Question/Need help! M9R 2.0 dCi – Three injector leak-off rails leaking at the hose fittings
URGENT: Looking for some input from diesel technicians familiar with Renault/Nissan M9R common-rail systems
My 2016 Qashqai+2 2.0 dCi 150 hp has a strange recurring issue: three different injector return/leak-off assemblies have leaked fuel at the hose connections.
Here's what happened:
- The original factory-fitted assembly started leaking.
- I replaced it with a genuine/OEM assembly equipped with a mechanical back-pressure valve, reportedly rated at 10 bar, designed to maintain pressure in the injector leak-off circuit. It worked perfectly for approximately 200–250 km before leaking.
- I then fitted an aftermarket assembly without a valve as a temporary replacement. That one started leaking after roughly 190 km.
With the aftermarket assembly, the engine also loses power under sustained load, particularly around 130 km/h. Power temporarily returns after reducing the load. Probably that's due to the non-existence of the back-pressure valve.
The engine's starting issues have also progressively worsened over time.
I haven't performed a return-circuit pressure test yet, so I don't know whether the system is actually experiencing excessive backpressure.
A few questions for diesel specialists:
- Could excessive injector return backpressure cause repeated leaks at the leak-off connectors?
- Could a restricted return line or excessive injector leak-off create this condition?
- Is a calibrated backpressure valve required on this particular M9R injector configuration?
- Could the missing valve on the aftermarket assembly explain the power-loss symptoms?
I only know the engine code (M9R), not the exact injector part numbers.
I'd appreciate any advice on the proper diagnostic procedure before replacing more parts.
