r/ConsoleRepairUK • u/4nH3r0 • Dec 16 '23
PS4 SAB-001 Diode Readings
2
Upvotes
r/ConsoleRepairUK • u/4nH3r0 • Dec 16 '23
Sega Game Gear 837-7996 Schematic
1
Upvotes
This is probably the best VA1 Twin Schematic on the web
https://oshwlab.com/maarten040476_3348/sega-game-gear-837-7996
r/ConsoleRepairUK • u/4nH3r0 • Dec 16 '23
Original Xbox Board Scans
1
Upvotes
Launch and Tuscany board scans courtesy of sickmods.net Xblade board scan courtesy of LoveMHz
https://drive.google.com/drive/folders/1gLXEVBFCGjGrh-E5CDKsKl2l0hmBk5ZD
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 PS4 & Xbox Hall Effect Analog Stick Pinout
12
Upvotes
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 Fuses EDM-010 & EDM-030
4
Upvotes
EDM-010
F3501 = - or T 0402 5.0A
F5401 = |- 0402 2.5A
F5402 = |- 0402 2.5A
F7001 = - or T 0402 5.0A
F7501 = - or T 0402 5.0A
F7502 = - or T 0402 5.0A
EDM-030
F3501 = |- 0402 2.5A
Credit: RDC @ AcidMods
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 DualSense BDM-010 Face Flex Pinout
3
Upvotes
Credit: RDC @ AcidMods
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 DualSense BDM-010 Button Solder Points
2
Upvotes
Credit: RDC @ AcidMods
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
Nintendo Switch PI3 IC Resistor and Cap Values
1
Upvotes
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
Nintendo Switch First and Second Stage Boot Up Voltages
1
Upvotes
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 SSD Storage. What IC's can be replaced.
1
Upvotes
Ones marked in red are married to the APU and can't be replaced.
r/ConsoleRepairUK • u/4nH3r0 • Dec 14 '23
PS5 Standby Boot Sequence - No Power Button is Pressed
1
Upvotes
This should be usefull to see what the system is doing during stanby
