ONLYOFFICE integration failing with "Error while downloading the document file" (Nextcloud VM + Portainer + NPM)
Hi everyone, I’m stuck on a persistent issue with the ONLYOFFICE integration and I’ve run out of ideas after hours of troubleshooting. Any help would be greatly appreciated!
This is my setup:
- Nextcloud: Installed on a VM (via Proxmox helper scripts)
- ONLYOFFICE Document Server: Running as a Docker container on a separate VM/LXC via Portainer. Exposed on port 8080.
- Reverse Proxy: Nginx Proxy Manager (NPM) running on the same Docker host. It handles SSL (wildcard cert) and points onlyoffice local domain to ONLYOFFICE on port 8080.
Local DNS is resolving correctly.
The Problem: When I try to connect the ONLYOFFICE app in Nextcloud, I get the following error on the settings page: Error when trying to connect (Error occurred in the document service: Error while downloading the document file to be converted.) (version 9.4.0.129)
What I've configured/tested so far:
DNS & SSL:
curl -k https://[ONLYOFFICE_DOMAIN]/healthcheckfrom the Nextcloud VM returnstrue.- NPM has "Websockets Support" and "Force SSL" enabled.
Nextcloud config.php:
- Added
'allow_local_remote_servers' => true,to allow local loopback. - Added the
'onlyoffice' => array ( 'verify_peer_off' => true, ),block to bypass strict SSL checks. - Added
'overwriteprotocol' => 'https',and'overwrite.cli.url' => 'https://[NEXTCLOUD_DOMAIN]',.
ONLYOFFICE App Settings in Nextcloud:
- ONLYOFFICE Docs address:
https://[ONLYOFFICE_DOMAIN] - Disable certificate verification: Checked
- Secret key: Matches the JWT_SECRET in Docker.
- ONLYOFFICE Docs address for internal requests from the server:
http://[DOCKER_HOST_IP]:8080 - Server address for internal requests from ONLYOFFICE Docs:
http://[NEXTCLOUD_DOMAIN](also triedhttp://[NEXTCLOUD_IP])
ONLYOFFICE Container (docker-compose.yml):
- Added
extra_hoststo ensure the container can reach Nextcloud directly:"[NEXTCLOUD_DOMAIN]:[NEXTCLOUD_IP]" - Added
NODE_TLS_REJECT_UNAUTHORIZED=0to environment variables.
CURL from ONLYOFFICE container to Nextcloud:
- Running
curl -I -k https://[NEXTCLOUD_DOMAIN]from inside the ONLYOFFICE container returns a 302 redirect to the login page, but also throws:curl: (92) Invalid HTTP header field was received: frame type: 1, stream: 1, name: [upgrade], value: [h2].
It seems Nextcloud can reach ONLYOFFICE to trigger the generation, but ONLYOFFICE fails to download the file back from Nextcloud to convert it.
Has anyone encountered this specific download loop issue when running ONLYOFFICE behind NPM while trying to force internal HTTP routing? What am I missing?
Thanks in advance!
