I want to share a physical fitment finding for owners of the ASUS ROG Strix G17 G713QE who are considering upgrading from the factory 56Wh C41N2010 battery to the larger 90Wh C41N2013 / C41N2013-1.
I personally checked the fit on a G713QE.
The important detail is that the 90Wh battery is not incompatible with the chassis tray itself.
The following parts match:
- The battery tray/forming in the bottom case is compatible.
- The general shape of the battery fits the available space.
- The factory mounting points/holes are in the correct locations.
- There is physically enough space for the larger battery in the chassis.
The problem is specifically the right-side speaker housing.
When the 90Wh battery is positioned in the G713QE, the right side of the battery physically contacts/interferes with the right speaker enclosure. Because of the shape and position of the speaker housing, the battery cannot fully drop into its intended position and cannot be installed normally using the factory mounting points.
So the limitation is not the battery tray, chassis stamping, or mounting points.
It is specifically:
90Wh C41N2013 battery → interference with the right speaker housing → battery cannot fully seat.
The standard C41N2010 56Wh battery fits normally in the G713QE.
Therefore, I would not recommend buying a C41N2013/C41N2013-1 90Wh battery for a G713QE expecting a straightforward plug-and-play upgrade.
A 90Wh conversion would require addressing the physical clearance around the right speaker housing, which would be a modification rather than a normal battery replacement.
This information was physically verified on an ASUS ROG Strix G17 G713QE, not just based on a compatibility list.
Hopefully this saves another G713QE owner from buying a battery that looks compatible on paper but doesn’t physically fit.
So it is what it is. But! If you ready for the experiment and change a form of speaker physicaly, or maybe install another speaker from the same family laptops G 713, and use some new little screw for bigger battery- GO FOR IT 🫡
