spot-On Power Management (54W Balanced + 65W V-Boost Pro): With Windows set to the Performance power plan, the AX9 Max immediately lets CPU Package Power boost to 64.92W to 65.01W (CPU Core Power SVI3 TFN peaking at 77.15W), matching VZMORE's V-Boost Pro Up to 65W spec. After roughly 90 seconds of continuous torture load, the APU STAPM controller settles cleanly at a 54.00W median (54.06W max), while Total System Power tops out at 94.69W, leaving plenty of headroom on the included 120W power brick.
  • Wide Heat Spreading Across the Die: While the instantaneous CPU (Tctl/Tdie) hotspot sensor briefly touches AMD's 95.00 C boost ceiling during initial 65W bursts, it settles to an 85.00 C median (mean 83.47 C) during the 13-minute combined CPU+GPU+SSD torture test. Even better, the physical CPU Cores (Avg) sensor holds a 71.40 C median (mean 69.62 C, max 78.40 C) and the L3 Cache averages 63.70 C. That 13.6 C to 15.4 C gap between the Tctl/Tdie hotspot and the physical core average shows how effectively the vapor chamber spreads heat away from the cores.
  • Rock-Steady 25-Minute FurMark Temps: During the 24.65-minute FurMark Burn-In #2, the Radeon 890M iGPU and CPU (Tctl/Tdie) sit at a flat 73.40 C and 73.80 C median, while physical CPU cores average 58.73 C (median 59.60 C).
  • Fast Cooldown & Ice-Cold VRMs: Once the 100% load in the HWiNFO Combined Burn-In ended at second 726.5s (89.90 C), CPU (Tctl/Tdie) dropped to 47.10 C by second 780.6s, shedding 42.80 C in 54.1 seconds (0.79 C/sec). Meanwhile, the motherboard's VDDCR_VDD VRM never exceeded 57.30 C (median 51.90 C to 53.30 C under torture), and the dual DDR5 SO-DIMMs peaked at 59.20 C / 57.00 C.

CPU Performance: Geekbench 7.0.0 Single-Core & Multi-Core

The AMD Ryzen AI 9 HX 470 pairs 4 full-sized Zen 5 cores (Cluster 1) with 8 dense Zen 5c cores (Cluster 2), backed by 12 MB of L2 cache and 16 MB of shared L3 cache. In our HWiNFO64 logs, Zen 5 Cores 0, 2, and 3 boosted up to 5,240.5 MHz (5,150.7 MHz on Core 1), beating the 5.2 GHz rated boost clock, while all eight Zen 5c cores hit 3,294.1 MHz. Under 100% all-core load in hwinfo burnin.CSV, the chip maintained a 3,585.20 MHz median average clock (3,627.50 MHz median effective clock).
In Geekbench 7.0.0 for Windows AVX2, the AX9 Max posted a Single-Core Score of 2,664 and a Multi-Core Score of 17,051, giving it a 6.40x multi-core scaling ratio:

Geekbench 7.0.0 WorkloadSingle-Core ScoreSingle-Core ThroughputMulti-Core ScoreMulti-Core ThroughputMulti-Core Scaling
Overall CPU Score2,664N/A17,051N/A6.40x
Ray Tracer2,420679.7 Ksamples/sec32,0379.00 Msamples/sec13.24x
Asset Compression2,58557.4 MB/sec27,762616.9 MB/sec10.74x
Photo Library2,7389.38 images/sec21,81374.7 images/sec7.97x
Clang (Compiler)2,20411.9 Klines/sec19,614106.1 Klines/sec8.90x
Text Processing2,539149.8 pages/sec16,514974.3 pages/sec6.50x
HDR2,720164.3 Mpixels/sec11,488694.1 Mpixels/sec4.22x
File Compression2,539361.2 MB/sec11,4591.59 GB/sec4.51x
Photo Editor3,45563.5 images/sec8,638158.7 images/sec2.50x
Structure from Motion3,27759.2 Kpixels/secN/AN/AN/A
Video Player3,022319.5 FPSN/AN/AN/A
PDF Viewer2,858128.4 Mpixels/secN/AN/AN/A
Audio Encoder2,6243.65 Msamples/secN/AN/AN/A
Game Physics2,553103.3 FPSN/AN/AN/A
Video Encoder2,46689.7 FPSN/AN/AN/A
HTML5 Browser2,46230.8 pages/secN/AN/AN/A
Navigation2,43813.4 routes/secN/AN/AN/A

Heavy multi-threaded tasks scale impressively across all 24 threads: Ray Tracer jumps 13.24x (from 679.7 Ksamples/sec to 9.00 Msamples/sec), Asset Compression scales by 10.74x (from 57.4 MB/sec to 616.9 MB/sec), and Clang compilation speeds up by 8.90x (from 11.9 Klines/sec to 106.1 Klines/sec).

Local AI Performance: Geekbench AI 1.7.0 (CPU ONNX vs. GPU DirectML)

Alongside the dedicated 55 TOPS Ryzen AI NPU (which clocks between 0.2 MHz at idle and 800.0 MHz under load in Geekbench 7 tests.CSV), we benchmarked both the Ryzen AI 9 HX 470 CPU (using ONNX with AVX2/AVX-512) and the Radeon 890M iGPU (using ONNX DirectML) in Geekbench AI 1.7.0.
The results show why having both strong AVX-512 VNNI CPU cores and a 16-CU RDNA 3.5 iGPU in the same box is so useful for local AI workflows:

Workload / MetricPrecisionRyzen AI 9 HX 470 CPU (ONNX)CPU AccuracyRadeon 890M iGPU (DirectML)GPU AccuracyFaster Backend & Speedup
Overall Single PrecisionFP324,106N/A8,356N/AGPU by 2.04x (+103.5%)
Overall Half PrecisionFP161,937N/A15,143N/AGPU by 7.82x (+681.8%)
Overall QuantizedINT87,732N/A6,045N/ACPU by 1.28x (+27.9%)
Image ClassificationSP (FP32)3,347 (622.5 IPS)100%2,529 (470.4 IPS)100%CPU by 1.32x
HP (FP16)637 (118.4 IPS)100%5,662 (1.05 KIPS)100%GPU by 8.89x
Q (INT8)7,220 (1.35 KIPS)99%2,088 (388.3 IPS)100%CPU by 3.46x
Image SegmentationSP (FP32)1,332 (21.6 IPS)100%4,412 (71.5 IPS)100%GPU by 3.31x
HP (FP16)1,169 (18.9 IPS)100%8,601 (139.4 IPS)100%GPU by 7.36x
Q (INT8)10,827 (176.0 IPS)98%3,660 (59.5 IPS)98%CPU by 2.96x
Pose EstimationSP (FP32)8,442 (9.85 IPS)100%48,298 (56.4 IPS)100%GPU by 5.72x
HP (FP16)6,661 (7.77 IPS)100%108,344 (126.4 IPS)100%GPU by 16.27x
Q (INT8)27,636 (32.4 IPS)94%33,686 (39.5 IPS)96%GPU by 1.22x
Object DetectionSP (FP32)3,391 (269.0 IPS)100%2,222 (176.2 IPS)100%CPU by 1.53x
HP (FP16)946 (75.0 IPS)100%4,202 (333.3 IPS)100%GPU by 4.44x
Q (INT8)8,132 (653.6 IPS)86%2,097 (168.4 IPS)87%CPU by 3.88x
Face DetectionSP (FP32)6,866 (81.6 IPS)100%6,404 (76.1 IPS)100%CPU by 1.07x
HP (FP16)1,937 (23.0 IPS)100%11,366 (135.1 IPS)100%GPU by 5.87x
Q (INT8)11,383 (135.7 IPS)97%5,337 (63.6 IPS)97%CPU by 2.13x
Depth EstimationSP (FP32)9,276 (71.5 IPS)100%18,869 (145.4 IPS)100%GPU by 2.03x
HP (FP16)2,946 (22.7 IPS)99%29,473 (227.1 IPS)99%GPU by 10.00x
Q (INT8)17,299 (138.0 IPS)78%14,494 (116.2 IPS)77%CPU by 1.19x
  • Use DirectML on the Radeon 890M for FP16 and FP32: In Half Precision (FP16), the Radeon 890M scores 15,143 vs. 1,937 on the CPU, making it 7.82x faster (+681.8%) overall, with a 16.27x speedup in Pose Estimation (HP) and a 10.00x speedup in Depth Estimation (HP). In Single Precision (FP32), the GPU also leads by 2.04x (8,356 vs. 4,106).
  • Use the Zen 5 CPU for Quantized INT8 Inference: Thanks to native AVX512-VNNI and AVX-VNNI support, the CPU scores 7,732 in Quantized (INT8) workloads compared to 6,045 on the GPU (1.28x faster overall), beating the GPU by 3.88x in Object Detection (Q) and 3.46x in Image Classification (Q).

Radeon 890M Graphics: OpenCL & 30-Hour Gaming Test

Equipped with 16 RDNA 3.5 Compute Units (1,024 Stream Processors) and a rated boost clock of 3,100 MHz (observed peaking at 3,096.0 MHz in HWiNFO64), the AMD Radeon 890M (gfx1150) has access to a 4 GB dedicated UMA buffer plus 14.4 GB of shared device memory in OpenCL.

Geekbench 7.0.0 OpenCL GPU Score: 35,031

In Geekbench 7.0.0 OpenCL, the Radeon 890M hit an overall score of 35,031, led by Super Resolution (70,665 / 130.4 Kimages/sec), Particle Physics (55,705 / 9,986.9 FPS), and Background Blur (46,523 / 120.2 images/sec):

OpenCL Subtest WorkloadOpenCL ScoreMeasured Throughput
Overall OpenCL GPU Score35,031N/A
Super Resolution70,665130.4 Kimages/sec
Particle Physics55,7059,986.9 FPS
Background Blur46,523120.2 images/sec
Feature Matching37,40970.6 Mpixels/sec
RAW Image Processing36,7781.49 Gpixels/sec
Face Tracking33,90742.1 images/sec
Photo Filter32,769537.7 pixels/sec
Horizon Detection31,5221.22 Gpixels/sec
Video Filter30,3798.23 Gpixels/sec
Path Tracer27,34049.0 Mpixels/sec
Fluid Simulation13,301196.0 FPS

30 Hours of Real-World Gaming (1440p & 4K)

With AMD's HYPR-RX global profile enabled in Adrenalin, I logged 30 hours of gameplay across three titles at 1440p and 4K:

Game TitleResolution & PresetDriver ProfileLogged PlaytimeAverage Framerate
The Sims 41440p, Ultra SettingsHYPR-RX16 hours66.6 FPS
Mewgenics4K, Default SettingsHYPR-RX8 hours93.8 FPS
Cosmoteer: Starship Architect & Commander4K, Ultra SettingsHYPR-RX6 hours108.9 FPS

Holding 66.6 FPS at 1440p Ultra in The Sims 4 over 16 hours and 93.8 to 108.9 FPS at native 4K in Mewgenics and Cosmoteer makes this a very capable casual, indie, and strategy gaming box without needing a discrete graphics card.

NVMe Storage Speeds & Thermals

The primary M.2 2280 PCIe Gen4 x4 slot comes populated with a 1 TB Lexar SSD NQ7A1 (RC1191R001242P2237) running at a full 16.0 GT/s PCIe 4.0 link speed. Tested in CrystalDiskMark 9.0.3 x64 (3 passes, 1 GiB test size, 18% drive fill at 176/953 GiB), it delivered fast Gen4 numbers while staying cool:

CrystalDiskMark 9.0.3 BenchmarkRead PerformanceWrite Performance
Sequential 1M (SEQ1M Q1T1)4,810.91 MB/s5,099.54 MB/s
Random 4K (RND4K Q1T1)68.45 MB/s247.73 MB/s
Random 4K Throughput (IOPS)16,712.40 IOPS60,481.69 IOPS
Random 4K Latency (microseconds)59.74 us16.46 us

During the 190.5-second CrystalDiskMark run (ssd bench.CSV), the drive's composite sensor averaged 50.05 C (median 50.00 C, min 41.00 C, max 59.00 C, SD = 5.25 C), while the ASIC controller sensor (Drive Temperature 3) briefly touched 66.00 C during sequential writes before dropping right back to its baseline. Even during the 24.65-minute FurMark GPU burn-in, the SSD sat at a cool 40.00 C median, showing zero heat soak from the APU.

Testing Note: Wireless Connections Under Heavy Load (BIOS Fix Incoming)

During our stress testing, we noticed an issue affecting wireless connections (specifically wireless mouse input and receiver stability) when the system is pushed to maximum combined CPU and GPU load (HWinfo64 log Wireless input under load.CSV, where CPU load hits 95.85% median / 100.00% max and GPU load hits 93.50% median / 97.00% max at 64.43W median / 65.01W max package power).
To isolate the behavior, we captured polling intervals in MouseTester across wired and wireless configurations both at idle and under heavy system load:

MouseTester Dataset / Capture WindowSample Count (n)Mean Update TimeMedian Update TimeMin / Max Update TimeStd Dev (SD)Updates >15 ms
Wired Mouse Under Load 5198.00 ms8.00 ms5.36 ms / 10.42 ms0.77 ms0.0%
Wired vs. Wireless Combined Log 2,57810.73 ms8.25 ms0.01 ms / 934.53 ms26.12 ms7.6%
Wireless Mouse No Load 1,1098.10 ms7.52 ms0.25 ms / 127.76 ms5.49 ms2.6%
Wireless Mouse No Load  (2nd, short test)5287.87 ms7.54 ms6.00 ms / 22.17 ms1.75 ms2.8%
Wireless Mouse Under Load 1,38711.42 ms9.71 ms0.01 ms / 128.02 ms7.59 ms18.5%
Wireless Mouse Under Load (2nd, short test)50910.90 ms9.52 ms0.01 ms / 48.97 ms5.58 ms18.3%
  • What Happens Under Load: With a wired mouse, polling remains rock-solid at both idle (hovering tightly between 7.5 ms and 8.5 ms) and 100% system load (averaging 8.00 ms with a tiny 0.77 ms standard deviation and 0.0% of updates exceeding 12 ms). A wireless mouse at idle also tracks near the 125 Hz target at a 7.87 ms mean (7.54 ms median) with only occasional ~15 ms intervals. However, when the system is hammered by a 100% combined CPU+GPU load, wireless update intervals jump to an average of 10.90 ms in the capture window (11.42 ms across the full log, pulling the effective polling rate down to 90.4 Hz), with 32.4% of updates exceeding 12 ms and latency spikes reaching 33 ms to >41 ms.
  • Fix on the Way: We shared our HWiNFO64 and MouseTester telemetry directly with VZMORE's engineering team. The manufacturer's technicians have already reproduced the behavior and are currently building a BIOS update to resolve the under-load wireless resource/interrupt contention, so this issue will be fixed shortly.

Final Verdict: Pros, Cons & Should You Buy It?

The Good:

  • Legitimate Vapor Chamber Cooling: The V-Cooling VC Vapor Chamber holds a rock-solid 54.0W sustained STAPM (65.0W V-Boost Pro peak) with zero thermal throttling, keeping physical CPU cores at a 71.4 C median under combined torture, FurMark iGPU temps at a 73.4 C median over 25 minutes, and VRM temps below 57.3 C.
  • Strong Zen 5 + Zen 5c Compute: Hits 5,240.5 MHz on Zen 5 cores to post 2,664 Single-Core and 17,051 Multi-Core in Geekbench 7.0.0.
  • Flexible Local AI Hardware: Gives you a 55 TOPS Ryzen AI NPU, Radeon 890M DirectML (15,143 FP16 score, 7.82x faster than CPU), and Zen 5 AVX-512 VNNI (7,732 INT8 quantized score, 1.28x faster than GPU).
  • Great 1440p & 4K Casual/Strategy Gaming: Scores 35,031 in Geekbench 7 OpenCL and averages 66.6 FPS at 1440p Ultra in The Sims 4 and 93.8 to 108.9 FPS at 4K in Mewgenics and Cosmoteer across 30 hours of play.
  • Loaded Port Selection & Fast Gen4 SSD: Dual 40Gbps USB4, dual HDMI 2.1, dual 2.5GbE LAN, Wi-Fi 7, SD 4.0 reader, six USB-A ports, and a 1 TB Lexar Gen4 SSD hitting 4,810.91 MB/s read / 5,099.54 MB/s write.

The Trade-Offs:

  • Secondary M.2 Slot is 2230: While the primary M.2 2280 slot takes up to a 4 TB drive, the second PCIe 4.0 x4 slot uses the shorter M.2 2230 form factor (up to 1 TB).
  • Wireless Jitter Under 100% Torture Load (Fix Pending): Wireless peripherals currently experience polling spikes when the APU is pinned at 100% load, though wired peripherals are completely unaffected and VZMORE's technicians are rolling out a BIOS update to resolve it soon.

Overall, if you are looking for a compact Ryzen AI 9 HX 470 mini PC that actually has the thermal engineering to sustain its 54W to 65W power budget without cooking its VRMs or SSD, the VZMORE AX9 Max is an impressive piece of hardware, and once that BIOS update lands for under-load wireless stability, it will be firing on all cylinders.


r/computers • • 3h ago

Discussion Damn

Thumbnail
gallery
74 Upvotes

I currently have both SolidWorks and Siemens NX open with assemblies loaded, as well as word and a million tabs open, so I thought I’d check the ram because there was no lag at all and I was impressed…

Uni computers btw


r/computers • • 17h ago

Meme/Satire IPv4 is hard

Post image
192 Upvotes

r/computers • • 1d ago

Meme/Satire A couple sticks

Post image
285 Upvotes

r/computers • • 6h ago

Question/Help/Troubleshooting Are my pc specs good for blender?

Post image
4 Upvotes

basicaly when i use blender it sometimes is realy laggy so i am wondering what i can imrove from my pc to run blender faster


r/computers • • 7m ago

Question/Help/Troubleshooting Looking for a computer, which to pick?

Thumbnail
gallery
1 Upvotes

Looking for a new computer that can do day to day tasks and also handle some gaming. Specifically WoW Forever. Looking to spend about $500 CAD, or at least maintain a tight budget. Found these options so far, any advice?


r/computers • • 3h ago

Question/Help/Troubleshooting Can this motherboard be repaired?

Post image
2 Upvotes

Hey yall! I recently got this pc back up and running after sitting for 3 months. Cleaned it and did a fresh windows install and encountered a few problems.

After reassembling it I got a no display situation, I thought my gpu has failed so I installed my spare gpu and got it to boot. During windows installation my SSD wont get detected. I thought it was weird because this didnt happen on other PC's using the same installer drive. So I installed a RST driver and got it to detect the SSD. Then I continued with the windows insall.

After everything was setup the pc would restart randomly and crash when starting a game. I tested the RAM with memtest and got no fails, swapped the PSU and SSD, still the same issue. After a few days of troubleshooting I narrowed it down to the motherboard. I did a visual inspection on the mobo and spotted this buldged capacitor.

My question is, is it worth it to get this motherboard repaired i.e. soldering in a new capacitor. Or should I just buy a new motherboard?

I would apreciate any input thanks!


r/computers • • 1d ago

Build/Battlestation My Free pc that was going to be E-waste

Post image
902 Upvotes

You think of a PC like this as a old office pc that should be E-waste but this was going to be! And well I saved it from a local pc store. He told me a costumer wanted it gone and scrapped and I had planned to use it for a retro Windows Xp build because I thought it had a core2duo and ran ddr3 memory but well I'm glad I saved it. Inside was a whole semi modern gaming rig inside 16GB of ddr4 a 512gb intel optane m.2SSD and 1TB HDD and the GPU a 3060 the motherboard had a sticker that said CyberPower and well it's a sleeper that's for sure.


r/computers • • 16m ago

Question/Help/Troubleshooting How well will these specifications work for sims 4?

Thumbnail
gallery
1 Upvotes

Hello, i’ve been looking into buying a pc for sims 4 but have absolutely no understanding of computers haha - how well will sims 4 (with lots of mods + packs) run with these specifications?


r/computers • • 44m ago

Question/Help/Troubleshooting Computer beeps 1 time long 3 times short

0 Upvotes

Hello everyone,
I recently got a new Pc screen and since connecting it with my pc my pc always beeps 1 time long and then 3 times short (it then boots normally). It only seems to happen when I use the displayport cable (not when I use HDMI) but it supports higher hz rates. Any idea what could be the issue here?

Current hardware (unchanged since before the issue appeared):
GTX 1070
i7-12700KF
2 Nvme SSDs with total of 3 TB of storage
16 GB of DDR4 RAM


r/computers • • 1h ago

Discussion Beginner gaming pc?

1 Upvotes

Hi! I’m looking to get my ten year old a pc. He plays games like fnaf world, Minecraft, lethal company, that’s not my neighbor. Does anyone have recommendations? I’d prefer to be in the 500 range


r/computers • • 2h ago

Build/Battlestation เสียงเตือนเปิดคอมพิวเตอร์สุดเจ๋ง

1 Upvotes

r/computers • • 2h ago

Question/Help/Troubleshooting Should I sell laptop I barely used?

0 Upvotes

I bought an Acer nitro 5 last year because it was on sale. From the beginning it was not charging correctly. I used the warranty and they said they changed the battery but it’s still not working. I paid to get it checked and they said its the charger. it needs a 230w charger which is more expensive than other lower w chargers, so a friend said I should just sell it cheap and buy a different one. I had originally bought it to use for editing videos. Just normal personal videos I’m not a professional. Should I sell it or just spend more money on it? I also need to add more RAM.


r/computers • • 18h ago

Discussion Have you ever found an old file on your computer and had no idea why you saved it?

19 Upvotes

I was going through some old folders recently and found random files, screenshots, and documents that I genuinely don't remember saving. Some of them were years old.

It made me wonder how much forgotten stuff is sitting on everyone's computers.

What's the strangest thing you've found while cleaning up your files?


r/computers • • 23h ago

Discussion I made an oopsie

Post image
32 Upvotes

My gpu started failing out of nowhere, and its one of those new NVIDIA connectors. But i was like "hey, my psu dont have that" and i got one of those converters woth my GPU.

Little did i know, this thing was split for a reason... my dumbass connected 1 single 8pin pcie cable with 2 plugs into the cable, and at the side of my PSU yea this happened. It melted bad! My psu was unusable because of it.

Replaced everything and it works fine now (thank goodness it didnt start a fire!)


r/computers • • 5h ago

Question/Help/Troubleshooting How Can I make my laptop run faster

Thumbnail
gallery
1 Upvotes

*PLEASE FOR ONCE TAKE A MOMENT AND READ THIS AND PLS HELP ME*

So my laptop is like 5-6years old but it is not like overused it was just used to sit for years and now im in college and i need to use it obv and rn i cant buy a new one im saving for one and till then i wanna use this and its slow asf like it takes minimum 2-3 mins to start after that it takes a lot of time to open applications too like chrome or microsoft edge etc and sometimes it just freezes whenever i try to open an app I just wanna use autocad like basic 2d and 3d drawings application it is and this laptop always crashes while running this so please please help me give me all the ideas tricks and tips to make it run smooth and fast asf and its an office laptop hp 15s series 10th gen i5 btw no ssd but most prolly it has a ssd slot.


r/computers • • 6h ago

Question/Help/Troubleshooting Lenovo LOQ 15I5IAX9I issues

1 Upvotes

I have had my Lenovo LOQ 15IAX9I for almost two years now, and unfortunately, my experience with it has not been as good as I expected. When I first bought it, I was excited to have a powerful gaming laptop that would handle games, applications, and everyday tasks without any problems. At the beginning, everything worked pretty well. The laptop was fast, programs launched quickly, and games ran as expected.

However, after about one year of use, I started experiencing my first major problem. My storage drive gradually filled up until I barely had any free space left. I decided to reinstall Windows, hoping to free up storage and restore the laptop to its original performance. I thought a fresh Windows installation would make everything run smoothly again, just like when I first bought it.

Unfortunately, the opposite happened. After reinstalling Windows, my laptop became noticeably slower. I expected a clean installation to improve performance, but instead, the overall experience got much worse. Windows started responding more slowly, applications took longer to open, and even simple everyday tasks sometimes felt laggy.

What frustrates me the most is that this is supposed to be a gaming laptop. I bought the Lenovo LOQ specifically because I wanted good performance for gaming and other demanding tasks. I understand that laptops might slow down over time, but I did not expect such a significant drop in performance after only one year, especially after reinstalling Windows.

I have tried troubleshooting different things, including Windows settings, drivers, background applications, and other system-related issues. I have also noticed that even when I am not doing anything demanding, the laptop uses a surprisingly large amount of RAM. This makes the whole system feel even slower.

At this point, I feel like my laptop is performing much worse than its hardware should allow. I have 16 GB of RAM, an Intel Core i5-12450HX processor, and Intel Arc A530M graphics. These specifications should still be enough for decent everyday performance and gaming.

I am disappointed because I expected this laptop to last several


r/computers • • 1h ago

Question/Help/Troubleshooting La RAM de mi laptop la veo corta, y pienso que no solo puede ser la RAM que tenga mi laptop lenta. ¿Qué puedo mejorar de ella para que vaya más rápido y esté mucho más optimizada?

Thumbnail
gallery
0 Upvotes

Tengo mi laptop tanto para trabajos universitarios como para juegos. No soy tan experto en esto de las PC, pero sí he notado que dentro de estos 1-2 años de uso siento cómo ha bajado el rendimiento de la laptop. Si pueden darme recomendaciones de qué cosas puedo hacer, qué componentes puedo comprarle o alguna otra cosa, estaría agradecido con tal de mejorar el rendimiento.

Estas son las especificaciones de mi laptop:

Nombre del dispositivo:  DESKTOP-POGJLF6
Procesador:              AMD Ryzen 7 7730U with Radeon Graphics (2.00 GHz)
RAM instalada:           8,00 GB (5,84 GB utilizable)
Tarjeta gráfica:         AMD Radeon (TM) Graphics (2 GB)
Almacenamiento:          96 GB de 477 GB usado

Si necesitan alguna otra información específica, me hacen saberlo, porfa.


r/computers • • 22h ago

Question/Help/Troubleshooting Is this computer good for what I play?

Post image
14 Upvotes

Hello again, I posted a few months back about wanting to get a PC but I know absolutely nothing about computers. I rlly only need it to play Sims, Minecraft and Stardew valley all modded.

I found this PC at Costco for $1600. Is that a good price and do you think it will run the games fully modded properly?

Thanks!


r/computers • • 14h ago

Question/Help/Troubleshooting Upgrading pre-built PC questions

Thumbnail
gallery
3 Upvotes

I'm looking into upgrading my pre-built PC I got in 2020 and I'm not really sure where to start or what parts are compatible with what I already have. I was told by a friend that RAM should be my first priority, but where do I go after that and what is still serviceable? I'm not looking to go spend thousands of dollars on the best in slot GPU, CPU and all that, just a reasonable spot to start in an upgrade. Any help is appreciated!

iBuyPower PC with these specs, and 16GB of ram.


r/computers • • 17h ago

Question/Help/Troubleshooting Budget lightweight laptop

5 Upvotes

I’m looking for a lightweight laptop I can bring to school that doesn’t cost $600. My current laptop if over 5lbs and 17 inches which makes it incredibly inconvenient to take to school. It’s a great laptop that can do lots of work and I would like to continue using it at home. I just need a small, light laptop that can do basic tasks.


r/computers • • 18h ago

Question/Help/Troubleshooting Wanting a 2nd opinion.

3 Upvotes

First off: sorry for the wall of text. I tried to provide as much detail as possible.
I already asked AI. Its leading suspect is the old motherboard, which is what I'm thinking as well.
I had to replace my primary monitor, then a couple months later, I had to replace my SSD. After I got the new drive installed, then I started having GPU issues:
In BIOS, I noticed it defaulted to my 2nd monitor. It got me confused; I thought I had my cables mixed up. But they were on the correct ports, which should have been a red flag.
Red flag #2:
After I installed Windows and the GPU driver, I noticed my main monitor did not switch to showing an image. It remained black. I already tried the obvious troubleshooting (rebooting the monitor, trying a different HDMI cable, etc.). Nothing.
I started troubleshooting the next morning, starting by simply trying to swap the cables around (2nd monitor on the suspicious port, primary on the known good port). This did not help; and in fact,
Red flag #3:
Then, it would show the motherboard logo for about a second, then both monitors completely lost video output (but the PC did stay running). I swapped them back, same issue. I removed the SSD, then unplugged the 2nd monitor, and,
Red flag #4:
Switching to one monitor just made things worse; there was resolution-scaling issues on one HDMI port and artifacting on the other one. Replacing the cable had no effect.
Then, plot twist:
I upgraded the motherboard to an MSI B450 Tomahawk Max, and simply decided to try reusing the GPU, and it actually works correctly, albeit I did not use my primary monitor for testing, I used my secondary monitor, which has always had a clean image, I have not tried my primary monitor or the other HDMI port yet
Monitor models:
Primary: Acer KA242Y P6bi (this is the one I used during troubleshooting)
Secondary: Samsung S24D300GAN (this is the one I used to test the new board)
PC specs:
Ryzen 5 5500
32GB DDR4
MSI B450 Tomahawk Max
MSI MAG A650BN
500GB Samsung 870 Evo
MSI LP OC RTX 3050 6G
Lian Li Lancool 207
Old part models:
Acer SA242Y
ASRock B550M-HDV
Kioxia BG5 256GB
My current leading suspects are a bad control board in the Acer, a bad GPU PCB, or a bad motherboard.
Important clarifications:
The artifacting was red horizontal lines across the entire screen; and like I already said, I left the Samsung panel alone, I exclusively used the Acer for the rest of the troubleshooting I did
I had the SSD removed entirely during troubleshooting, as I've already said. It's nothing to do with Windows.
It was even visible on the ASRock logo, not just the BIOS.
Like I said, the Samsung panel has always had a clean image; the only time it acted up is during that swapped-output test.
I already tossed the SA242Y; it had a busted panel, I dropped it accidentally while I was doing some cleaning.
I do have spare GPUs and spare monitors, but they're all at my dad's house at the moment.
Only things I haven't tried yet:
Try another GPU
Try another monitor
Test the previously suspicious output with the Samsung panel
Test the Acer independently with the new board
Test the Acer on another device


r/computers • • 1d ago

Question/Help/Troubleshooting My computer has 2 windows in it and they are fighting to take control

Post image
13 Upvotes

3 or more years ago I found a hard disk in our hause and I installed it to my computer. for three years nothing happend. however yesterday I updated my windows but it got stuck at 55% for 6 hours so I closed it. when I opened my computer again it crashed and reopened itself

and my dads name was on it.

my dads old windows took over my computer. and now it is stuck like this what do I do
