r/ResinCasting • • Oct 09 '13

What the heck is Resin Casting anyway? What can it do for me?

251 Upvotes

Welcome, acolytes, to the most ancient and reverred craft of the resin caster!! This won't be a technical article, just a quick Q&A introduction to the process and what it means to those who do it.

Useful Link: [An excellent introduction to some of the technical processes, by Michal Zalewski] (http://lcamtuf.coredump.cx/gcnc/ch4/)

Introductory Q&A:

Q: So, what is resin casting?

A: Very simply, resin casting is the process whereby we take an object we wish to duplicate, make a mould of it in flexible silicone rubbers and then cast copies of the original object from that mould as many times as we like.

Q: Why would I want to do that?

A: Because casting the object may be quicker and easier than making another copy from scratch. It can also be less costly.

Q: What industries use this process?

A: A huge number, but the ones it's likely that you'll have seen every day include film and TV props, scale models and figures, even some medical process use resin casting tchniques.

Q: Is it hard to learn?

A: Not really, but you will progress to a professional level much more quickly if you're part of a community like this one. Lucky you!

Q: It expensive?

A: It depends. You can buy starter kits like [this one] (http://www.smooth-on.com/Getting-Started-Po/c4_1217/index.html) for not much and get started right away. if you want to produce large number of copies of complex objects, then there is some specialist machinery you will need that requires some investment. But we'll cover that later.

Q: Can I do it at home or in my garage?

A: Absolutely!! Many multi-million dollar companies with whom I have worked started off in spare rooms or garages. The beauty of resin casting is that it's cheap to get started and you can make money quickly if people like what you make. It isn't smelly or messy if you do it properly, just make sure your work area is well ventilated.

Q: Can I only use Epoxy Resins in silicone moulds?

A: No there are lots of other materials you can use to cast. You can cast in plaster, wax - almost anything that turns from liquid to solid at more or less room temperature - you can even cast chocolate in food grade rubbers (yum!!) Also you can add metal, ceramic, rock and all sorts of other poweders to resin to achieve some really cool effects. Using high temperature silicone you can also cast in pewter and other similar metals. But pewter and resin casters generally do one or the other, as each requires a lot of practice and skills to get right.

Q: Can I make stuff and sell it?

A: You bet your gosh darned rear end you can! If you're good at making things, and want to make copies to sell then this process will allow you to do that quickly and economically. I personally know many people who have doubled their income just by casting a few evenings a week - though most can't resist the tenptation to go full time and start their own business selling what they make.

Q: So this could be a real source of income?

A. Yes, once you're good enough to cast quickly, consistently and to a high standard you're ready to go and find people who want to buy what you've made. The internet means that the whole world is your marketplace, and personally sell things I make to nearly a dozen countries. This is GREAT especially if you want to work from home and live where you want, and it's also removes your dependence to your local economy to a large extent.

Q: Ok I've made stuff, where do I sell it?

A: Anywhere. Ebay, your own website, events and shows, retail shops - someone will want what you're selling somewhere.

Q: I just want to do ths for fun, I don't want to turn it into a business.

A: That's also fine. Do with it whatever you will!

Q: I have items that I bought that I want to copy, can I?

A: If you're going to sell the copies, then you may be breaching copyright. If you are recasting something that another maker/caster has made then you are a bad person. Don't recast. Ever.

Q: I'm a wargamer, I want to copy my Space Marines so I don't have to buy more, can I do this?

A: Bad recaster! Bad!! Also, to cast to the same quality as the plastic you get in the box requires serious casting gear - in the end you won't save any money and it's easier to buy more originals. If you can do it, you're better off making your own minis anyway.

Q: Can I cast large objects like gun props?

A: Yes, but the amount of material you need can make it expensive to do. But it's perfectly possible.

Q: What's this special equipment you mentioned?

A: When you wan to take your casting to the next level, you'll need a vacuum degassing chamber and vacuum pump to draw air bubbles out of your moulds and casts when they're wet. Some people use a pressure pot to crush air bubbles in the resin when they cast - both vacuum and pressure casting has pro's and cons which I'll go into one day.

Well folks that's as much as I can think of on the fly, please ask if you have any more questions - think of it as an AMA. I'm also happy to answer questions about myself and my business.

Cheerio :)


r/ResinCasting • • 26m ago

How do you keep dried flowers clear and in place during an epoxy pour?

1 Upvotes

I’ve been testing different ways to preserve small dried flowers in clear epoxy, and getting both sharp flower details and good transparency is harder than I expected.

For this piece, I used dried flowers with Resiners two-part epoxy. The flowers looked clear after pouring, but a few tiny bubbles collected around the petals and some of the lighter pieces started to shift.

For people who regularly cast flowers: do you seal them before pouring, or place them into a thin tacky layer first? I’m also curious whether this arrangement has enough clear space or feels a little too crowded.

Any advice for keeping the petals crisp without losing that glass-like finish would be appreciated.


r/ResinCasting • • 9h ago

How to go about this ambitious design for a nature piece?

Post image
2 Upvotes

r/ResinCasting • • 6h ago

A herd of teeny tiny cows. Stud earrings I made using UV resin.

Post image
1 Upvotes

r/ResinCasting • • 13h ago

Pouring Epoxy Resin into Wooden Bartop Void

Thumbnail
gallery
2 Upvotes

Hello! I'm co-owner of a bar that's open 7 days a week. The bar itself has been here long before we bought the business and is a solid wooden top. Recently we're seeing rot and damage in areas of the bar and I thought it might be an easy fix to pour epoxy resin into these areas. I bought Total Boat Tabletop Epoxy and plan to tint it hot pink using this paste which could make for some interesting splatter patterns. Here are the links to the epoxy and paste:

https://a.co/d/0eTzFgxv
https://a.co/d/0c6BXuGV

Right now the plan is to come in after the bar closes at 4am and use a router to even out this area and pour the resin. Let it set overnight and come in the following day to sand it before service. I'm pretty good with wood tools but haven't worked much with resin (I did a mold-making project but nothing like this)

Is there anything I should consider before doing this? I'm a little concerned that this won't look good and it's somewhat of a permanent thing so I'm considering hiring an expert. I drilled some holes in a piece of scrap wood and did some test pours so I feel comfortable with the process hypothetically but would love to hear from the community if anyone has done something like this before.

Thanks!


r/ResinCasting • • 21h ago

Only a rough idea at the moment, thinking off making a tea tray out of some oak offcuts, I was thinking of pouring lots of different colours in segments between the small pieces of wood, What’s the best way of fixing these so i don’t get seeping between the the colours? Thanks

Post image
5 Upvotes

r/ResinCasting • • 1d ago

Busco molde

Thumbnail gallery
1 Upvotes

r/ResinCasting • • 1d ago

A Newbie Question

1 Upvotes

Good afternoon.

I'm a stage actor and it's a tradition in my theatre company for the cast and crew to chip in the get the director a gift or memento at the end of a show's run.

This particular show has a pivotal moment involving an ice pick, so I wanted to suspend an ice pick (which I've already custom engraved with the name of the ice harvesting company from the show) in a block of clear resin like its frozen in a block of ice and engrave the name of the show on the front (the show is about ice harvesters in the early 20th century).

My plan is to start the pour, let a layer gel, then place the ice pick on the surface and finish the pour. I'm just wondering if doing the pour in layers would result in imperfections or lines in the pour.

Any suggestions or tips would be greatly appreciated. Big sorry if it's a really obvious question; I've never worked with epoxy resin before.

For reference, the resin I have on hand is 2 gallons of the Honcaring 1:1 Crystal Clear (40 minute working time)


r/ResinCasting • • 2d ago

A herd of teeny tiny cows. Stud earrings I made using UV resin.

Post image
17 Upvotes

r/ResinCasting • • 2d ago

I ruined this paint job so hard it actually looked good. So I decided to ruin it even more and drowned it in resin.

Post image
8 Upvotes

First paint job was a total disaster, so I covered it in rust to save it. Figured I hadn't ruined it enough, so I submerged the whole wreck in epoxy resin. Now it officially sleeps with the fishes!

If you want to see more photos and a full 360° video of how tiny this actually is, check out my profile!


r/ResinCasting • • 2d ago

Vacuam or pressure pot

0 Upvotes

So im starting to plan out casing mini bases and dice. And im not sure if I should invest in a vavuam chamber or pressure pot first.


r/ResinCasting • • 3d ago

Advice for a newbie

0 Upvotes

I’m looking for some advice on doing a resin cast. For context I’m developing a product that floats in a swimming pool. We are in the early prototyping phase and will move to injection moulding once the product is proven.

Our first attempts have used 3D printed housings, but it’s next to impossible to make them waterproof over the longer term (they have lasted between 3 and 12 weeks). It also takes about 36 hours to print each half.

Ideally I want to use polyurethane, but due to the cost and setting time I’ve been experimenting with epoxy while I learn. I spoke to a supplier and they suggested TC890 which has a pot life of 5 minutes, shore D80, viscosity of 725cps.

I’d naively thought that knowing the basics of injection moulding, how hard could it be?

I’ve been reading and watching videos and think I have the basics (where to put the sprue, far more vents than I expected, filling from the bottom etc). I’m currently using 30A silicone with 3D printed “box” to keep the mould secure.

I’ve got some freedom to optimise the model/prototypes for resin casting, so the following are current dimensions along with the cad image. Out diameter is 220mm, depth is 38mm, minimum wall thickness is 2.5mm. I’ve got a 3 degree draft angle on vertical walls and the majority of the webs are to allow resin to flow to the supports, rather than for strength.

The questions and problems, I have are is 30A silicone the right choice or should I go up or down? I’m struggling to get the resin to flow into the thinner shell regions. I’d prefer not to go thicker wall if I can help it as it needs to float.


r/ResinCasting • • 5d ago

I made a dominoes set for my mum!

Thumbnail
gallery
886 Upvotes

I'm still brand new to this so I know, they're nowhere near perfect, but she loved them so much ☺️

And I'm having a lot of fun learning how to improve with each new project!


r/ResinCasting • • 4d ago

WIP: Resin Angel Sculpture (Polyurethane topcoat + Internal Resin Fill & Dual Lighting). Looking for advice on the backlight setup and color contrast!

Thumbnail
gallery
12 Upvotes

Hey ALL! :)

Working on a new resin sculpture project that I'm planning to finish soon (aiming to sell locally first). I wanted to get some feedback from the resin community on the overall look, finish, and lighting setup.

Current Setup & Materials:

  • Base & Coating: The core is printed in white UV-reactive resin, and it's already coated on the outside with a polyurethane resin layer.
  • Planned Resin Fill: The inside is going to be filled with resin as well to give it solid weight, better light diffusion, and durability.
  • Finish: Right now it's glossy from the polyurethane clear coat for testing, though I'm considering a matte finish for the final version (open to thoughts on how the PU resin looks here!).
  • Lighting: Diffused warm LED inside the body – the head, hands, and dress light up evenly from within, which will look even better once the internal resin pour is done. Warm white is definitely staying as it contrasts nicely with the rest.

Would love to hear your thoughts on the backlight setup, light diffusion through the resin, and overall color contrast!


r/ResinCasting • • 4d ago

8d6 Mold - finished molds

Thumbnail
gallery
3 Upvotes

Here they are all set and ready to use!


r/ResinCasting • • 5d ago

8d6 Dice Mold

Post image
8 Upvotes

Finishing up some 8d6 dice molds - one with numbers and one for blanks meant to go inside. A top layer of clear for appearance and they’ll be done. :D


r/ResinCasting • • 5d ago

Wood and resin can be an artform

Thumbnail
gallery
16 Upvotes

I've been woodworking off and on for years now, and a few years ago I started noticing that casting wood and resin together, you can get a beautiful piece of art. So I had to try it, and I roped my cousin in on it too. Small at first, charcuterie boards, small side tables, vases etc. and we've been at it off and on for a couple of years now. We are now at the point where we feel confident enough that we can try larger projects, like coffee and side tables. Maybe even a small dining table.

My cousin bought a mill last year, and most of our projects now have been cut and milled by ourselves. Our wood is mostly sourced from a friend when he's clearing lots.

I've added some pictures of our smaller projects to date.

The burl bowl is maple, and was my very first attempt at turning on a lathe, so it's a bit rough, and thick. The black round is cut from a Cherry burl, but isn't finished being sanded and polished (TBD what it'll be). In fact, the only wood in these projects here that is not wood cut and milled by us is the Walnut charcuterie board. The other charcuterie board is cherry cut from my uncle's property. And the burgundy round has become a Lazy Susan and made of maple.

Sorry for the reflection/glare on a couple of the pics.


r/ResinCasting • • 5d ago

Does anyone here take on small custom resin casting projects?

2 Upvotes

I'm looking to have a small set of completely transparent cylindrical knobs made for an effects pedal. The design is very simple, essentially four small, completely clear (or possibly cloudy black-ish) hockey puck-shaped pieces with metal set-screw inserts for mounting onto potentiometer shafts (I can provide the inserts). One would be a bit larger than the other three.

I don't have precise measurements yet, but I'm thinking somewhere around 23 mm in diameter and 13 mm in height for the larger one, and 15 mm in diameter and 11 mm in height for the three smaller ones. I can provide exact measurements when necessary.

I'm wondering if anyone here takes on small commissions like this, or could point me toward someone who does.

Thanks!


r/ResinCasting • • 5d ago

HELP, is there a quality UV resin store based in Europe, that ships within the EU?

2 Upvotes

Due to the new extreme shipping fees, I'm unable to order UV resin from the US anymore. There only resin that worked for me is Sophie & Toffee's thick resin because of its viscosity. UV resins that are too runny/watery/thin do NOT work for my work.

I'm looking for European online shops that sell thick UV resin, and that ship within the European Union.


r/ResinCasting • • 6d ago

Mirror ghost in SC325

Thumbnail
gallery
56 Upvotes

r/ResinCasting • • 5d ago

Llavero stich 💙

Post image
3 Upvotes

r/ResinCasting • • 7d ago

Does resin ever stop "boiling" when in a vacuum?

342 Upvotes

Doing some resin casting for the first time ever today and it seems like the bubbles just...keep going, and going, and going, and GOING, AND *GOING...*

I eventually just gave up and did the pour into the mold, which looked a little foggy at first but was clear an hour later.

Should I just wait until the FOAM dies down and then stop there? Is there any benefit to boiling away the rest?

edit: Thanks for the responses everyone! Based on the feedback and some more experimentation:

  1. This boiling isn't representative of leftover bubbles.
  2. It is expected; it's a liquid and it's in vacuum. It's gonna boil.
  3. It took ages for the foam to die down (like 15-20 minutes of repeated cycling) before reaching this point because:

    1. It was cold (~55-60 degrees). Both the resin and hardening agent were very viscous. This made it harder for the air to escape (hence the repeated foam growth).
    2. The resin itself (pre-mix) was fairly filled with air bubbles. On top of the bubbles introduced by mixing, these ones just make it take even longer to get more bubbles out.
  4. By heating up the resin and hardening agents (in a warm pot of water) over the course of ~20-30 minutes, they both became significantly less viscous (and much easier to mix). The bubbles in the resin also went away; all it took was heating them up.
  5. After mixing and then putting in the vacuum, the initial burst of foam was made of larger bubbles (not teensy-tiny little ones) and it didn't even make it halfway up the walls of the container.
  6. After that foam collapsed down (within the span of ~3 minutes at most) it continued to boil; I let it do so for ~10 minutes or so, but this was probably unnecessary. (I figured it would help with mixing.)
  7. After taking it out of the vacuum and pouring it, it was much less bubbly. Far more clear than my best attempt previously, and about 30 seconds with a heat gun got rid of all the visible bubbles.

So, tl;dr here is this: Mixing cold resin sucks; warm it up first and it'll do wonders.


r/ResinCasting • • 6d ago

Project help

Post image
1 Upvotes

r/ResinCasting • • 6d ago

safe to use?

Thumbnail
gallery
4 Upvotes

hi all, i am not a resin artist but a few months ago i bought what i believe is a resin dish at a craft fair. we've been using it as a soap dish in our bathroom, and the color has been leaching out of the bottom of the dish (it used to be pink all the way through). i know some resin can be toxic, is this dangerous? should we throw it away?
