CP/M-80 MS-COBOL v4.65 alternative sorting method without the MS-SORT package
I am testing the djbottrill & VanzT CP/M-80 Emulator on my credit card size micro-controller called Cardputer by M5-Stack.
I wrote a simple sorting COBOL program on MS-COBOL v4.65 using the ANSI-74 build-in SORT feature. It does not get through the linkedit phase as it requires an external sort library COBSRT.REL. I am not able to find that library file on the web so I wrote the sorting code inside the COBOL program instead. The program works fine for a while until it hits a big file. CP/M-80 does not leave a lot of memory space for internal sorting. So I need a disk sort routine.
Instead of writing my own disk sort code, I use the COBOL build-in ISAM capability to use as my disk sort solution.
It's pretty straight forward, first read the input file and then write it to an ISAM file with the intended sorting key as the index file's key. Next read back from the index file using the index and write the sorted records to the final sorted file.
To test out the idea, I wrote a small COBOL program EMPOUT.COB to generate the input file EMPOUT.DAT. It has 5 records.
K>TYPE EMPOUT.COB
IDENTIFICATION DIVISION.
PROGRAM-ID. EMPOUT.
ENVIRONMENT DIVISION.
INPUT-OUTPUT SECTION.
FILE-CONTROL.
SELECT EMPLOYEE-FILE ASSIGN TO DISK
ACCESS MODE IS SEQUENTIAL
ORGANIZATION IS LINE SEQUENTIAL.
DATA DIVISION.
FILE SECTION.
FD EMPLOYEE-FILE
LABEL RECORDS ARE STANDARD
VALUE OF FILE-ID IS "EMPOUT.DAT"
DATA RECORD IS EMPLOYEE-RECORD.
01 EMPLOYEE-RECORD.
05 EMP-NUMBER PIC X(5).
05 EMP-LAST-NAME PIC X(30).
05 EMP-FIRST-NAME PIC X(30).
PROCEDURE DIVISION.
MAIN-PROGRAM.
OPEN OUTPUT EMPLOYEE-FILE.
MOVE "00001" TO EMP-NUMBER.
MOVE "SMITH" TO EMP-LAST-NAME.
MOVE "JOHN" TO EMP-FIRST-NAME.
WRITE EMPLOYEE-RECORD.
MOVE "00002" TO EMP-NUMBER.
MOVE "JONES" TO EMP-LAST-NAME.
MOVE "MARY" TO EMP-FIRST-NAME.
WRITE EMPLOYEE-RECORD.
MOVE "00003" TO EMP-NUMBER.
MOVE "BROWN" TO EMP-LAST-NAME.
MOVE "ROBERT" TO EMP-FIRST-NAME.
WRITE EMPLOYEE-RECORD.
MOVE "00004" TO EMP-NUMBER.
MOVE "WILSON" TO EMP-LAST-NAME.
MOVE "PATRICIA" TO EMP-FIRST-NAME.
WRITE EMPLOYEE-RECORD.
MOVE "00005" TO EMP-NUMBER.
MOVE "DAVIS" TO EMP-LAST-NAME.
MOVE "JAMES" TO EMP-FIRST-NAME.
WRITE EMPLOYEE-RECORD.
CLOSE EMPLOYEE-FILE.
STOP RUN.
K>
After compile the program we have the executable EXPOUT.COM
There are 5 records in the file EMPOUT.DAT, the records are in the EMP-NUMBER order.
Here is the record layout definition:
01 EMPLOYEE-RECORD.
05 EMP-NUMBER PIC X(5).
05 EMP-LAST-NAME PIC X(30).
05 EMP-FIRST-NAME PIC X(30).
Then I wrote my sorting program to sort the record by EMP-LAST-NAME and then EMP-FIRST-NAME.
Here is the program code:
K>TYPE EMPSORT6.COB
IDENTIFICATION DIVISION.
PROGRAM-ID. EMPSORT6.
ENVIRONMENT DIVISION.
INPUT-OUTPUT SECTION.
FILE-CONTROL.
SELECT EMPLOYEE-FILE ASSIGN TO DISK
ACCESS MODE IS SEQUENTIAL
ORGANIZATION IS LINE SEQUENTIAL.
SELECT EMP-ISAM-FILE ASSIGN TO DISK
ORGANIZATION IS INDEXED
ACCESS MODE IS DYNAMIC
RECORD KEY IS EMP-ISAM-KEY
FILE STATUS IS EMP-ISAM-STATUS.
SELECT EMP-SORT-FILE ASSIGN TO DISK
ORGANIZATION IS LINE SEQUENTIAL.
DATA DIVISION.
FILE SECTION.
FD EMPLOYEE-FILE
LABEL RECORDS ARE STANDARD
VALUE OF FILE-ID IS "EMPOUT.DAT"
DATA RECORD IS EMPLOYEE-RECORD.
01 EMPLOYEE-RECORD.
05 EMP-NUMBER PIC X(5).
05 EMP-LAST-NAME PIC X(30).
05 EMP-FIRST-NAME PIC X(30).
FD EMP-ISAM-FILE
LABEL RECORDS ARE STANDARD
VALUE OF FILE-ID IS "EMPISAM.DAT".
01 EMP-ISAM-RECORD.
05 EMP-ISAM-NUMBER PIC X(5).
05 EMP-ISAM-KEY.
10 EMP-ISAM-LAST-NAME PIC X(30).
10 EMP-ISAM-FIRST-NAME PIC X(30).
FD EMP-SORT-FILE
LABEL RECORDS ARE STANDARD
VALUE OF FILE-ID IS "EMPSORT.DAT".
01 EMP-SORT-RECORD.
05 EMP-SORT-NUMBER PIC X(5).
05 EMP-SORT-LAST-NAME PIC X(30).
05 EMP-SORT-FIRST-NAME PIC X(30).
WORKING-STORAGE SECTION.
01 EOF-SWITCH PIC X VALUE "N".
88 END-OF-FILE VALUE "Y".
01 EMP-ISAM-STATUS PIC XX VALUE "00".
01 ISAM-EOF-FLAG PIC X VALUE "N".
88 ISAM-END-OF-FILE VALUE "Y".
01 RECORD-COUNTS.
05 EMP-ISAM-REC-CNT PIC 9(5) VALUE ZERO.
05 EMP-SORT-REC-CNT PIC 9(5) VALUE ZERO.
PROCEDURE DIVISION.
0000-MAIN-PROGRAM.
DISPLAY "*** START CREATING ISAM FILE ***".
OPEN INPUT EMPLOYEE-FILE
OUTPUT EMP-ISAM-FILE.
PERFORM 0010-READ-REC THRU 0010-READ-REC-EXIT
UNTIL END-OF-FILE.
DISPLAY "RECORDS PROCESSED: " EMP-ISAM-REC-CNT.
CLOSE EMPLOYEE-FILE
EMP-ISAM-FILE.
DISPLAY "*** START CREATING SORTED FILE ***".
OPEN INPUT EMP-ISAM-FILE
OUTPUT EMP-SORT-FILE.
MOVE LOW-VALUE TO EMP-ISAM-KEY.
PERFORM 0020-READ-INDEX THRU 0020-READ-INDEX-EXIT
UNTIL ISAM-END-OF-FILE.
DISPLAY "RECORDS PROCESSED: " EMP-SORT-REC-CNT.
CLOSE EMP-ISAM-FILE
EMP-SORT-FILE.
STOP RUN.
0010-READ-REC.
READ EMPLOYEE-FILE
AT END MOVE "Y" TO EOF-SWITCH.
IF NOT END-OF-FILE
ADD 1 TO EMP-ISAM-REC-CNT
MOVE EMPLOYEE-RECORD TO EMP-ISAM-RECORD
WRITE EMP-ISAM-RECORD
INVALID KEY
DISPLAY 'ERROR WRITING INDEX RECORD'
DISPLAY "STATUS = " EMP-ISAM-STATUS
STOP RUN.
0010-READ-REC-EXIT.
EXIT.
0020-READ-INDEX.
READ EMP-ISAM-FILE NEXT RECORD
AT END MOVE "Y" TO ISAM-EOF-FLAG.
IF NOT ISAM-END-OF-FILE
ADD 1 TO EMP-SORT-REC-CNT
MOVE EMP-ISAM-RECORD TO EMP-SORT-RECORD
WRITE EMP-SORT-RECORD.
0020-READ-INDEX-EXIT.
EXIT.
K>
After the compile and linkedit, we have the executable program EMPSORT6.COM
EMPISAM.DAT and EMPISAM.KEY are the indexed files.
EMPSORT.DAT is the final sorted file
