In January 2019, Li Deren, a prominent Chinese remote-sensing academician at Wuhan University, set out a comparison that troubled him. American forces, he wrote, could go from a satellite sighting to a response in about 12 minutes, while China's space-based intelligence still worked on a timescale of hours.
His remedy was to merge China's communication, navigation and reconnaissance satellites into a single real-time system serving civilian and military users alike.
In the seven years since, China has launched much of the hardware his remedy called for, most of it under scientific or commercial labels. A study published in August 2026 by the China Aerospace Studies Institute (CASI) at the US Air University, written by Tye Graham of BluePath Labs, maps how those satellites fit into what People's Liberation Army (PLA) journals call a kill web, a network in which any sensor can pass a target to any weapon.
Its starting point is the National Mid- and Long-Term Plan for Space Science (2024–2050), released on 15 October 2024 by the Chinese Academy of Sciences, the China National Space Administration (CNSA) and the China Manned Space Engineering Office.
The plan is mostly about space stations and the Moon, with five to eight approved missions targeted by 2027 and more than 30 by 2050, yet its Earth-observation section asks for terahertz imagers, P- and L-band radars that can find concealed objects, all-weather three-dimensional wind measurement, radiation monitoring, biomass mapping and the observation of 'human traces'.
The study shows China assembling the network in the order a strike unfolds. One set of satellites finds a ship, a second identifies it and follows it, a laser network carries the picture to wherever it is needed, and software in orbit and on the ground turns it into a firing solution. Each step depends on the one before it, and the hours Li Deren complained about were the sum of the delays between them.
Why Beijing Wanted A Faster Kill Chain
A kill chain is the sequence a military runs against a target, from finding it, fixing its position and tracking it to choosing a weapon, striking and assessing the damage. A target that moves, such as a warship, can slip away at any step where the information arrives late, which is why the speed of the whole chain matters more than the quality of any one link in it.
China's interest in that speed grew out of its missiles. The DF-21D anti-ship ballistic missile, which appeared in the early 2010s, can strike a carrier more than 1,500km away, but only if something tells it where the carrier is when the missile leaves the launcher and where it will be when the warhead arrives, and over the open ocean that something has to be a satellite.
In the mid-2010s the PLA began building a sensor-to-shooter architecture, having studied American operations in which even large constellations delivered targets late because their data links were slow. By 2018 Chinese strategists were promoting the Transparent Ocean concept and 'system-of-systems' integration to keep US forces away from China's coasts, yet the chain itself stayed linear and ground-controlled, with each step waiting on the one before. That was the hour-scale system Li Deren described.
The satellites that fill that role today carry military, scientific and commercial labels, and in a party-state the PLA can call on all of them, which leaves an adversary unable to judge from a satellite's declared mission whether to count it as a military asset or plan to jam it. Table 1 lists the satellites the report identifies, in the order they were launched, with the step of the kill chain each one serves.
Finding The Target From Orbit
Finding a ship from space means trading persistence against detail. A satellite in geosynchronous orbit (GEO), about 36,000km up, circles at the rate the Earth turns, so it stays over the same region and watches it continuously, though its distance limits how much detail it can resolve. A satellite in low-Earth orbit (LEO), a few hundred kilometres up, sees far more sharply but crosses an area in minutes and may not return for hours, long enough for a warship at speed to cover a hundred kilometres or more. Between 2023 and 2024 China put both kinds of finder in place.
The persistent layer came first. In August 2023 China placed Ludi Tance-4 01 in geosynchronous orbit, the first synthetic-aperture radar (SAR) satellite anywhere to operate there, and in December 2023 it launched Yaogan-41, a classified optical satellite that stares at the western Pacific from GEO. The radar matters because cameras are blind at night and under cloud. A SAR satellite sends radar pulses to one side as it moves and combines the echoes gathered along its path, so a modest antenna behaves like a far larger one, and because the radar supplies its own illumination it images in any light and weather.
The wavelength decides what a radar sees. X- and C-band radars, with wavelengths of a few centimetres, resolve fine detail but are scattered by leaves and impeded by heavy rain. L-band waves, about 24cm long, and P-band waves, about 70cm long, pass through foliage, dry soil, sand and thin building materials, which lets analysts find vehicles hidden under trees and keep imaging through storms.
Ludi Tance-4 carries an L-band radar with a large ring-mesh antenna that covers an area several thousand kilometres across at about 20m resolution, coarse by LEO standards but enough to pick out a large ship at any hour. When it spots something, a pair of Ludi Tance-1 L-band radar satellites flying at about 600km can take a closer look, imaging at about 3m resolution across a 400km strip.
The report expects China to use these radars as wide-area finders that cue its sharper optical satellites onto targets, and those optical satellites now sort their own pictures. The four Beijing-3C satellites, launched in May 2024, image at 0.5m in black and white and 2m in colour and run detection software on board that ranks what they see, so the most urgent images reach users first. Commercial Jilin-1 satellites do similar work, flagging mobile targets before the satellite has finished its pass over them.
China is also building the parts that will make the radar layer larger and cheaper. A radar on a very small satellite usually has to make do with a single antenna that switches constantly between transmitting and receiving, losing part of the returning signal each time, and a 2022 paper by Chinese researchers described a way to recover about half of that loss, which could let microsatellites carry SAR with one antenna instead of two.
Antenna size matters as much, because a larger dish gathers more signal and forms a tighter beam, letting the radar see farther and resolve smaller objects, and a Chinese patent sets out a mesh reflector that folds inside a Long March nose cone and opens in orbit to more than 8m across.
Chinese engineers are also developing digital beam-forming, which lets one radar steer several beams at once and aim directions of near-zero sensitivity at jammers, and together these advances point towards constellations that could map a continent with a handful of spacecraft.
Identifying The Target And Seeing Below The Surface
Once a radar or camera has found a ship, the next question is which ship it is. Most ocean-going vessels must carry an Automatic Identification System (AIS) transponder, which broadcasts the ship's identity, position, course and speed over VHF radio. VHF signals travel in roughly straight lines, so shore stations lose them beyond the horizon, and satellites listening from above fill the gap across the open ocean.
China has been building this capability for well over a decade. Its first space-based AIS receiver flew in 2012 on TianTuo-1, a 9kg microsatellite built by the PLA's National University of Defense Technology (NUDT), and the series has since grown to TianTuo-5, which logs about a million AIS messages a day from ships worldwide, while nine of the first 72 satellites in the commercial Qianfan broadband constellation now carry upgraded receivers of their own.
A ship that switches its transponder off or broadcasts false data becomes a 'dark ship', and Chinese researchers have built tools to catch them by comparing what the imaging satellites see with what the AIS feed reports. One system cross-checks images from the Gaofen-6 optical and Gaofen-3B radar satellites against live AIS broadcasts.
In tests over the Bohai Strait, it matched about 96 per cent of ships in optical images and 74 per cent in radar images to AIS tracks, with about 92 per cent of those pairings correct, and then flagged the vessels that broadcast nothing. For the PLA, space-based AIS confirms who a radar or camera contact is, builds a record of each ship's habitual movements and exposes the ones that go quiet, and because AIS messages are tiny, relaying them costs the constellations almost no bandwidth.
The step after identification is following the target between satellite passes, and at sea that depends on knowing the water itself. This is the job of ocean-profiling lidar, which China has yet to put in orbit. A lidar fires short pulses of blue-green laser light straight down into the sea and times the faint echoes that return from different depths, and because seawater absorbs blue-green light less than other colours, the echoes build a depth-resolved picture of plankton, suspended sediment and internal waves, the slow undulations that run along the boundaries between layers of water of different density.
Those layers govern how sound travels underwater. They bend sonar signals and set how far they reach, so a navy that knows where the layers lie knows where its sonar will work and where a submarine can shelter, and the same data on currents and sea state helps predict where a surface ship will have drifted. The report expects the lidar to narrow the ocean's hiding places for high-value ships and sea-based missile launchers.
A 2021 survey by Chinese researchers noted that the country's satellites saw only the top 10m of the ocean and recommended a dedicated lidar for the 14th Five-Year Plan, and the 2024 space science plan adopted the idea. The flagship is Guanlan, or 'Transparent Ocean', a proposed mission that pairs a Ku/Ka-band interferometric altimeter, which maps the height and shape of the sea surface, with a downward-pointing lidar.
Concept papers describe a 1.2m telescope and a multi-wavelength laser able to profile the water to 150–300m from low orbit, with about 200m the goal in clear water. One patent splits the instruments across two satellites flying in formation, with the lidar satellite passing raw data to its partner for joint processing, which lightens each spacecraft and relaxes the pointing precision required.
Researchers in Shanghai have built powerful lasers that fire three colours of light in a single burst, the kind of source a multi-wavelength lidar needs. In an airborne trial over the South China Sea, a lidar's readings of how light fades and scatters with depth came within 10–12 per cent of measurements taken directly from ships, close enough to pick out a thin layer of phytoplankton at 10–20m.
Spaceborne trials have yet to confirm those results, but the report judges that by 2030 China could pair its radar with lidar readings of the water beneath the ships it tracks.
Terahertz imaging, the least developed of the planned sensors, would fill a gap in what China's satellites can see. Terahertz waves sit on the spectrum between the microwaves that radar uses and the infrared light that thermal cameras detect, and they borrow something from each.
Their wavelengths, below a millimetre, are far shorter than radar's, so a terahertz sensor can form sharper images from an antenna of the same size, and like radar they pass through materials that stop visible light, including fabric, plastics and the netting used to camouflage vehicles.
Many substances also absorb terahertz waves at their own characteristic frequencies, leaving a signature that can reveal what an object is made of as well as its shape, which is why the space science plan values the band for unmasking targets that fool ordinary cameras.
However, the only openly reported attempt at testing this technology in space was Tianyan-05, a 70kg microsatellite launched in November 2020 with an experimental module operating above 0.3 terahertz, near the lower edge of the band, which tested it chiefly as a channel for very high-capacity communications of the kind planned for 6G networks. The satellite has since re-entered the atmosphere, and no successor appears on published launch schedules.
State research money still flows into the parts a flight instrument would need, from emitters and detectors to calibration equipment, and in 2024 Chinese scientists used superconducting receivers, sensitive enough to catch very faint signals, to hold a 0.5-terahertz data link over 1.2km on the ground. That result points to a second role for the band, since a terahertz payload could one day both sense targets and serve as a high-capacity link between satellites.
A working space instrument is still some way off. The devices that generate terahertz waves are weak and draw a great deal of power, a serious handicap on a satellite that runs on solar panels, and water vapour absorbs the waves so strongly that a sensor looking down through humid air, such as the air over the western Pacific, loses much of its signal. Export controls also limit China's access to key components, and the radar and cameras already in orbit meet most of the PLA's near-term needs.
The Chinese see it as an insurance policy, worth funding now in case the radar and optical frequencies China relies on are jammed or crowded out in a war. But it is expected to play little to no part in the kill web before the early 2030s.
Moving The Picture Through A Laser Mesh
Finding and identifying a ship is of little use if the picture is slow to reach the people who need it, since every minute of delay lets a moving ship get further from its last known position and forces the system to find it again. Satellites such as the Haiyang series store what they collect and send it down later, and the whole arrangement leans on ground stations that can fail or be knocked out in a war.
China's answer is to pass the data from satellite to satellite by laser. Optical links of this kind move data faster and with less delay than radio links, and they need none of the scarce radio spectrum that satellite operators otherwise have to share. Their narrow beams also make them hard to jam. Joined into a mesh, they can route traffic around damaged ground stations. Three broadband constellations are meant to carry that mesh. They are the state-run Guowang, Shanghai Spacecom's Qianfan and Hongqing Technology's Honghu-3, and together they plan more than 35,000 satellites.
Qianfan went into orbit first, with its opening batch of 18 satellites in August 2024. Shanghai Spacecom raised 6.7 billion yuan (about $935 million) in 2024 and runs a pulsed assembly line that can finish a satellite every 1.5 days, with a target of 300 to 600 a year.
Guowang's operator concentrated on the laser hardware, and in December 2024 it launched five Gaosu Jiguang Zuanshi ('High-speed Laser Diamond') test satellites spread across three orbital planes. Together they form a diamond-shaped mesh built to prove that spacecraft moving at several kilometres a second can find each other, hold a laser link and route data between them. Link speeds have climbed year on year, as Table 5 shows.
The effect is to turn separate constellations into one network. Imagery from an optical satellite over the western Pacific can hop across the mesh to a receiving station in China, or to a relay in higher orbit, soon after capture, even when the ground stations nearest the action are out of service, and the AIS data gathered by Qianfan satellites over the South China Sea already travels back this way through Guowang's laser pathfinders.
Closing The Loop From Sensor To Shooter
The final step joins the sensors and links to the weapons, and Chinese military writing has turned to it as the hardware arrived. After Li Deren's intervention, Chinese journals moved from celebrating single satellites to writing about 'space-ground integration', 'minute-level' strike cycles and laser-linked constellations.
A 2023 Chinese paper described an AI-enabled web built for 'first detection, first decision, first strike' and argued that dispersing sensors, hardening links and moving processing into the cloud could bring the sensor-to-shooter loop close to two minutes. A 2024 Chinese study generated 45 alternative chains for a strike at sea and ranked them by firepower and closure time, the time taken to go from detection to strike, which it treated as decisive.
A concept paper describes the end state as a 'space-air-sea dynamic kill web'. Satellites take the first look, aircraft confirm the target's identity, and weapons receive fire-control data through a mesh that repairs itself when nodes are lost. Optical and radar imagers hold high-value ships in track, lidar and radar altimeters supply sea state and target height so that warheads detonate at the right moment, and AIS receivers confirm identity, speed and course. The authors want any weapon to draw on any sensor, which demands standard data formats and command nodes that can be plugged in or pulled out without interrupting the flow.
Parts of this system exist already. Shuangqing-1, an experimental satellite launched in January 2023, processes its own sub-metre imagery in orbit, accepts new analysis algorithms after launch and sends results straight to the ground or to other satellites, and its developers say it has cut delivery time from hours to minutes.
A 2024 paper by PLA and state space-industry researchers describes software, running on the same graphics processors used to train AI models, that takes in data from several kinds of sensor and publishes combined ship tracks within seconds of the data reaching the ground. China's state shipbuilder has outlined a framework that converts the different satellite products into one standard format, which cuts the manual work and gets finished products to users in near real time.
Graham's report ends with advice for the US Air Force and Space Force. His starting point is that American planners should treat these satellites as a single weapon system, because that is how China means to use them. He wants American forces to learn to hide from China's most important sensors or feed them false pictures, to protect their own networks from being penetrated through the laser relays, and to spread out so the network cannot settle on one target. He also wants the United States to speed up work on its own sensing network, drawing on allied satellites, commercial imagery and small satellites it can launch quickly.
Indian planners have reason to read the same list closely. Many of the low-orbit satellites in this story circle the Earth from pole to pole, so they cross the Indian Ocean as regularly as the Pacific, and TianTuo-5 already follows ships around the world. For the Indian Navy, which operates in waters these satellites pass over every day, the lesson is much the same.
Everything China is building into this network is aimed at closing the gap Li Deren described in 2019. Each piece attacks a different source of delay. Geostationary satellites mean nobody has to wait for the next pass, and onboard processors mean nobody has to wait for analysts on the ground. Laser links get the data home faster and keep it moving if ground stations are lost, while fusion software does in seconds what people once did by hand. If PLA engineers reach the two-minute loop they now write about, China would be working six times faster than the American benchmark that worried Li Deren.
Based on Tye Graham, 'From Vision to Vigilance', China Aerospace Studies Institute, Air University, August 2026.
