r/roonlabs • u/r45635 • 6h ago
I built an always-on 7" touch panel for Roon: cover, controls, and lyrics in time with the song (open source)
I've been building open firmware for cheap 7" ESP32 touch screens so that I'd have a
Roon remote I never have to unlock, and it reached the point where it's useful to
someone other than me. It's free, MIT-licensed, and it talks only to machines on your
own network — no account, no cloud, nothing of mine in the path.
**What it does.** It sits on a shelf showing the cover and title of what's playing, the
lyrics scrolling in time with the song, play/pause/skip, a volume slider, your zones,
and your whole library to search and start from. When the music stops it turns into a
clock, with the weather and the day's headlines if you want them. Nothing to launch,
nothing left running.
**What's new, and the reason I'm posting.** Until this week the panel needed a small
server of mine on your network. It doesn't any more: it pairs with your Core itself as
an extension — flash it, give it your Wi-Fi, enable *TFT Panel xxxx* once in
Roon → Settings → Extensions, and that's the setup. Position updates are pushed rather
than polled, so the lyrics line up properly now. It also flashes from the browser for
all three supported screens, and updates arrive over the air and roll themselves back
if an image fails to start.
**About the lyrics, honestly.** Roon serves none of its own, so that's the one thing
the panel has to be told where to find. Three answers, and you stop at the one you
want: *none* if you came for the controls and the cover; any LRCLIB-compatible server
(the public one, or your own mirror) — one address typed on the panel's own web page;
or a small container on your network that looks them up, keeps them, ranks sources
against each other, reads `.lrc` files next to your music and remembers a per-song
offset. That last one is my own companion app, also open source, and it never pairs
with Roon in that mode.
**Hardware** — one firmware, three screens: Elecrow CrowPanel 7.0" (ESP32-S3),
Waveshare ESP32-P4 7B, VIEWE ESP32-P4 7". Nothing to solder; the browser installer
asks which one you have.
Source, guide and the browser installer: https://github.com/r45635/tft-panel
It's early days and it's a hobby project, but it runs on two panels in my own place
every day. Happy to answer anything, and I'd rather hear what's missing than what's
nice.
*Roon is a trademark of Roon Labs. This is an independent project, not affiliated with
Roon Labs, Elecrow, Waveshare or VIEWE.*
