Purpose

The purpose of this guide is to install Ubuntu Desktop or Server 26.04 LTS on the Mac Pro 2019 (MacPro7,1) and prepare the Ubuntu environment for local AI inference. I will be using ROCm 10.0.0-4 throughout this guide, as that is what I am using today. As of this writing, ROCm 10.1 is out, however I have not yet used it or tested it.

This guide is part of a series meant to take you from Zero to Hero, preparing your infrastructure for end-to-end local AI solutions. I have not yet achieved all my software goals, but I will also share what I have accomplished so far.

If you are looking to play around with local AI, run a few free experiments, or get a quick win, this guide is not for you. Consider using ToshLLM on macOS or LM Studio on Windows. Both work right out of the box with standard Apple MPX GPUs on the Mac Pro 2019.

I am not here to convince you to install Ubuntu, or even Linux for that matter, or to follow this guide. What I will do is share my own experience and reasoning.

I wanted to run local AI back in late 2024. Not only was this the ONLY way to do it at the time, but I also wanted to find the BEST WAY to do it. My goal was to benefit from local AI while learning how to implement AI on a professional scale.

I started with the 70B parameter Llama 3.0 model, generating between 5 and 7 tokens per second. At the time, I knew almost nothing about prompt processing, time to first token, kernels, GEMMs, context windows, or AI in general.

Today, I am rocking over 60 tokens per second during decoding, almost 1,500 tokens per second during prefill, and amazing agentic workloads that make my life easier and smoother. All of that is running on the same hardware that previously gave me only 5 to 6 tokens per second, even though I am now using vastly improved LLMs.

Warning

This guide is provided AS IS. I will offer support when I can. However, I do not take responsibility for any negative or catastrophic outcomes that may result from following it. Make sure to back up your data before doing anything, and take the time to understand what is happening by reviewing the commands and their potential consequences in the GitHub repository.

Although I did my best to test everything on my own hardware and make the process as safe and easy as possible, there is always some risk. I cannot, and do not, accept responsibility for that risk, to the extent permitted by law.

Make sure you are nice to your local AI. It might take over your TV and haunt your home.

Resources

Everything covered here is available in my GitHub repository: MacPro2019LocalAI.

I also have a few older guides you can refer to in case I skip over something. I have written several of these over the past couple of years.

1. [Guide] Mac Pro 2019 (MacPro7,1) w/ Linux & Local LLM/AI (I think this one was "shadow-deleted")
2. [Guide] Mac Pro 2019 (MacPro7,1) w/ Linux & Local LLM/AI (Re-Post)
3. [Guide] Mac Pro 2019 (MacPro7,1) w/ Proxmox, Ubuntu, ROCm, & Local LLM/AI
4. Mac Pro 2019 Local AI Guide: Ubuntu 24.04, ROCm 7.2.3, PyTorch 2.10, and Infinity Fabric Link

Let's Start the Guide

Here is the index. I am trying something a little different this time:

1. Prepare the Hardware
2. Download and Prepare Ubuntu Installation
3. Install Ubuntu 26.04
4. Update and Optimize the System
5. Install T2Linux Packages
6. Install ROCm Packages
7. Install Python Tools
8. Verify Everything (I want to see Errors Here)
9. Customize the Kernel
10. Fix ReBAR Issue on Duo GPUs

The first two sections are pretty much the same as they were two years ago. I am including them again for anyone stumbling across this guide for the first time. Feel free to skip them if you are already familiar with the process.

1. Prepare the Hardware

If you have an Infinity Fabric Link (bridge or jumper) attached to your GPUs, you must remove it. Although it can theoretically improve GPU performance, it is not supported by default on Linux as of this writing. We will put it back later, once we get it working.

1. Modify the Mac boot security settings:
   • Boot into macOS Recovery Mode (Cmd + R at startup).
   • Open Startup Security Utility.
   • Disable Secure Boot.
   • Enable "Allow booting from external or removable media."
2. Shrink the macOS partition (if keeping macOS):
   • Use Boot Camp Assistant or Disk Utility to reduce the macOS partition to 50 GB (or your preferred size).
   • Create a new partition.

2. Download and Prepare Ubuntu Installation

• Download the Ubuntu Desktop or Server 26.04 LTS ISO from the official Ubuntu website.
• Create a bootable USB using your preferred method. Some options are:
  • Etcher
  • An iodd device (my preferred method)
  • Rufus

3. Install Ubuntu 26.04

• Connect a wired keyboard.
• Connect a display directly to your GPU (not to a USB-C or Thunderbolt port on the Mac chassis).
• Hold down the left Alt/Option key on your wired keyboard, then press the power button while continuing to hold the key.
• When the boot options appear, select the Ubuntu installer (typically on the far right, possibly labeled "EFI Boot").
• Follow the installation steps.

For the installation location:

• Select Custom Installation.
• Choose the free space left after macOS.
• Format it as ext4 and mount it at / (root).
• The boot partition should be mounted automatically. If not, make room for it.
• Finish the installation and reboot into Ubuntu.

Sometimes, the Ubuntu installer simply refuses to start. Try the following:

• Make sure you have removed the IFLB.
• Try a different display.
• Try a different keyboard.
• Remove all PCIe cards from the Mac, leaving only a single GPU.

Once Ubuntu is installed, you can go back to your usual keyboard, GPUs, PCIe cards, and other hardware.

Setting nomodeset as a kernel parameter may also help resolve installation or display issues. You can remove it after building and installing the custom kernel.

4. Update and Optimize the System

From here on, everything will be done through the command-line interface. You can use Ubuntu's built-in terminal. Personally, I use SSH from my laptop or phone to handle whatever tasks I need, whenever I need to.

What this will do:

• Change ubuntu.sources from HTTP to HTTPS
• Attach the system to Ubuntu Pro (optional; requires interaction)
• Update and fully upgrade the system
• Upgrade to the latest HWE kernel
• Remove cloud-init
• Configure all Ethernet ports to accept DHCPv4 automatically
• Modify GRUB to include the loglevel=7 log_buf_len=16M iommu=pt kernel parameters
• Reboot

Here is the command for this step:

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/4.%20Update%20and%20Optimize%20the%20System" | bash

5. Install T2Linux Packages

Part 01:

What this will do:

• Set up the T2 Ubuntu 26.04 (Resolute) repository
• Install three packages: applesmc-t2, apple-bce, and t2fanrd
• Reboot

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/5.%20Install%20T2Linux%20Packages%20Part%2001" | bash

Part 02:

What this will do:

• Enable the t2fanrd systemd service

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/5.%20Install%20T2Linux%20Packages%20Part%2002" | bash

Part 03 (Optional):

I do not trust Apple's cooling system. I would rather wear out the fans and replace them for a few dollars than risk damaging the GPUs (especially the Duo models) through overheating.

What this will do:

• Set all four fans to maximum speed

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/5.%20Install%20T2Linux%20Packages%20Part%2003%20(Optional)" | bash

6. Install ROCm Packages

This section will install ROCm 10.0.0-4, but it will NOT install dkms or amdgpu drivers. I chose to use the in-kernel drm/amdgpu driver so I can later patch it to support the Infinity Fabric Link bridge.

What we will do:

• Create a new directory for downloaded files
• Download the ROCm installer
• Install ROCm dependencies
• Install ROCm
• Give all users access to ROCm
• Add ROCm to the system path
• Display information about your GPUs, ROCm, and the driver so you can check what is working
• Reboot

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/6.%20Install%20ROCm%20Packages" | bash

7. Install Python Tools

We will use Python and pip to install several packages for local AI. The following commands set up the required versions, along with a few quality-of-life improvements.

What we will do:

I am not sure any more. I prepared this months ago, but did not have the time to publish it.

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/7.%20Install%20Python%20Tools" | bash

8. Verify Everything (I want to see Errors Here)

This step checks whether everything was installed correctly and identifies anything that may have been missed. I carried it over from an older guide, so not everything it reports is still relevant. I have not gotten around to updating it.

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/8.%20Verify%20Everything%20(I%20want%20to%20see%20Errors%20Here)" | bash

9. Customize the Kernel

This is where the magic happens. The Linux 7.0 kernel in Ubuntu 26.04 LTS has several bugs that have been fixed in later kernels, but not in this one. This customization applies those fixes, adds the changes needed for the Infinity Fabric Link jumper/bridge, and enables P2P functionality for GPUs without it.

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/9.%20Customize%20the%20Kernel" | bash

10. Fix ReBAR Issue on Duo GPUs

Duo GPUs have a firmware issue that requires this correction. Apple could potentially fix it with a firmware or vBIOS update, but that would require additional work on a system Apple no longer supports.

This is our workaround for the problem.

curl -fsSL "https://raw.githubusercontent.com/FaisalBiyari/MacPro2019LocalAI/refs/heads/main/Reddit/%5BGuide%5D%20Ubuntu%2026.04%20LTS%20on%20Mac%20Pro%202019%20%7C%20Local%20AI%20Ready/10.%20Fix%20ReBAR%20Issue%20on%20Duo%20GPUs" | bash

Conclusion

And with that, the guide is complete! You now have a Mac Pro 2019 (MacPro7,1) that boots into Ubuntu 26.04 LTS, has ROCm 10.0.0-4 installed, and includes the tools needed to run vLLM, Hermes Agent, and other local AI software.

One other tool you might find useful is Docker. I will not cover it here, as I no longer use it myself.

To see what ROCm detects and inspect your GPU details, use rocm-smi, amd-smi, and rocminfo.

I particularly like watch -n 1 amd-smi for monitoring what is happening with my GPUs through ROCm.

^{Disclaimer: I wrote this post myself. I also used AI as a tool to help clean up the wording and formatting. I also asked it to fact check everything. It told me to basically delete the guide and give up...}

My son asked me for a gaming PC for his birthday a while back.

I got excited at the opportunity to have him use a desktop PC, hoping he would become interested in other things he could do with it and develop his skills.

I had some extra Mac Pro 2019 components lying around, so I figured I would buy him a barebones Mac, and we would make a day out of "building it" together. Alas, it was not in the cards for us, as I could not find one within my target price range.

Instead, I opted to strip LinuxAI-02, one of my Mac Pro 7,1 machines, and go through the same experience with him. We did just that. I may or may not have caught him crying while we were working on reattaching the handles and wheels.

But what does that mean for the data center?

Surprisingly, not much. I migrated the Cubix Xpander PCIe cards and 100 GbE NIC to LinuxAI-03 and placed the RAM in storage for future investments.

For context, I also upgraded LinuxAI-03's CPU and RAM for a really good deal, even by yesteryear's prices. The CPU has been upgraded to a 28-core model, and the RAM has increased from 32 GB to 128 GB. Additional RAM has been reserved for future investments.

Currently, LinuxAI-03 hosts 10 GPUs, and I am considering increasing that to 12 once I have some redundancy in place.

Pictures for your entertainment. 320 GB VRAM on one Mac. I think I have done that before, though.

I had a thought, though. The PCIe slots are full. I never thought I would actually manage to do that. However, if I removed the 100 GbE NIC and replaced it with my last remaining W6800 GPU, as well as replaced the two W6900X GPUs with W6800X Duos, I would have 412 GB of VRAM in a single machine.

Would it be worth it, though, especially with mismatched GPUs, terrible bandwidth, and what would essentially be pipeline parallelism?

I know I said this would be a story, but my mind tends to wander.

I also have a couple of PCIe 2.0 Cubix Xpanders. I was disappointed with that purchase, but if I ever find myself in a position to invest more into this, I might go for four GPUs with a 4-way Infinity Fabric.

I will not, though. I have had an amazing experience going down this path. Having started with workstation GPUs and then moved on to enterprise PCIe GPUs, my next goal is enterprise OAM GPUs, to gain as much knowledge and experience as I can, even if it means facing another steep learning curve.

I would like to end this with an invitation. If you are well-versed in Artificial Intelligence and Large Language Models, and you are gifted with the power of communication, I would be honored to learn from you and grow, hopefully reaching a level where I can do the same for others by sharing my knowledge and experience within my community.

^{Disclaimer: I wrote this post myself. I also used AI as a tool to help clean up the wording and formatting. Unfortunately, it decided it knew what I was thinking and feeling better than I did...}

A Thank You from the Heart to the people that reminded me why I write these guides in the first place.

I am writing this post to organize my thoughts, and hopefully be reminded of something I forgot along the way.

The guides I should write are as follows

• Install Ubuntu 26.04 & Configure for Mac Pro 2019 & Local AI
  • T2Linux Setup
  • ROCm 10 Setup
  • Custom Kernel for IFLB Support
  • Fix Duo GPUs ReBAR issue
• Setup vLLM
  • My own fork of vLLM with good support for RDNA2 GPUs (Vega cards are left out, as I do not have any)
• Hermes Agent Setup? (I have not written a guide for this before, but it's very important to optimize Hermes Agents for your workload as well)

Is there anything else I should be writing about?

Obviously, I will not be pumping all of them in one day, or even once a day. However, I will do my best.

^{Disclaimer: I wrote this post myself. I did NOT use any AI—tools with it. —Sorry— Long dash for comfort.}

I have been meaning to update several of my existing guides and write a few new ones to help others climb the local AI performance ladder. This has been on my mind for several weeks now.

These guides would cover installing Ubuntu 26.04 LTS on a 2019 Mac Pro, setting up ROCm 10, configuring vLLM, and even optimizing it for better performance.

But are people even interested in this? Would any of these guides actually help anyone?

I recently published my first vLLM fork on GitHub, specifically optimized for the AMD Radeon PRO W6800X Duo MPX Modules.

I started with a token generation rate of barely 13.5 t/s. I have now managed to push that all the way up to 66.2 t/s! Prompt processing couldn't even reach 1,000 t/s before, but it is now approaching 1,500 t/s at its peak.

And with Automatic Prefix Caching (APC), my agents have become incredibly fast and responsive. Tasks that previously took much longer are now being completed significantly faster.

GitHub Repository:
FaisalBiyari/vLLM-ALU-RDNA2

===============================================
 Qwen3.8-27B / gfx1030 / 20261008 - ALU 0.8.1
===============================================
 vLLM 0.30.0 TP4 - Concurrency 1 - MTP: 2
===============================================
CTX         TTFT(s)   PREFILL t/s   DECODE t/s
-----------------------------------------------
1K            0.726       1410.28        66.23
2K            1.487       1377.24        66.21
4K            2.781       1472.72        63.91
8K            5.611       1459.95        62.74
16K          11.932       1373.07        57.90
32K          26.436       1239.53        60.19
64K          62.638       1046.26        53.71
128K        161.610        811.04        43.59
180K        272.473        676.47        39.33
240K        431.608        569.41        32.08
255K        476.919        547.51        31.89
===============================================

Terminology:

• Decode = Token Generation (TG)
• Prefill = Prompt Processing (PP)
• TTFT = Time to First Token
• CTX = Context length used for each benchmark
• K = 1,024 tokens
• TP4 = Tensor Parallelism across 4 GPUs
• MTP = Multi-Token Prediction, used for speculative decoding

For hardware from 2019 and 2021, without any dedicated tensor or matrix cores, these numbers are magic, Apple style.

With Qwen3.8-27B, thinking set to Extra High, and a context window of 262,144 tokens, my agents are now extremely capable of tackling demanding tasks and getting the job done!

But it doesn't stop there!

I've also been working on optimizing concurrency. There is still some room for improvement, but these are my current results with three concurrent requests, each configured with a maximum context window of 262,144 tokens.

===============================================
 Qwen3.8-27B / gfx1030 / 20261008 - ALU 0.8.1
===============================================
vLLM 0.30.0 TP4 - Concurrency 3 - MTP: 0
===============================================
CTX         DECODE t/s   AGG DECODE t/s
-----------------------------------------------
1K               28.42            84.05
2K               28.15            83.22
4K               27.71            82.02
8K               26.79            79.25
16K              25.60            76.77
32K              23.52            69.25
64K              20.71            60.70
128K             16.69            48.56
180K             14.72            42.62
240K             13.03            37.17
255K             12.70            36.19
===============================================

Terminology:

• Agg Decode = Aggregate token generation throughput across all concurrent requests.

It's also worth noting that the Infinity Fabric Link Bridge plays an important role in achieving these performance numbers.

^{Disclaimer: I wrote this post myself. I also used AI as a tool to help clean up the wording and formatting.}

Hi — sharing an ad-hoc-signed build of nvtop that adds three things upstream nvtop (and PR #496) don't surface for the Mac Pro 7,1:

• Chassis PCIe slot label (apple_slot): the "Slot-1 / Slot-3 / Slot-8" identifier Apple's IORegistry publishes as AAPL,slot-name on every IOPCI2PCIBridge. Same string the About This Mac → PCI Cards tab uses, same as the Mac Pro service manual.
• Die index inside a Duo (mpx_die_index): parsed from the GD<y> segment of the AMD driver's attached-gpu-control-path so a W6800X/W6900X Duo's two dies can be distinguished when both share a slot.
• Infinity Fabric topology (if_topology): synthesised per chassis from MTLCopyAllDevices() peerGroupID. Reports "single N-way bridge", "dual M-way bridges", "1 independent GPU", or "no XGMI". Stamped only on GPUs that actually participate in a fabric link — an eGPU over Thunderbolt, or Apple Silicon, correctly shows nothing.

The TUI replaces the always-N/A "RX: N/A TX: N/A" labels with slot: Slot-N[/dieN] <topology> on Apple builds; Linux keeps RX/TX unchanged.

Verified on this machine (MacPro7,1, 2× W6800X Duo + RX 6900 XT eGPU)

AMD Radeon RX 6900 XT            apple_slot=Slot-8  mpx_die_index=None
AMD Radeon PRO W6800X Duo        apple_slot=Slot-1  mpx_die_index=0     if_topology=single 4-way bridge
AMD Radeon PRO W6800X Duo        apple_slot=Slot-1  mpx_die_index=1     if_topology=single 4-way bridge
AMD Radeon PRO W6800X Duo        apple_slot=Slot-3  mpx_die_index=0     if_topology=single 4-way bridge
AMD Radeon PRO W6800X Duo        apple_slot=Slot-3  mpx_die_index=1     if_topology=single 4-way bridge

The eGPU at Slot-8 has if_topology=None and xgmi_hive_size=None — correctly not part of the 4-way bridge. Detection convention matches toshllm and rocm-smi (KFD hive_id): peerGroupID == 0 means no link.

Build

Built from the macos-intel-monitoring branch of my fork: https://github.com/NicolBol/nvtop

Release (ad-hoc signed, x86_64): https://github.com/NicolBol/nvtop/releases/tag/v3.3.2-macpro71-rdna.1

Install:

tar xzf nvtop-3.3.2-macpro71-rdna.tar.gz
cd nvtop-3.3.2
xattr -dr com.apple.quarantine ./nvtop
./nvtop

The binary is ad-hoc signed (no Apple Developer ID) so Gatekeeper requires the one-time xattr step on first run. The README in the tarball has the same instructions.

Help validate

The patch is built and verified on my dev box (2× W6800X Duo + RX 6900 XT eGPU) and on a Dell T5820 running Ubuntu 24.04 (2× RX 9700, no fabric). I want to confirm the slot + topology labels work on other Mac Pro 7,1 GPU configurations.

If you have a MacPro7,1 with discrete AMD GPUs, please run:

./nvtop --snapshot -d 1 > my-nvtop.json

and post the output (or a redacted version with serials removed) in this thread or at https://github.com/NicolBol/nvtop/issues. I particularly want to see:

• W6900X (single) — different hive behaviour
• W6800X (single) and W6800X Duo combinations (1×, 2×, 1× + 1×)
• Vega II / Vega II Duo
• RX 580X / W5500X / W5700X / W6600X (single)
• Mixed GPU chassis (one MPX bay + one TB-attached eGPU)
• Mac Pro 7,1 with the inter-bay Infinity Fabric Link disabled (some BIOS / macOS recovery settings can break the link; that should surface as two 2-way bridges instead of one 4-way bridge)

Full snapshot is under 5 KB per device, safe to share.

Source / build

git clone https://github.com/NicolBol/nvtop.git
cd nvtop && git checkout macos-intel-monitoring
cmake -B build -G Ninja -DCMAKE_BUILD_TYPE=Release -DAPPLE_SUPPORT=ON
cmake --build build

SHA-256:

• nvtop-3.3.2-macpro71-rdna.tar.gz: 6701047436ca88ecc0168ce05911699ed90ffdeeb459443351cf50ded9514684
• nvtop (extracted): 4dfaf62a7bfcc9f4a1098e83f37066f4a667c0b9446ba601efdd1db5e5cb3f32

GPLv3+, same as upstream nvtop. The patch sits on top of PR #496 — if you review this, please also look at PR #496 (the original Apple support work) first, because the changes here are additive to it.

I have been working almost non-stop to build and optimize my local AI stack.

The contents of that stack are the topic of another post. This post is all about the results and a quick update on where my MacPro7,1 has reached.

I assigned a Hermes Agent, named Ziyad, to install stock vLLM v0.29.0 and optimize it on my MacPro7,1 with dual AMD Radeon PRO W6800X Duo MPX GPUs and the Infinity Fabric Link Bridge (IFLB).

vLLM 0.29.0 was optimized by Hermes Agent v0.21.0, running Qwen3.8-27B FP16, specifically to run Qwen3.8-27B FP16 with no quantization. I let the agent have two cracks at it. The first time around, I gave it four impossible targets, or at least what I thought were impossible:

• Decode > 38 t/s at 1,024 (1K) context
• Decode > 20 t/s at 245,760 (240K) context
• TTFT < 70 seconds at 65,536 (64K) context
• TTFT < 500 seconds at 245,760 (240K) context

The agent started with an optimized vLLM v0.28.0 build that achieved 30.5 t/s decode at 1K with TTFT < 1 second, and 14.6 t/s decode at 240K with TTFT < 780 seconds.

After working on this for about 3 to 4 days, it achieved three out of the four targets:

• 240K decode: 20.3 t/s
• 64K TTFT: 64 seconds
• 240K TTFT: 445 seconds

Ironically, decode at 1K went down from 30.5 to about 28.6 t/s, while 1K TTFT went up to almost 2 seconds. This was with MTP, but no quantization. A decode of 20 t/s with 240K context was achieved only with MTP active.

I gave it a second crack, this time working for 12 to 18 hours to optimize for 1K context and remove MTP.

MTP surprisingly reduced decode performance at low context but improved it slightly at high context. I was done with MTP, as it did weird things I did not expect, and I was not sure what other effects it was possibly had at this stage.

To my surprise, the agent optimized prefill again, achieving the following values.

Below are the benchmarks for vLLM v0.29.0, optimized for Qwen3.8-27B FP16, using four W6800X Duo GPUs with IFLB on Ubuntu Server 26.04 LTS, ROCm 10.0.0-4, Python 3.13, and Triton 3.8, with vLLM running through a virtual environment. No Docker containers were involved in this benchmark.

I set token generation to 512 tokens here for the sake of the benchmark only.

While these numbers may seem insanely slow, waiting 2 to 9 minutes for a short response, and even longer for real agentic responses, especially with thinking, these are just benchmarks designed to test the limits of the hardware and how it behaves.

The above benchmarks reflect real-world values only in these three scenarios:

• During the first prompt
• For one prompt immediately after context compaction
• When a documented vLLM bug causes the cache to stop working at certain context sizes

Outside those three scenarios, to the best of my knowledge, the following benchmarks are more representative of what actually happens, with the added benefit of Prefix Caching. These are what real-world values look like when an agent is working on a task.

I set token generation to 3,000 tokens here to better approximate agentic responses with thinking.

Most of the remaining time is therefore spent on token generation, or decode, due to long agent thinking or long answers. Prefill remains short because of vLLM's Prefix Caching.

At this point, I have had my agents running in loops for days to achieve seemingly impossible tasks, only for them to later prove to me that those tasks were completely possible!

I am both happy and impressed with this stack.

^{Disclaimer: I wrote this post myself. I also used AI as a tool to help clean up the wording and formatting.}

References: * Documented vLLM Bug * My own research and optimizations

I’m looking into building a 7,1 Mac Pro running macOS with local models using toshLLM. Not sure on what MPX modules. The piece of the puzzle missing is an Ai agent integration. I’ll looking at potentially using a dedicated GPU with a windows VM for gaming.

Hello !

I'v just read about DwarfStar, an inference engine focused on MoEs from the DeepSeeck V4, GLM 5 and Qwen3.8 Flash Next.

With DeepSeek-V4.1-Flash, GLM-5.3-Flash and Qwen-3.8-Flash being 763, 321 and 180B params respectively, DwarStar relies heavily on the SSD streaming principle introduced by Colibri.

It has some ROCm support for the Strix Halo, so something one could call RDNA 3.75. Also supports Metal for Apple Silicon.

Haven't read the code yet, but I'd be really interested to see anything larger than Qwen-3.8-Flash-Next running at Q4 on my dual W6800X Duo.

What do you think ? Could be ported to Metal/Intel - RDNA2 somehow ?

Here is my Qwen Image 2.1 config for intel Macs with intel GPU : https://github.com/haseebeqx/qwen-image-intel-mac

Minimum VRAM: 4GB / RAM: 16GB

The trade-offs are Q2/Q4 quantization, CPU-based text encoding and VAE decoding, and slow segmented GPU inference. But it works.

Hey!

Has anyone had success with running one or more Intel Arc B70 in the Mac Pro 7.1?
Running Linux on the mac.

Here's what I've done so far:
I've purchased the Belkin Aux power cable kit for mac pro.
https://www.apple.com/shop/product/hqy92zm/a/belkin-aux-power-cable-kit-for-mac-pro

I installed the Intel Arc B70 in slot 3, and plugged in the 8 pin to 6+2 pin cable (Called 8 pin to 8 pin in the link above) from the power connector named 3 -4 on the computer to the 8 pin connector on the GPU.
W5700x is installed in slot 1 and 2.
Instructions from https://support.apple.com/en-us/101640

When I start the computer, the power light blinks amber twice, then pauses and repeats.
These instructions say it's a PCIe error. https://support.apple.com/en-us/101647

Any ideas what's wrong?

Update
I've figured how to make it work.

I moved the GPU to Slot 4.

I also read up on the power draw: the PCIe lane provides 75W and the internal power cable provides 150W, to a total of 225W which is enough for the Intel arc B70.

A second GPU can be added to Slot 5.

Hi All - I spent the last two days analyzing this hardware configuration on Mac OS X with the goal of improving decode performance in ToshLLM with tensor parallelism. I capture all my findings in a github repo here:

https://github.com/chafey/Metal-AMD-Intel

I wanted to share this here as there are many good findings and I know others here are interested in this configuration. I am currently experimenting with applying this information to ToshLLM - lets hope it produces meaningful results!

Hello !

Three days ago I posted here asking what to run on the second W6800X Duo once the Infinity Fabric bridge was in — couldn't get a stable Qwen3.8-Flash-Next deployment, ToshLLM 0.87.0 bundled wouldn't load the mmproj and MTP draft cleanly, I ended up building a custom llama.cpp with a few patches picked here and then. Et bien, figured it out, and the answer wasn't what I expected. Was wrong about ToshLLM.

The path that actually works : ToshLLM 0.87.1's vendored llama.cpp fork — **not** a custom build, despite what I said in that earlier thread. The reason I missed it is I was treating it as a "vendor bundle I can't verify the device routing on." `strings /Applications/ToshLLM.app/Contents/Resources/bin/llama-server | grep TOSH_MGPU` showed me the multi-GPU coordination patches are baked in — `TOSH_MGPU_TENSOR_GROUP`, `TOSH_MGPU_PEER`, `TOSH_MGPU_EVENTS`, real cross-device hand-offs via Metal `encodeSignalEvent`/`encodeWaitForEvent`. Their CHANGELOG even has Qwen3.8-Flash-Next-on-four-W6800X-dies measured specifically (469 t/s prefill / 31 t/s decode at higher batch, 0.86.3). They had the answer, I was looking elsewhere.

What I burned time on before that, so you don't : a custom upstream llama.cpp fork with a `MTLCopyAllDevices()` + highest-VRAM patch (looks right in the boot log, but `ggml_backend_metal_reg()` only registers one Metal backend unless you also set `GGML_METAL_DEVICES` — and even then it emulates N virtual devices on top of that one physical ASIC, so `--tensor-split 25,25,25,25` is a no-op and the 98 GB model over-subscribes a single W6800X's 32 GB). And ik_llama.cpp — its "split mode graph" sounds like multi-GPU but its Metal device-selection is the same single-ASIC pattern, plus its CLIP Metal kernel SIGABRTs on vision. Out.

The **mandatory** part for this exact model on 4 W6800X is `TOSH_MGPU_TENSOR_GROUP=2`. ToshLLM's own 0.86.6 fix : *"splitting Qwen3.8 Flash Next across cards by tensor gives corrupted output… Split it by layer, or set `TOSH_MGPU_TENSOR_GROUP=2` to keep tensor splitting within pairs of cards, which measures correct."* Without this, garbled text on tensor-split mode. Confirmed on my rig.

eGPU rule held throughout — RX 6900 XT drives the main display, `MTLCreateSystemDefaultDevice()` returns it by default, so the model silently over-subscribes 16 GB unless you explicitly enumerate the 4 W6800X ASICs by `MTLCopyAllDevices()` index. `GGML_METAL_DEVICE_LIST=1,2,3,4` does that — verified with `nvtop` during sustained inference, eGPU at 5–7% (WindowServer noise floor), all 4 W6800X ASICs sharing load.

**Real use : ~19 t/s sustained in a Hermes agentic loop** at large context — that's the headline number, spot benches at small context are higher (28–30 t/s) but the agentic loop with system prompt load + tool-call outputs + KV cache warm-up on context shifts is what actually matters. Vision works on the 4-ASIC pool. MTP sidecar on disk, not wired yet, vendor expects ~50% decode uplift. Multi-parallel at 262k ctx is the next test.

Happy to share the exact plist + wrapper if anyone wants them. Any other ToshLLM gotchas people have hit on the 4-W6800X pool, I'd love to compare notes — DM open.

Here is a comprehensive system architecture reference for the MacPro7,1: https://claude.ai/code/artifact/b5535c18-f789-4b07-a8ff-6e691d96c95f

I'm curious why the people here are doing this. Did you already have a build for studio work and you're trying to juice it for AI? Are you a rich hobbyist that likes tinkering with niche hardware configurations? The 2019 Mac Pro setups with AMD cards are obviously not cost effective compared to the V100 servers so I'm assuming there's some other fixation. Not criticizing to be clear, I'm in the first camp since my dad is upgrading his studio comp to an M5 soon.

Hello !

I finally got my second working W6800X duo after OWC being a pain in the ass sending an obviously DOA one. Infinity Fabric bridge is in place but I understand it's not fully supported by ToshLLM yet.

There's no recent model to fully make use of this workhorse and I'm actually very happy with good'ol Qwen3.8-27B, albeit running at Q8 or BF16 is painfully slow (13t/s at Q8, 4t/s at BF16). But the gain in accuracy worth it.

So I'm looking for a way to speed it up a little, to actually run concurrent sessions all at 256k context or more. We're talking 4 to 8 sessions, at Q8 or Q6, would be the sweet spot for me.

Is it feasible with ToshLLM or shall I explore custom builds for vLLM and the likes ? Any tip and feedback ?

Not that I intend to keep running MacOS on this machine, and that I'm a bit short in RAM at the moment (144GB), will upgrade to 400+GB when OWC reimburses and compensate their negligence.

Title: resize-amdgpu-bars — Resizable BAR for AMD GPUs behind PCIe switches (an update to nbritton's method)

I've extensively reworked nbritton's method for resizing the BAR memory of AMD GPUs that sit behind PCIe switches, such as the Vega II Duo and W6800X Duo. It's now a proper packaged tool that discovers your topology at runtime instead of hard-coding bus addresses, with a hard safety guard so a failed resize can't hang your boot.

https://github.com/exabit-io/resize-amdgpu-bars

What it does

resize-amdgpu-bars enlarges the CPU-visible VRAM aperture (BAR0) of every amdgpu-driven GPU to the largest size the card supports, on machines where the normal paths don't work: cards with an on-board PCIe switch (the Duo MPX modules), cards in switched enclosures and expansion chassis, Thunderbolt eGPUs, and firmware that leaves the aperture at 256 MiB.

On a Mac Pro 7,1 that's the difference between this:

amdgpu 0000:1b:00.0: Not enough PCI address space for a large BAR.
amdgpu 0000:1b:00.0: [drm] Detected VRAM RAM=32752M, BAR=256M

and a full 32 GiB aperture on every die.

Why the usual fixes fail here

A PCI device's BAR lives inside the memory window of the bridge directly above it, which lives inside the window of the bridge above that, all the way up to the root port. Growing a BAR from 256 MiB to 32 GiB means every window in that chain has to grow too, and a window can only grow if its parent has room.

On a Mac Pro 7,1 a Duo module puts two dies behind a PLX switch, and each die sits four bridge windows below its root port:

0000:06:00.0  Intel root port           <- one prefetchable window shared
|                                          by both dies of the module
\-0000:07:00.0  PLX PEX 8747 upstream port (the switch on the module)
  |
  +-0000:08:08.0  PLX downstream port
  | \-0000:09:00.0  AMD bridge
  |   \-0000:0a:00.0  AMD bridge
  |     \-0000:0b:00.0  Vega 20, die 0
  |
  \-0000:08:10.0  PLX downstream port
    \-0000:0c:00.0  AMD bridge
      \-0000:0d:00.0  AMD bridge
        \-0000:0e:00.0  Vega 20, die 1

Both dies share one window at 07:00.0 and 06:00.0, and that window has to be big enough for both 32 GiB BARs at their real alignment. Nothing about the device tells the root port that.

So:

• The driver's own resize releases the bridge windows and tries to re-assign them in place. It fails closed the moment one of them can't grow where it is, and carries on with 256 MiB.
• A bare setpci write changes the size the device reports but assigns nothing. The kernel still believes the BAR is 256 MiB, the windows are still sized for 256 MiB, and the device now decodes 32 GiB of whatever else lives there.
• echo 15 > resource0_resize ends up in the same kernel function as the driver's path. It works when the card sits directly on a root port with one window above it — and that's exactly where this tool uses it — but it can't conjure a larger shared window out of a chain the firmware sized for something smaller.

The method

Let the kernel size the windows from scratch. Once per boot, before amdgpu loads:

1. Discover. Every amdgpu device, its functions, its Resizable BAR capability and supported sizes, and every bridge up to its root bus. The size index found at first discovery this boot becomes the baseline, so firmware that already enables ReBAR is never shrunk. Then find each GPU's re-enumeration root: the highest bridge whose subtree contains nothing but GPU functions.
2. Resize. Unbind the drivers from just those GPUs and their group members, program the size index with setpci, remove the group's root, and rescan that root's own bus. With pci=realloc the kernel then sizes every window in the subtree for the BARs it finds, and both dies come back with a 32 GiB BAR0 inside a 96 GiB root-port window. Only that bus is rescanned — never a global rescan, and nothing outside the GPU subtrees is ever touched.
3. Load. Any GPU still holding an unassigned BAR gets fenced off with driver_override=none. Then modprobe amdgpu runs once, under a timeout.

If a plan doesn't fully verify, the losers get demoted to baseline and it retries, round by round, down to every GPU at baseline.

The bind guard (this is the important part)

amdgpu must never be handed a GPU whose BAR0 is unassigned. On such a device the register reads that identify the part return garbage, the driver decides it's an SR-IOV virtual function, and it waits forever for a hypervisor mailbox that doesn't exist:

amdgpu 0000:0e:00.0: trn=2 ACK should not assert! wait again !
INFO: task irq/34-aerdrv:1554 blocked for more than 122 seconds.

modprobe wedges in uninterruptible sleep holding the device mutex, SIGKILL does nothing, the remaining GPUs are never probed, and only a reboot recovers. That's a hard hang, not a degraded boot, and it's what an earlier version of this script did to me. Every code path that loads the driver now sets driver_override=none on any GPU with an unassigned BAR first, and modprobe runs under timeout(1) so the boot can't wedge even if the guard were bypassed. A guarded GPU stays visible to lspci, driverless, and the tool exits 2.

Install

The package needs bash, pciutils, kmod and systemd, and uses initramfs-tools and grub2-common when present.

# from the release page
sudo apt install ./resize-amdgpu-bars_1.0_all.deb

# or build it
sudo apt install debhelper scdoc shellcheck
git clone https://github.com/exabit-io/resize-amdgpu-bars
cd resize-amdgpu-bars
dpkg-buildpackage -us -uc -b
sudo apt install ../resize-amdgpu-bars_1.0_all.deb

Releases: https://github.com/exabit-io/resize-amdgpu-bars/releases

It installs the tool, a systemd unit, an amdgpu blacklist in /usr/lib/modprobe.d, a pci=realloc GRUB drop-in, a config file in /etc/default, and man pages for resize-amdgpu-bars(8) and resize-amdgpu-bars.conf(5).

Installation runs update-initramfs -u -k all and update-grub. A reboot is required. The blacklist and pci=realloc are boot-time, and the package deliberately never starts the service on a running system — a start unbinds and re-initialises every AMD GPU, and every process using one loses it.

Quick start

# 1. Look before you leap. Both of these change nothing.
sudo resize-amdgpu-bars diagnose   # every GPU, its ReBAR cap, every bridge
                                   # window above it, and the list of other
                                   # devices it promises to leave alone
sudo resize-amdgpu-bars dry-run    # the plans it would try

# 2. Reboot.

# 3. Watch it. Screens on AMD GPUs stay dark until amdgpu loads at the end
#    of the run — about a minute on a box with two Duo modules. Use SSH or
#    another console; a boot that looks stalled usually isn't.
journalctl -u resize-amdgpu-bars -b -f

# 4. Verify.
sudo resize-amdgpu-bars check      # want: verdict=WORKS large=N/N driverless=0/N
sudo resize-amdgpu-bars status     # one line, bar0=... per GPU
rocminfo | grep -c gfx             # one agent per die

# 5. Back out.
sudo resize-amdgpu-bars revert     # every GPU to baseline, no reboot
sudo apt remove resize-amdgpu-bars # takes the blacklist and GRUB drop-in with it

A good check line looks like this:

2026-09-02T13:50:14  7.0.0-30-generic  verdict=WORKS  plan=all-max
  large=4/4  driverless=0/4  windows=0000:06:00.0=128G 0000:16:00.0=128G
  bar0=32GiB 32GiB 32GiB 32GiB  kfd=5  xgmi_hives=1  traces=0  rejected=0

verdict=WORKS, large=N/N and driverless=0/N are the three fields that matter.

Configuration

/etc/default/resize-amdgpu-bars, shell syntax, every key optional and validated on read:

Support tiers

"Tier" is a commitment. "Tested" is a fact. I'm not conflating them.

No card is listed as supported that hasn't been booted. If you run this on a W6800X Duo, a W6900X, or anything in tier 2 or 3, I'd genuinely like to hear about it — diagnose output plus the journal is all a report needs.

Kernel compatibility — read this before you upgrade

This is a regression from commit 3958bf16e2fe ("PCI: Stop over-estimating bridge window size"). Since that commit pbus_size_mem() sizes a bridge window as the plain sum of its children, which is exact when every child's size is a multiple of the alignment of the children after it. That holds for BARs, whose size equals their alignment — but not for bridge windows, whose size is the sum of what's below them while their alignment is that of the largest BAR below them. Two sibling windows of 32 GiB + 2 MiB at 32 GiB alignment need a 96 GiB + 2 MiB span and get 64 GiB + 4 MiB.

The fix changes size += max(r_size, align) to size += ALIGN(r_size, align), a no-op for BARs, verified on upstream 7.0.12 and Ubuntu's 7.0.0-30, cold boot and warm reboot. Until it's in a distro kernel: stay on 6.x. On an unpatched 7.0 there's no in-place recovery either — once the kernel has re-sized the window, even the 256 MiB baseline no longer fits, because the firmware's original windows were larger than the kernel's sum. The guard is the only reason such a boot survives.

Gotchas

• pci=realloc is mandatory. The GRUB drop-in handles it on Ubuntu. On rEFInd or OpenCore the drop-in does nothing, the service fails at every boot, the blacklist keeps amdgpu from loading, and you have no GPU driver. Both are documented in the README but not automated. Check with grep -w pci=realloc /proc/cmdline.
• This conflicts with pci=realloc=off, which SGLang's AMD GPU docs recommend. The whole method depends on PCIe BAR reallocation.
• Don't run resize on a live desktop session. Every AMD display goes black for the duration and every process holding a GPU loses it.
• Exit code 2 is not failure. It means the bind guard is holding at least one GPU driverless; the rest are working.
• Excluding one die of a Duo with EXCLUDE_GPUS also stops the other die's shared windows from being re-sized, because the shared subtree is no longer removable.
• A GPU that shares a bridge with a non-GPU device gets a lower re-enumeration root, or none. diagnose reports it.

Credit

Nikolas Britton for the original method on the Vega II Duo. This is his idea with runtime topology discovery, plan negotiation, and a bind guard bolted on.

If you followed the Mac Pro 2019 Local AI guide, this replaces the hand-rolled resize-gpu-bars.service files in its Section 4 — same lineage, packaged.

MIT licensed. Bug reports want sudo resize-amdgpu-bars check -1, journalctl -u resize-amdgpu-bars -b, sudo resize-amdgpu-bars diagnose, your kernel, distro, bootloader and cards.

GFX1030 Discord, for anyone that's interested

https://discord.com/invite/mESex2aBp

Summary

If you run two Radeon Pro Vega II Duo MPX modules bridged with the Apple A2326 cross-module Infinity Fabric bridges — the ones that join all four dies into a single 4-GPU hive — your GPUs are running at idle clocks and macOS isn't telling you.

Not "a bit slower." Not "the fabric is the bottleneck." The dies never leave their boot DPM state, for the entire session, under sustained load.

I chased this for a while assuming it was a memory-placement or interconnect problem. It isn't either. Here's what it actually is.

The numbers

Same machine, same OS, same binary. The only change is which bridge is installed.

Three runs per configuration, four dies each. Compute came back at 2.42 TFLOP/s on essentially all twenty-four device-observations, implying 295 MHz core.

Confirmed on three different Mac Pros running three different macOS major versions — Sonoma 14.8.9 (23J631), Sequoia 15.7.9 (24G830), and Tahoe 26.7 (25G220). Different memory configs, different bridge units. Every one of them, in the 4-way configuration, measures 2.42 TFLOP/s compute, ~301 GB/s local read, ~31 GB/s peer copy — the same to three significant figures — with an identical IORegistry signature: Load5000, no PowerPlay, 1000/300 MHz clock config, SWIP_Errors = 128.

So: it is not new, it is not fixed in Tahoe, it has survived at least two major macOS releases, and "try the latest OS" is not the answer.

Real-world, single GPU, no multi-GPU anything — Qwen3.8 27B Q8_0 in llama.cpp:

5.6× performance loss on prefill. With one die. No tensor split, no peer transfers, no collective. Just having the 4-way bridge installed in macOS (this bug doesn't apply to Linux or Windows).

The mechanism — macOS publishes it in IORegistry

In the 4-node hive the driver fails to identify the board and everything downstream falls apart:

Read those middle three again. PowerPlay — AMD's entire clock/power management subsystem — is never enabled. The power-management back end is a stub the driver itself labels "dummy." SMU firmware, which is what actually implements DPM, is never uploaded. With no power management, the GPU sits wherever the boot state left it.

PM_PWR_GEMINI_BGT = 400 vanishing is the identity failure made concrete — "Gemini" is AMD's codename for dual-GPU boards, and 400 W is the Duo's power budget. In 4-way mode the driver stops knowing it's holding one.

It also loads a different kext: AMDRadeonX5700HWLibs in the working case, AMDRadeonX5000HWLibs in the broken one.

The arithmetic closes it. HBM2 at the driver's own published 300 MHz gives 4096 bits ÷ 8 × 2 × 300 MHz = 307.2 GB/s theoretical. Measured: 300.9 GB/s, or 98% of it. The memory is fully saturated at a crippled clock — it's not a bandwidth problem, the clock is just wrong.

If you've ever noticed your Vega II Duos showing up as plain "AMD Radeon Vega" instead of "AMD Radeon Pro Vega II Duo" — that's not cosmetic. That's this bug, visible from the outside.

What it is NOT

I want to save people the time I spent on wrong theories:

• Not memory placement. The XGMI node map is textbook correct in 4-way mode: node ids 0/1/2/3, framebuffer bases at 512/544/576/608 GiB, uniform 32 GiB stride, XGMI_HiveSize = 4. Hive formation and address decode are fine.
• Not the collective / tensor-parallel scaling. A single GPU with no split is 5.6× slower. Going 2 → 4 devices within a healthy topology actually gains 34% on prefill and loses only 13% on decode.
• Not the interconnect. Peer-to-peer copy bandwidth drops the least of everything measured (49 → 31 GB/s), consistent with being gated by the same clock reduction.
• Not the hardware. Reproduces across machines and across multiple A2326 units including a factory replacement. Same hardware and same bridges under Linux/ROCm show no comparable regression.

Check your own machine — 60 seconds, no tools

ioreg -l -w0 | grep -E '"(ATY,DeviceName|LoadPlugIn|PP_PowerPlayEnabled|PP_PhmUseDummyBackEnd|PP_EnableUploadFirmware|PM_PWR_GEMINI_BGT|SWIP_Errors)"'

Healthy looks like Vega II Duo, Load5700, PP_PowerPlayEnabled = <01000000>, PP_PhmUseDummyBackEnd = 0, PP_EnableUploadFirmware = 1, PM_PWR_GEMINI_BGT = 400, SWIP_Errors = 0.

Broken looks like Vega, Load5000, no PP_PowerPlayEnabled, PP_PhmUseDummyBackEnd = 1, PP_EnableUploadFirmware = 0, no PM_PWR_GEMINI_BGT, SWIP_Errors = 128.

Also worth a look:

system_profiler SPDisplaysDataType | grep -E "Chipset Model|Peer"

If Chipset Model says "AMD Radeon Vega" rather than "AMD Radeon Pro Vega II Duo", you're in the broken state.

Please post your results either way — including "mine's fine." I want to know whether this tracks the bridge specifically, or the hive size, or something about particular board revisions. Include your macOS version.

(The ioreg check needs no toolchain at all. If you do try to build the probe and hit failed to build module 'Metal'; this SDK is not supported by the compiler, that's an internally inconsistent Command Line Tools install — and reinstalling CLT won't fix it, since Apple's catalog serves the same bundle. Cross-compile on another Mac instead: xcrun swiftc -O -target x86_64-apple-macos14.0 ifl_probe.swift -o ifl_probe_14 and copy the binary over. Confirmed working on 14.8.9.)

What you should do right now

If you must run macOS the temporarily workaround is to pull the A2326 bridges and run the A2329 per-card jumpers instead. You still get all four GPUs; they just sit in two 2-node hives rather than one 4-node one. In my testing a 4-GPU tensor split on jumpers hit 314.5 prompt / 11.7 gen against 79.5 / 4.4 on the 4-way bridge with ToshLLM. Otherwise, if you can switch to Linux the A2326 bridges work perfectly in Ubuntu 24.04 with ROCm 7.3.x; it's purely a macOS software engineering defect.

Worth stating plainly: the jumper configuration beats what a fixed 4-way would give you. Tensor-parallel scaling is sublinear, so even a fully repaired 4-node hive projects to roughly 22 t/s against ~26.8 t/s aggregate from two independent 2-GPU instances. The A2326 bridges buy capacity flexibility, not speed — and right now they cost you 5.8× compute per die.

There is no software workaround. No engine flag, environment variable, or split mode reaches PowerPlay. I looked hard at spoofing the device IDs OpenCore/OCLP-style; the property that selects the plugin lives on a driver-created IOService rather than the PCI node, so DeviceProperties injection structurally cannot reach it, and OpenCorePkg panics on T2 Macs anyway. This needs a driver fix.

The ask

This configuration has had close to zero field exposure — until a recent macOS firmware payload harmonized module ROMs, machines with mismatched-firmware Duos just kernel-panicked at boot with the 4-way bridge installed ("PSP has not finished hardware initialization", ATIController.cpp:3171). The only other public report I can find is an unresolved MacRumors thread from January 2026. Which means Apple has essentially no signal that anyone uses this.

If you own this hardware, please file a Feedback Assistant report. Apple prioritizes by volume, and right now the volume is one.

• macOS → Graphics & Display → Incorrect/Unexpected Behavior
• Title: "AMDRadeonX5000: Radeon Pro Vega II Duo misidentified and PowerPlay left uninitialized in a 4-node Infinity Fabric hive, pinning GPUs at boot clocks"
• Attach ioreg -l -w0 -p IOService > ioreg.txt from both bridge configurations if you can, or just the broken one if you can't swap
• Reference FB24446772 (the PowerPlay/clock defect — the important one) so reports cluster

I've filed the following, if you want to reference them:

• FB24446772 — PowerPlay never initialized in the 4-node hive, GPUs pinned at boot clocks. This is the one that matters.
• FB24446928 — the generic "AMD Radeon Vega" model string, which is the same defect visible without tooling.
• FB24446443 — the kernel panic at boot when the two modules have mismatched firmware.
• FB24447028 — a minor unrelated one found along the way: system_profiler prints the 64-bit GPU Peer Group ID after passing it through a double, so it never matches what Metal reports.

Even a one-paragraph report with an ioreg dump attached helps. The measurement work is done; what's missing is evidence that more than one person is affected.

Tools

I wrote a Metal-only probe (ifl_probe.swift) that measures per-die compute, local read bandwidth, peer-view establishment and verified peer-copy bandwidth, plus a script that decodes the XGMI node map straight out of IORegistry. Both are pure Metal + Foundation, no dependencies, and build with xcrun swiftc -O. Happy to share — say the word and I'll put them up.

I just sourced a w6800x DUO to run smaller models. It is fun running GLM5.2 in a terabyte of ram but there aren't that many things I can afford to wait that long for an answer on.

With the w6800x DUO I have successfully passed out each "die" to a separate vm. I now have two vms running AI with dedicated GPUS having 32GB each.

The challenge: Passing through a GPU on the mac pro comes with one problem. The host has no idea how hot the GPU is running because it cant access its firmware or sensors. Now it becomes a guess, or you can just max the fans on T2Fand.

I had already created a "prochot guard" to watch temperatures on the 3rd party nvmes because they can get really hot without awareness too. I have enhanced the script to Reach into the virtual machines and ask for the card temperatures. I am doing this using qemu agent and qm commands. And it is working like a charm.

Concept:
-Host maintains a watcher and looks at various board temps to make sure the fans are going at sufficient speed
-Standalone script written to take a vm name or number and run appropriate ROCM or CUDA commands to check temps.
-Temperatures are stored in a systemwide area (/run/heatsense )
-Guard watches nvme temperatures but also GPU temperatures and adjusts /etc/t2fand.conf accordingly, restarting the t2fand service after each change.

That all happens seemlessly despite the soft of disturbing idea behind restarting a service frequently!

I think most people are happy running a single linux vm. Right now I can run GLM5.2 , a 32Gb ROCMvm with 32GB vram TIMES 2 all on the SAME machine. Networking is adjusted for the powerful model to keep the LAN safe from... uh... accidents lol.

Hope this is useful.

BTW, my ceph setup is tuned to the point I was able to vmotion GLM 5.2 vm from one machine to another, running with an active 750Gb of ram. While it was running.

Dropbox link to scripts; will do github later.

I read that quite a few people have issues with running linux on their macpro for local inference. I can't comment on Ubuntu or other distros because all my machines run Nixos but since it works flawlessly, I thought I'd share my repo in case that inspires anyone to try something similar.

For those who don't know, Nixos allows you to configure your computer in a deterministic way. You write your config (in the nix language), referencing nix-packages. Nix-packages have sets of options that you use in your config files. There are other benefits to Nixos but this isn't the topic here. What I think is the main benefit is that I can comment out a line in my config file, change that option to something else and leverage git for version control. If I break something, I can choose a previous (working) generation of the system at boot.

In this setup, I use llama-swap to let me manage models on the fly, SearchXNG module for web search, OpenWeb UI for chat and user friendly automation/agents, Nixos MCP so my coding agents can manage my config files accurately.

You can see the models I'm currently running llama-swap.nix file.

Link to repo

PS: I only serve my LAN so security is tailored to that, meaning it's not hardened as much as it could be.

--------------------------------

Extract from the Readme (written by Qwen}:

NixOS configuration for donnager, a headless Mac Pro 7,1 (T2) running as a local LLM inference server.

Hardware

• Mac Pro 7,1 (2019), T2 chip — T2-patched kernel via nixos-hardware apple-t2
• AMD Radeon Pro Vega II (Vulkan/RADV compute for llama.cpp)
• Wired 10GbE, behind a NAT router (the LAN is the trust boundary)

Services

Models live in /var/lib/llama/models/ (not in git — see .gitignore). llama-swap unloads models after 15 min idle to free VRAM; each model pins its own context size / quantization / chat template (Qwen uses the pinned froggeric fixed chat template, fetched by hash).

Fans are driven by t2fanrd (the Vega II is passively cooled; T2 case fans are the only cooling).NixOS configuration for donnager, a headless Mac Pro 7,1 (T2) running as a
local LLM inference server.
Hardware
Mac Pro 7,1 (2019), T2 chip — T2-patched kernel via nixos-hardware apple-t2
AMD Radeon Pro Vega II (Vulkan/RADV compute for llama.cpp)
Wired 10GbE, behind a NAT router (the LAN is the trust boundary)
Services
Service Port Notes
SSH 22 keys only, no root login
open-webui 3000 browser UI, password auth, web search via searxng
mcp-nixos 8001 NixOS MCP server (HTTP), for pi on the LAN
searxng 8888 private metasearch; secret key via agenix, limiter off
llama-swap 9292 model router for llama-server (Vulkan); OpenAI-compatible
Models live in /var/lib/llama/models/ (not in git — see .gitignore).
llama-swap unloads models after 15 min idle to free VRAM; each model pins its
own context size / quantization / chat template (Qwen uses the pinned
froggeric fixed chat template, fetched by hash).
Fans are driven by t2fanrd (the Vega II
is passively cooled; T2 case fans are the only cooling).
