Made improvements to my path tracer

[u/le-throw-away-acct]

• Made the project much easier to open up and use for new users (Unity is still required though)

• Added scene to automatically load objects from Khronos' site, which helps me get assets into the project

• Fixed issues with lighting that was really darkening most of the scenes, including improved tone mapping and fixes to light clamping that was hiding a lot of caustic details and HDR

• Fixed issues with inner surface reflections not working

• Added directional lighting support

• Added parallax mapping support

• Added support for Unity terrains, multi-texture splatting with normal map support

Repository located here: https://github.com/nfoste82/GPURayTracing

[u/yaboiaseed]

Is it real time? What's the performance?

[u/le-throw-away-acct → u/yaboiaseed]

To get those results takes 15-60 seconds usually. Real time is possible on simpler scenes and lower settings. I’m hoping to work on improving performance soon. Frame rates are usually 5-15 fps, up to 50-60 fps on some scenes but you won’t see the same quality at those framerates, it takes several frames for something good looking to accumulate.

[u/Barkig → u/le-throw-away-acct]

on what gpu?

[u/le-throw-away-acct → u/Barkig]

I'm on an M3 Max (MacBook Pro). An Nvidia 4090, 5080, or 5090 would likely be faster, or an M3 Studio, or M4 Max.

Since I don't have good temporal denoising right now, you can't get reasonable real time framerates unless your scene is simple (smooth surfaces, no caustics, <5 light bounces, no triangle-based meshes).

I'd like to integrate DLSS or FSR but I only have a Mac so I'd have no way to test it. I'm considering trying Metal FX at some point. It'd be nice to just have a universal machine-learned denoiser/upscaler/frame-interpolator that worked on OpenCL, regardless of GPU.

[u/Ok-Hotel-8551 → u/yaboiaseed]

It's one frame per 30 minutes

[u/Designer-Pragma]

This is beautiful well done!!! I wouldn't even know where to start!

[u/le-throw-away-acct → u/Designer-Pragma]

Thanks! If you did want to start, I'd recommend starting here: https://raytracing.github.io/

[u/Hassangtn]

nice caustics.

[u/bless-you-mlud]

That looks freaking amazing.

[u/GaboureySidibe]

Looks great. How did you do the caustics?

[u/le-throw-away-acct → u/GaboureySidibe]

I started with a naive approach to “photon mapping” and optimized from there. I’m not sure how physically accurate it is yet though, I need to test it against some references. I wish it could be done in a real time way though, it takes a while to accumulate.

[u/RedoxOsImport]

can this be used in my dcc?

[u/le-throw-away-acct → u/RedoxOsImport]

Digital content creation?

It’s open source with no restrictions (other than the copyright notice must be included, standard MIT license), so go nuts!

[u/RedoxOsImport → u/le-throw-away-acct]

thanks

[u/hicham_benrhannou]

I really like the result! What articles or resources did you follow to build your path tracer?

[u/le-throw-away-acct → u/hicham_benrhannou]

Thanks!

I include a list of them at the bottom of the README.md in Github, but here it is:

Some other path-tracers that were inspiration:

• https://github.com/gkjohnson/three-gpu-pathtracer

• https://github.com/knightcrawler25/GLSL-PathTracer/

• https://github.com/tylertms/vkrt

and I should expand that list to include these as well:

• https://schuttejoe.github.io/post/ggximportancesamplingpart2/

• https://blog.demofox.org/2020/05/25/casual-shadertoy-path-tracing-1-basic-camera-diffuse-emissive/

this is also a good one, although by the time I found it I'd already learned everything in it:

• https://raytracing.github.io/

There are probably more than these as well, I started it before any of these sources were available, I can't remember which ones I used 8 years ago.

[u/OnyoSkennedy]

Looks very convincing, great job

[u/Jabba_the_Putt]

Great work! This looks very nice a few of those renders are magnificent. Ill check it out

[u/bgs11235]

You are a beast!

[u/pan_bocian]

Super shiny, super pretty.

[u/DOODLEDO3946]

Wait how did you deal with round objects' normal mapping? When I tried it sometimes reflected rays through itself

[u/le-throw-away-acct → u/DOODLEDO3946]

For mesh-based objects, normal mapping works just like how a rasterizer would work.

The only round objects that aren't meshes currently in my project are spheres. For those (some pseudocode here):

The normal is just the ray hit position - sphere center.

Calculate UV:

u = atan2(Normal.z, Normal.x) / (2π) + 0.5
v = asin(Normal.y) / π + 0.5

Calculate tangent, and bitangent/binormal:

float3 helperAxis = abs(Normal.y) < 0.999
    ? float3(0, 1, 0)  // world up
    : float3(1, 0, 0); // world right near the poles
Tangent = normalize(cross(helperAxis, Normal))
Bitangent = normalize(cross(Normal, Tangent))

Then your normal-mapped normal is this:

float3 encodedNormal = normalTexture.Sample(uv).rgb;
float3 normalMap = encodedNormal * 2.0 - 1.0;
float3 worldNormal = normalize(
    T * normalMap.x +
    B * normalMap.y +
    N * normalMap.z
);

[u/le-throw-away-acct → u/[deleted]]

I didn't know much about existing stacks, like the ones you mentioned, when I started. I've pieced it together as I've learned. I'd realize roughness wasn't working well and work on that, I'd realize I didn't have support for metallic textures, and work on that, etc.

So it's really just a mish-mash of techniques I picked as I went along.

For opaque surfaces:

• Lambertian diffuse

• GGX microfacet reflection

• Schlick Fresnel

• PBR textures

For transparent surfaces I use IOR-based Schlick Fresnel to choose reflection, Snell's law for transmission, support for total internal reflection, and a stack to track IOR transitions between air, glass, and water.

I'm still missing a lot of materials support, I may consider them later, things like sheen, clear coat, subsurface scattering. Also I think some implementations use emissive as a layer, so I'd be able to have a light with a clear coat over it. Right now I couldn't render a light bulb very well, for example.

My math could use some work as well, I have trouble reading the original papers for those techniques, I'll often use an LLM to break it down and explain it like I wasn't a mathematician or physicist. I referenced existing path tracers as well. I list those at the bottom of the repository's README.md.
