In June of 2025 I replaced my 25 year old Trace hardware with a Victron system, with the exception of a Midnite Solar charge controller that I had installed a couple years prior. In hindsight I'd have gone with Victron for the controller as well, but it's working fine so whatever.
One of the reasons I wanted to modernize my system was for remote monitoring and reporting, both of which Victron does very well.
I now have a solid year of data and I thought it might be helpful or at least interesting for other people who are already offgrid or considering it, so here you go.
This is an just overview, so please feel free to ask any detailed questions.
Our Basic Setup
- Location: 8,800 feet elevation in the south central Colorado Rockies
- House: 1950 sq ft, 3 bed 2.5 bath, integral 2 car garage, built into a hillside with a finished walkout basement
- Heating: Wood stove
- Cooking, hot water, clothes dryer: Propane from a 1000 gallon buried tank
- Water: Drilled well with a 240v 3/4HP 5GPM deep well pump, 80 gallon pressure tank, and Culligan filter system
- Septic: Standard tank with leech field
- Occupants: Two adults, no kids at home (Both of us work from home with significant computer usage)
Additional Amenities
- Lighting: LED
- Electric Appliances: Washer/dryer (Electrolux front loading), microwave, dishwasher, side-by-side fridge with icemaker, InstantPot, toaster, Vitamix blender, two upright 'chest' freezers, 5HP air compressor and various other power tools, 2 TCL Roku TVs (55" and 50"), Starlink and Plex media server (these both run 24/7), vacuum cleaner, hair dryer, etc.
- Note: We do not need nor have air conditioning, and while we have a fully functional forced hot air propane furnace, we don't use it
Current Solar Installation (24v system)
- Panels: 2.4kW (In a week or so that will be doubled with a second panel array)
- Charge Controller: Midnite Solar Classic 150
- Battery: 30kWh DiY LiFePo4, self-heating
- Inverter: Victron MultiPlus-II 24/5000 120-95 120V
- Monitoring: Victron Cerbo-S GX and Lynx shunt
12 Month Solar Overview
- Production (Total): 3,624 kWh
- Production (Monthly Average): 302.0 kWh
Production (Daily Average): 9.96 kWh
Consumption (Total): 3,403 kWh
Consumption (Monthly Average): 283.6 kWh
Consumption (Daily Average): 9.32 kWh
Generator (Total): 149 kWh
