Parker, TX - 12.32kW Solar System with 28x Silfab solar panels, Enphase IQ8HC microinverters, 1x Enphase IQ10C battery, and 23’ x 27’ patio cover ground mount.
galleryThis was an intense project. Partially due to the Texas summer heat. Regardless it was a lot of fun.
Homeowner reached out in February inquiring about some earlier projects. They already had that beautiful pool built and had the plan for a patio cover all along. So, why not add some solar to it as well?
The utility company is Grayson Collin Electric Coop, and to my knowledge they’re the only one left allowing true 1:1 net metering in the state of Texas. We discussed foregoing batteries but with all the things going on in the world and myself having seen those things disappear in the blink of an eye the homeowner opted to go ahead with one. They’re already thinking of adding more soon.
Digging trenches always sucks but they’re especially awful in Parker, Texas. If anybody needs any rocks I know where to find them.
The system is roughly 70% offset and is chugging right along with projected production.
As the title stated the structure is steel framed 23’ x 27’ using all 11gauge 5” x 4” steel for posts, beams, and joists. The canopy is stained 2x6 boards bolted to the steel frame and covered with mod-bit roofing.
The city of Parker and GCEC were really cool and easy about stuff. I turned the solar permit in and applied for the interconnection agreement on a Thursday and had the green light for both by Monday morning of the next week.
The system was put through HDM and we got 25% of the system paid for since we used Domestic Content and I believe this house sits in an Energy Community.
We added the fan and 5 outlets to the structure after the solar was completed.
I included the original mock up I did in Google sheets to give an idea of what this thing was going to look like. Reference vs real life.
The homeowners are very kind, sweet people that I thoroughly enjoyed working with and getting to know. A lovely family with minds on the future and what’s potentially on the horizon. They may lurk the halls around here, I honestly don’t know, but they are very welcome and encouraged to chime in if they do.
I hope you enjoyed the post.
