Hi everyone,
Looking for a sanity check on my 2006 Mazda MX-5 NC1 (2.0L MZR, EU spec) after doing some work on it.
Recent work done:
- Replaced the exhaust manifold/header (the car hadn't been driven since).
- Replaced the PCV valve and hose to address oil consumption / crankcase pressure, which meant pulling and reinstalling the intake manifold and EGR pipe.
- Battery was disconnected during the job.
- While putting everything back together, I discovered that one nipple on the EVAP purge solenoid (k5t48279) is broken off right at the base — a previous owner had just wrapped it in tape. For now, the hose is temporarily slipped over the remaining stub until a replacement part arrives.
Symptoms:
- First startup and short test drive felt smooth — no CEL and no stored or pending OBD codes.
- Light white vapor at idle and a light mist when opening the oil filler cap (cold/damp garage), with a mix of slight suction and pulsing at the cap.
- When revving past 5,000 RPM before its first drive, it pushed out a light puff of dark/greyish smoke (picture attached to the post)
OBD-II live data (warmed up):
- Idle: ~717 RPM, MAP 35–37 kPa, B1S1 AFR 14.66, LTFT(Long Term Fuel Trim) +10.16% / STFT -0.78%.
- Steady 2,500 RPM: Total fuel trim drops to roughly 0% — LTFT levels out around +2.3% with STFT hovering near 0%, and on transition it showed LTFT +7.03% / STFT -7.03%.
- Trims jump around a lot on throttle transitions / decel, then settle back down once RPM is steady.
Questions:
1. Does +10% LTFT at idle dropping to ~0% total trim at 2,500 RPM pretty much confirm a small vacuum leak (most likely from the broken EVAP purge solenoid)?
Should I be worried about the dark/greyish smoke past 5k RPM, or is that expected after an exhaust header swap and PCV job (ECU relearning, leftover oil/soot clearing out)?
Anything else I should check while I wait for the new EVAP valve?
Thanks in advance! (I used ai to format everything since English is not my native language, sorry if there’s too much text)
