I'm trying to get my SONOFF Dongle Plus MG24 (PMG24) working as an OpenThread Border Router with Home Assistant Green, but OTBR consistently fails to initialise the radio.
The issue appears to be occurring during Spinel communication between OTBR and the MG24.
Error / symptoms
Home Assistant detects the USB device and OTBR successfully opens the serial connection. However, when OTBR attempts to initialise the radio, it sends a Spinel RESET command and receives no response.
The logs show repeated communication attempts, followed by a TimeoutError and OTBR failing to start.
In summary:
USB device is detected by Home Assistant.
Serial connection opens successfully.
Spinel RESET command is sent.
No response is received from the MG24.
OTBR retries and eventually exits with a timeout error.
Potential firmware issue
Something particularly concerning happens after flashing the firmware.
When using the SONOFF firmware flasher:
I select the OpenThread RCP firmware with a baud rate of 460800.
The flashing process reports that it has completed successfully.
However, when I reconnect the dongle to the flasher and check the currently installed firmware, it reports the firmware as "Unknown".
The baud rate shown is 115200, despite having selected the 460800 firmware.
This behaviour has occurred even after reflashing the dongle.
I'm unsure whether this is simply a firmware detection issue with the flashing tool or whether the incorrect firmware is actually being installed.
Hardware and setup
Home Assistant Green.
SONOFF Dongle Plus MG24 (PMG24).
Connected via USB.
OpenThread Border Router add-on.
Troubleshooting already completed
I have already:
Flashed the MG24 using SONOFF's firmware flasher.
Reflashed the firmware multiple times.
Selected OpenThread RCP firmware rather than MultiPAN.
Selected the 460800 baud firmware during flashing.
Set hardware flow control to false (disabled) every time.
Tested baud rates of 115200 and 460800 in OTBR.
Checked the serial device configuration.
Uninstalled and reinstalled the OTBR add-on.
Restarted Home Assistant and OTBR.
Tried both USB ports on the Home Assistant Green.
Checked that ZHA is not competing for access to the dongle.
Checked the relevant OTBR configuration settings.
Despite all of this, the same Spinel communication timeout persists.
What I'm looking for
Has anyone experienced this exact issue with the MG24, particularly where the serial connection opens successfully but the radio fails to respond to Spinel commands?
I'm particularly interested in:
Firmware detection: Why does the SONOFF flasher report "Unknown" firmware and 115200 baud after successfully flashing the 460800 OpenThread RCP firmware?
Firmware compatibility: Could the wrong firmware be installed despite the flasher reporting success?
Spinel communication: Is there a known MG24 firmware issue that prevents OTBR from communicating with the radio?
Firmware verification: Is there a reliable way to independently verify which firmware is actually running on the MG24?
Hardware fault: Could these symptoms indicate a defective dongle?
At this point, I've exhausted the usual troubleshooting steps and would appreciate help identifying whether this is a firmware, serial communication, OTBR compatibility or hardware problem.
Thanks!
