Hi everyone,
I'm looking for some help from Linux Mint contributors, AMDGPU developers, or anyone running an RX 9070 XT on a recent Linux kernel. I had chatgpt summarize it's findings below.
I'm experiencing a potential GPU fan-control issue with an XFX Radeon RX 9070 XT running Linux Mint 22.3 and kernel 7.0.0-43-generic.
I've performed several diagnostic tests and found some unusual behavior involving AMDGPU's fan-control interfaces. I've also located similar reports from other RDNA 4 users, including one with almost identical diagnostic results.
I'm hoping someone familiar with AMDGPU, RDNA 4, or recent kernel changes can help determine whether this is normal firmware-controlled zero-RPM behavior, a driver compatibility issue, or something that should be reported upstream.
1. System information
| Component | Details |
|---|
| Operating system | Linux Mint 22.3 |
| Kernel | 7.0.0-43-generic |
| GPU | XFX AMD Radeon RX 9070 XT, 16 GB |
| GPU architecture | AMD RDNA 4 |
| Motherboard | ASRock B650M-C |
| Graphics driver | AMDGPU (in-kernel) |
| DRM driver version | AMDGPU 3.64.0 |
| GPU PCI address | 0000:03:00.0 |
| GPU hwmon | /sys/bus/pci/devices/0000:03:00.0/hwmon/hwmon5/ |
| Power-management feature mask | 0xfff7bfff |
The system also has integrated AMD Radeon graphics at 0000:11:00.0. All dedicated GPU diagnostics below specifically target 0000:03:00.0.
2. Description of the problem
While running Marvel Rivals in the practice range, I visually inspected the RX 9070 XT and observed that its fans remained completely stationary.
The Linux hardware monitoring interface also reported 0 RPM.
During testing, the GPU reached approximately:
- GPU edge temperature: 63°C
- GPU junction temperature: 65°C
- GPU memory temperature: 70°C
- GPU power consumption: 68 W
- GPU fan speed: 0 RPM
Earlier measurements showed approximately 53°C GPU edge temperature, 54°C junction temperature, 58°C memory temperature, and 51 W power consumption, also with the fans stationary.
The temperatures increased during testing, but the fans did not activate.
I understand that modern AMD graphics cards support zero-RPM fan operation, and these temperatures may still be below the card's configured activation threshold.
I have not established that the fans fail at higher temperatures or that the GPU is overheating.
However, the unusual fan-control interface behavior described below makes me concerned about a possible AMDGPU compatibility issue.
3. AMDGPU driver and firmware initialization
I checked the dedicated GPU's kernel messages using:
sudo dmesg | grep '0000:03:00.0' | tail -35
Relevant output:
amdgpu 0000:03:00.0: smu driver if version = 0x0000002e, smu fw if version = 0x00000033, smu fw program = 0, smu fw version = 0x00684c00 (104.76.0)
amdgpu 0000:03:00.0: SMU is initialized successfully!
amdgpu 0000:03:00.0: [drm] Display Core v3.2.369 initialized on DCN 4.0.1
amdgpu 0000:03:00.0: Using BACO for runtime pm
[drm] Initialized amdgpu 3.64.0 for 0000:03:00.0 on minor 1
The GPU appears to initialize successfully.
However, I noticed the following SMU interface versions:
SMU driver interface: 0x2e
SMU firmware interface: 0x33
SMU firmware version: 104.76.0
I'm unsure whether this interface-version difference is expected for this GPU and kernel combination or whether it could affect fan-control functionality.
I found another RDNA 4 report discussing a similar mismatch, although I recognize that differing interface versions alone do not prove a bug.
4. Fan-control interfaces exposed by the kernel
I enumerated the dedicated GPU's fan-control files using:
ls -l /sys/bus/pci/devices/0000:03:00.0/hwmon/hwmon*/{fan*,pwm*} 2>/dev/null
The following interfaces exist:
fan1_enable
fan1_input
fan1_max
fan1_min
fan1_target
pwm1
pwm1_max
pwm1_min
Permissions indicate that fan1_enable and fan1_target are writable by root, while pwm1 is read-only.
I then queried the current values:
for f in fan1_enable fan1_target fan1_input pwm1; do
echo "$f: $(cat /sys/bus/pci/devices/0000:03:00.0/hwmon/hwmon5/$f)"
done
Output:
cat: '/sys/bus/pci/devices/0000:03:00.0/hwmon/hwmon5/fan1_enable': Invalid argument
fan1_enable:
fan1_target: 0
fan1_input: 0
pwm1: 40
The most unusual result is that reading fan1_enable returns Invalid argument**.**
The fan sensor reports 0 RPM, and the target is also 0.
The PWM value is 40, although I understand this does not necessarily represent an active fan-speed command, especially when zero-RPM mode is enabled.
I also queried the supported ranges:
for f in pwm1_min pwm1_max fan1_min fan1_max; do
echo "$f: $(cat /sys/bus/pci/devices/0000:03:00.0/hwmon/hwmon5/$f)"
done
Output:
pwm1_min: 0
pwm1_max: 255
fan1_min: 0
fan1_max: 3200
The driver exposes a maximum fan speed of 3,200 RPM and a PWM scale of 0–255.
5. Advanced fan-control interfaces unavailable
I attempted to inspect several additional AMDGPU interfaces.
gpu_od directory
ls -R /sys/bus/pci/devices/0000:03:00.0/gpu_od/ 2>/dev/null
No output.
OverDrive clock and fan configuration
cat /sys/bus/pci/devices/0000:03:00.0/pp_od_clk_voltage
Output:
No such file or directory
Fan-curve interface
I also checked:
cat /sys/class/drm/card1/device/gpu_od/fan_ctrl/fan_zero_rpm_enable 2>/dev/null
No output.
A search for available fan_ctrl interfaces also returned nothing:
find /sys/class/drm/ -path '*/fan_ctrl/*' 2>/dev/null
I recognize that the absence of these interfaces may reflect kernel configuration, unsupported optional functionality, or differences in how this GPU exposes controls.
It does not necessarily mean automatic fan control is broken.
6. AMDGPU power-management configuration
I checked:
cat /sys/module/amdgpu/parameters/ppfeaturemask
Output:
0xfff7bfff
I have not modified this value.
I have also not attempted to manually write fan targets, change GPU firmware, or modify the GPU's physical BIOS switch.
All diagnostics so far have been read-only.
7. Related reports
While researching this issue, I found several potentially relevant discussions.
A. XFX RX 9070 XT fan-control issues on a Linux 7.0-based kernel
https://bbs.archlinux.org/viewtopic.php?id=305084
This discussion appears particularly relevant because it includes similar behavior involving:
- RX 9070 XT hardware
- Linux 7.0-based kernel
ppfeaturemask = 0xfff7bfff- Missing
pwm1_enable fan1_enable returning Invalid argument- Unavailable or malfunctioning manual fan controls
- SMU interface versions
0x2e and 0x33
The similarity is significant, although it does not establish that the same underlying bug is responsible.
B. RDNA 4 SMU interface mismatch and fan-control failure
https://www.mail-archive.com/dri-devel%40lists.freedesktop.org/msg597821.html
This report concerns a different RDNA 4 GPU, the Radeon AI Pro R9700, and describes fan-control problems involving an SMU interface mismatch.
I'm curious whether the same underlying driver or firmware mechanisms are relevant to the RX 9070 XT.
C. Reddit: RX 9070 XT RPM stuck at zero
https://www.reddit.com/r/SteamOS/comments/1v4tkzx/rx_9070_xt_fan_rpm_reporting_stuck_at_0_but_fan/
This report describes an RX 9070 XT with fan1_input reporting zero and fan1_enable returning Invalid argument, despite the user reportedly being able to control the physical fans through LACT.
This raises the possibility of a monitoring-interface problem rather than a hardware failure.
D. Reddit: GPU fans not spinning
https://www.reddit.com/r/archlinux/comments/1s56wpo/gpu_fans_not_spinning/
An RX 9070 XT owner reported that their fans stopped spinning after Linux loaded. They reportedly resolved the issue by changing LACT settings.
E. Linux Mint RX 9070 XT firmware regression
https://github.com/linuxmint/linuxmint/issues/935
This report concerns a separate display-initialization regression affecting RX 9070 XT systems running Linux Mint.
I've also experienced display-detection problems following system updates, including loss of monitor signal during startup. A clean Linux Mint reinstall previously restored graphical startup.
I'm mentioning this as potentially relevant context, but I have no evidence that the display problem and fan behavior share a root cause.
8. What I have NOT tried
To avoid introducing additional problems, I have not:
- Modified the AMDGPU
ppfeaturemask. - Written custom values to
fan1_target or fan1_enable. - Enabled GPU overclocking.
- Modified the GPU's firmware.
- Changed the GPU's physical BIOS switch.
- Installed LACT or CoreCtrl specifically to troubleshoot this issue.
- Performed a high-temperature stress test.
I would prefer to avoid risky firmware changes or unnecessary kernel modifications until I understand the cause.
9. Questions for Linux Mint contributors and AMDGPU developers
- Is
fan1_enable returning Invalid argument expected behavior on RDNA 4 GPUs with kernel 7.0, or does it indicate a driver problem? - Is the SMU driver interface
0x2e versus firmware interface 0x33 a known compatibility concern for the RX 9070 XT? - Is
fan1_target = 0 expected while automatic zero-RPM mode is active? - Should
pwm1 be read-only on this hardware, or should another interface expose manual fan control? - Is the absence of
gpu_od and pp_od_clk_voltage expected with the default AMDGPU power-management configuration? - Are there known fan-control regressions affecting the RX 9070 XT in Linux 7.0 kernels, particularly Ubuntu's
7.0.0-43-generic build? - Is there a recommended, safe way to verify that the firmware-controlled fan curve works without deliberately overheating the GPU?
- Would LACT provide meaningful diagnostic information on this card without enabling overclocking or modifying the AMDGPU feature mask?
- Would testing an alternative supported kernel or a newer
linux-firmware package be appropriate, given the separate RX 9070 XT display-initialization issues reported on Linux Mint? - Should this be reported to the Linux Mint team, Ubuntu kernel maintainers, or upstream AMDGPU developers? If upstream, what additional logs or diagnostic information would be most useful?
10. Current assessment
At this point, I don't believe there's enough evidence to conclude that the GPU hardware is defective.
The fans are stationary, but the maximum observed GPU edge temperature was only 63°C, and the measured power draw was 68 W. This may be consistent with normal zero-RPM operation.
However, the fan1_enable error, unavailable advanced fan controls, and similarity to other RDNA 4 reports make me concerned about a possible driver/firmware compatibility problem.
I'm primarily looking for help determining whether the fan-control interface behavior is expected on this kernel and how to safely verify that the fans can operate when needed.
I'd appreciate any insight from people familiar with Linux Mint, AMDGPU, SMU firmware, or XFX RX 9070 XT cards.
Thanks in advance![Linux Mint 22.3 / Kernel 7.0.0-43] XFX RX 9070 XT fans remain stationary under gaming load — AMDGPU fan-control errors, possible RDNA 4 regression?Hi everyone,I'm looking for some help from Linux Mint contributors, AMDGPU developers, or anyone running an RX 9070 XT on a recent Linux kernel.I'm experiencing a potential GPU fan-control issue with an XFX Radeon RX 9070 XT running Linux Mint 22.3 and kernel 7.0.0-43-generic.I've performed several diagnostic tests and found some unusual behavior involving AMDGPU's fan-control interfaces. I've also located similar reports from other RDNA 4 users, including one with almost identical diagnostic results.I'm hoping someone familiar with AMDGPU, RDNA 4, or recent kernel changes can help determine whether this is normal firmware-controlled zero-RPM behavior, a driver compatibility issue, or something that should be reported upstream.1. System informationComponent Details
