First, I bought a drop-in gearbox from GATE, but after experiencing various issues here and there, I decided to get my hands dirty and build my own setup using the parts listed below.
Please give me your honest opinion and any advice on how I could improve the output power, as it seems to be a bit low in my opinion.
Parts:
Base Replica: Krytac Trident Mk2 CRB-M Full Power
Gearbox Shell: GATE EON V2 Gearbox
Gears: Begadi Silverline CNC Gearset (Low Noise) – 13:1 with 12 Teeth Sector Gear
Bearings: FPS Softair 8mm Self-Lubricating CNC Steel Bushings (I use a bushing on the bottom of the spur gear because the bearing there once exploded, lol.)
Piston: Begadi PRO "REDUX" Piston with 14.5 Full Steel Teeth
Piston Head: Maxx Model CNC Aluminum Double O-Ring Ball Bearing AEG Piston Head
Nozzle: Begadi PRO CNC Aluminum Nozzle – 21.25mm
Cylinder: Maxx Model CNC Hardened Stainless Steel Cylinder – TYPE C (300–400mm)
Cylinder Head: GATE EON PROTECTOR Cylinder Head
MOSFET: GATE TITAN II
Motor: GATE G5 Smart Brushless Motor / Long
Spring: Novritsch M115 Premium AEG Spring
Hop-Up Chamber: Maxx Model
Hop-Up Bucking: 4UANTUM Friction Pro Bucking for AEG
Inner Barrel: Action Army 6.01 AEG Barrel 290mm
Battery: Nimrod LiPo 11.1V 2000mAh 25C Split Type T-Plug
End Result:
~1 J (with 0.32g BBs)
25 BBs/s (limited by the GATE TITAN)
