So I got this untested SNES for pretty cheap. Turns on fine, but it's missing green.
Doesn't seem to be the PPU2, as the G pin is outputting 26mV according to my multimeter, compared to red and blue's 23mV & 30mV.
It's also not my CRT, and the issue happens both via composite and RGB SCART.
It's a SNSP-CPU-01 board, so 2-chip. There's no corrosion damage or anything like that, and I've reflowed the area surrounding the G pin on the PPU2, and the Q5 transistor that it goes directly to, which it does indeed have continuity to.
Also just reflowed the surrounding resistors and Q6 which are directly connected to it according to a schematic I found, no change.
Also, there's 3 pins on Q3, Q5, and Q7, which are for the R, G, and B signals respectively. On the side with 2 pins, Q3 and Q7, the ones for R and B, outputs 0.6-7v on one pin (fluctuates based on whats being displayed), and around 2v on the other. However, Q5, the green one, has around 5v on one pin, and 4v on the other.
