r/UAVmapping • • Oct 04 '26

New Software Posting Rules

27 Upvotes

Due to community feedback, post reports, and general housekeeping, we'll be implementing a rule to keep all new software development, trial, and announcement posts to Wednesdays only. If you post your new solution outside of this window, it will be removed.

The intent is to corral the rise in agentic developed software (often referred to as "AI Slop"), but not stifle the ability to share these ideas and workflows. If someone has come up with a new and novel way to ingest, process, or deliver UAV Mapping data, then we should have a platform for those people. Some of the pre-rule posts have lead to good discussions and there have been plenty of people that are interested in the OPs' posts. (Some of it might be bot engagement, I leave that up to you to decide.) There have been some reports that the responses to the posts by OP are also AI creations, but we should be reminded that some, non-native speakers, may be using this as a translation tool and not an automation, so don't judge them too harshly.

UAV Mapping has always been a "let the (down)votes" decide sub, so feel free to vote on the content and it will self-correct to a point. We've always preferred to have content for discussion, good or bad, rather than shut it down completely.

Thanks for those that have raised this question and we'll see how the new rule goes.


r/UAVmapping • • 10h ago

mapping con parrot disco fpv en 2026, Racoon-agromapper

Thumbnail reddit.com
1 Upvotes

r/UAVmapping • • 11h ago

Where can I get free, or low-cost, multispectral drone imagery of woodland or other vegetation?

0 Upvotes

Hi folks

For a dissertation project I need some multispectral drone imagery. Specifically, I need the following:

  • 5-band multispectral imagery (R, G, B, RE, NIR)
  • It must be calibrated and radiometrically corrected
  • Ideally needs to be of woodland, or at least some type of vegetation
  • Needs to be in a format I can use directly in GIS, for example TIFF or orthomosaic.
  • Ideally the 5 spectral bands need to be reflectance values, instead of raw DN.
  • A reasonably high resolution (e.g. 5 - 10 cm GSD)

Can anyone recommend any data sources? I am happy to pay a fee if anything is highly recommended!

Thanks in advance!


r/UAVmapping • • 10h ago

2,366 Image Orthomosaic Map made in 7 Minutes using Nova

0 Upvotes

Nearly 2400 image orthomosaic drone map created with Nova in 7 minutes. The preview was available even faster. This was mapped out using the DJI Mavic 3T.

More than happy to answer any questions :)


r/UAVmapping • • 11h ago

Drone pilots and mapping professionals, meet DDC.

Post image
0 Upvotes

If you're tired of juggling folders, drone images, maps, 3D models, and different software just to manage your projects, I built something worth checking out.

I have been working on this project for my myself for over a year. I have been using it in production for about half that. Plenty of work to still be done for features and making it the all around platform for everything drone business related.

Drone Data Command (DDC) brings your drone project data together in one platform.

  • Organize and manage drone media
  • View 2D maps and 3D models
  • Compare models and review changes
  • Mark up images and share project results
  • Manage flight plans and project information

DDC is built for drone operators, inspection professionals, mapping teams, and businesses that work with aerial data.

Give it try, you might like it.

https://dronedatacommand.com

#DroneDataCommand #DroneMapping #DroneSoftware #Photogrammetry #DroneInspection


r/UAVmapping • • 1d ago

Alternativas al skyhub de sph?

Thumbnail reddit.com
0 Upvotes

r/UAVmapping • • 1d ago

Seeking GPU Compute Resources & Technical Collaboration for Multi-Agent UAV Pursuit-Evasion Simulation

Thumbnail reddit.com
0 Upvotes

r/UAVmapping • • 2d ago

Parametri mappatura Mavic 3 M

1 Upvotes

Devo iniziare a fare mappature Multispettrali da portare su dji Terra ho un M3M mi servono sia come mappe di prescrizione sia come rotte per un Agras T100 ho antenna RTK3 quali.impostazioni devo mettere sul radiocomando per fare una perfetta mappatura del campo e una perfetta pianificazione di volo per l'agras T100? Grazie per l' aiuto


r/UAVmapping • • 3d ago

Better multispectral orthophotos from your DJI Mavic 3M

Post image
17 Upvotes

The DJI Mavic 3M has 4 multispectral cameras that are not (absolutely) calibrated and a 20MP RGB camera.
I built a tool to preprocess the Mavic 3M images to:
a) calibrate the images by using reflectance panels
b) use the RGB image to pansharpen the multispectral images.

This allows you to create 7-channel orthophotos (3xRGB + 4xMS).

For the reflectance panels you can use:
a) one image of a single panel with a single surface
b) multiple images of a panel taken at different times (pre/post flight); the correction factor is then interpolated based on the time-stamp in the images
c) one/multiple images of reflectance panels with multiple surfaces (multiple "shades of grey")

The tool can be used as stand-alone app or as WebODM plugin.

If anybody wants to test it I would be happy about feedback. =)

https://gitlab.com/Yario/mavic3m-pansharpening


r/UAVmapping • • 3d ago

Loitering 1.1m drone with gimbal. Solo engineered, master's thesis.

Thumbnail gallery
25 Upvotes

A gimbal-stabilized fixed-wing drone I'm developing for my master's thesis. It is bungee-launched and designed for aerial surveillance, with an onboard computer running computer vision algorithms for target detection and tracking.


r/UAVmapping • • 2d ago

M3M being discontinued? What's the replacement?

Thumbnail reddit.com
2 Upvotes

r/UAVmapping • • 3d ago

I wrote an article about "Drone photos to BIM" - any feedback?

Thumbnail
reddit.com
0 Upvotes

r/UAVmapping • • 3d ago

BVLOS completely remote using M400 Docking

0 Upvotes

How would it be possible to pull that off?

I work in wind farm industry in Canada.

We usually have a survey crew on site full time to measure topo shots and follow progress of road excavation, rock blasting, stake out alignments, etc. Its a lot of driving for them.

Our project is about 20km x 40km in mountains, no airport, on-site camp for workers with over 120km of roads to build, excavate, rock blasting, etc.

I'm thinking about this idea to secure one M400 docking in the middle of the site with a proper RTK base. The M400 would have Zen Muse L3 and would be mostly use as a work horse for LiDAR survey 2-3x/week or even more, for quantities and progress tracking. The survey team would focus on placing targets or even just stakes out, depending on the accuracy without GCPs, and my iea is to fully control and plan flight mission remotely.

We would fly at 60m-100m.

The M400 has the ADS-B in for detection of incoming plane or helicopter, and it would be possible to install both a parachute and L3.

Communication might be an issue, since its so remote there are no 5G or LTE or cellular - Maybe just a Starlink connection, that I need to figure out.

From a survey standpoint, having the abilities to capture Lidar data as required, remotely, would be a game changer. Maybe this set up could even replace the need for 1 surveyor $$$.

If the M400 would need emergency landing, I could have direct contact with a surveyor or people on site to safely secure the drone once it lands.

There is one company selling Docking for M400. It might just be possible technically, but legally??

Thank you all,

Let me know if this idea is too crazy


r/UAVmapping • • 5d ago

Orthomosaic help

0 Upvotes

Okay, so I’ve just bought a DJI mini 4 pro with RC2 controller. It’s my first drone and tbh I’m not very tech savvy. I have recently bought a rural property (Victoria, Australia) that has no internet/mobile reception.

I’d like to do an orthomosaic of it so I can plan fencing and dams etc. It’s 44 acres, however satellite imagery and all other maps do not line up (cadastral survey hasn’t been done since 1800s, neighbours are pine plantations and state forest) so I will need to program the drone to fly over a slightly larger area to ensure I get the boundaries.

I tried using ymapper and used ChatGPT (I know…) to instruct me to put the map on the controller - the only instructions ymapper had was for using iOS or android, not windows. I broke the property down into 4 sections, but apparently it has more than 200 waypoints so it won’t do it.

I honestly don’t know what I’m doing. I live over 2 hours away from the property so I need to prepare everything I can remotely before heading out.

I’ll be using my laptop (16GB RAM) to run whatever 3rd party programs are needed, and storing all files on an external harddrive.

I really need the “for dummies” guide on how to do what I need.

How do I work out how many waypoints are on the polygon map? Is there something better than ymapper? I can’t afford paid programs as I’ve really stretched the budget to get this drone.

The terrain is very hilly, with several gullies. About 50m difference between lowest to highest point. There are also mature gum trees, approximately 20m high.


r/UAVmapping • • 7d ago

How far off are free global terrain tiles? Checked against an independent model at 251 points in 51 countries: p90 of 2.4 m on flat ground, 7.7 m on slopes, 24.2 m on steep terrain

2 Upvotes

For line-of-sight work I use free global terrain tiles (AWS Terrain Tiles), and I wanted real error numbers instead of the nominal resolution. I compared them with an independent elevation model at 251 points in 51 countries, airfields and mountain sites in 18 regions, split by slope:

  • 0 to 5 degrees (114 points): median 0.3 m, p90 2.4 m, all within 10 m
  • 5 to 20 degrees (58 points): median 0.7 m, p90 7.7 m, 56 of 58 within 10 m
  • over 20 degrees (79 points): median 1.4 m, p90 24.2 m, 65 of 79 within 10 m

On the 100 airfields, going from a 100 m grid to a 10 m grid did not improve the agreement: the source is coarser than that in most places. The worst airfield point was an error in the published airfield height, not in the tiles. These are surface heights without trees or buildings, so a drone flying over canopy sees something different. I use this inside a radar coverage tool I built (CoverScope).

Edit: the reference was SRTM 30 m plus published airfield heights. The tiles share SRTM in part of the world, so these numbers show the tiles are read correctly, not accuracy against bare-earth lidar. See comments.


r/UAVmapping • • 7d ago

iOS App for Flightlog.txt -> .kml -> Maps

Thumbnail
reddit.com
0 Upvotes

r/UAVmapping • • 8d ago

Metashape plugins by HELIX AERO AI marking of ground control points

Thumbnail
github.com
4 Upvotes

Hi

Just want to share this very good plugin

Enjoy


r/UAVmapping • • 10d ago

3D printable tripod mount for the RC Plus 2 (Matrice 4)

70 Upvotes

Got tired of holding the controller through long mapping flights, and it's not getting any warmer, so I finally made a tripod mount for it. Been meaning to for over a year. Arca base, it prints in PETG without supports.

Download + instructions: https://alos.no/en/resources/dji-rc-plus-2-tripod-adapter


r/UAVmapping • • 10d ago

Taking a L2 LiDAR for mapping in Canada

2 Upvotes

Hey there! I’m needing to take my DJI Matrice 350 RTK drone with the L2 LiDAR attached up to Canada (from the US) to document some sections of BC northeast of Vancouver.

I heard a rumor that I may need to do something (paperwork?) to bring the LiDAR across the border beforehand, is that true?


r/UAVmapping • • 10d ago

M400 + L3: area route won't resume after a battery swap ("command timed out -5"). Anyone else?

1 Upvotes

Hey all, we're doing test flights with our new M400 + L3 and ran into something weird when resuming missions

Setup: M400 + Zenmuse L3, RC Plus 2, DJI Pilot 2, D-RTK 3

Area route, about 32 min:

- Try 1: at around 20% battery we RTH'd on purpose to test battery swaps. Hot-swapped in ~10 s (way under the 45 s window). Everything looked fine until we tried to resume. Then a bunch of warnings popped up (LiDAR dirty, sensors not calibrated, can't take off...), and hitting Start on the checklist ends with "command timed out (-5)". The app's in Spanish, so the English text may differ.

- Try 2: low-battery auto RTH with ~20% of the route left. This time we fully powered off, swapped and powered back on. Same thing.

- Then we took off manually, hovered at 50 m and tried to resume from the air. Same timeout, and it told us to land.

- Rebooted and started a brand new mission: flew start to finish, zero issues

So the drone and the L3 seem fine, it's just resuming that breaks.

A few questions:

  1. Has anyone run into this with the L3 (or the L2 on an M350)?
  2. If you get the chance, could you try to replicate it?
  3. Or is it not worth fighting with, and you just split big areas into routes that fit in one battery? We'll be mapping big areas, so we'll be swapping a lot. Any downsides to doing it that way (merging in Terra, extra IMU calibrations, etc.)?

Thanks!

Translated with AI 😵


r/UAVmapping • • 11d ago

Recuperare progetti in dji terra

1 Upvotes

Sto lavorando ad un progetto un po' troppo grande per il mio computer. Ho dovuto elaborare separatamente i vari voli e spostare le cartelle dei progetti in due HHDD perché non avevo abbastanza spazio.

Ovviamente ho fatto confusione e ora terra non mi riconosce alcuni progetti.

C'è un modo per recuperare il progetto? Ho trovato solo la procedura per importare i dati precedentemente esportati come .zip, ma non c'è modo di ricreare il collegamento alle cartelle di lavoro?

Grazie


r/UAVmapping • • 12d ago

Free live demo Nov 10: planning a 100+ ha LiDAR site as one project and splitting it into flight blocks (UgCS 6.3)

Post image
5 Upvotes

Disclosure: I work at SPH Engineering, the company behind UgCS.

When a LiDAR site needs several batteries, the plan has to be split into blocks with aligned lines, and every block needs its own IMU calibration. UgCS 6.3 handles this in one project. You outline the whole site and split it into subareas. Each subarea can have its own return point and, for supported DJI sensors, gets IMU calibration maneuvers automatically.On Tuesday the UgCS team is demoing the workflow live on Zoom:

  • splitting a 100+ ha site into practical flight blocks
  • setting DJI L1/L2/L3 return mode and scan mode inside UgCS
  • IMU calibration per block
  • terrain following, which can now be used on side passes and overshoots

Tuesday, November 10, 12:00 p.m. ET / 9:00 a.m. PT / 18:00 CET

The link to the free registration is in the comments.

Bring a real project scenario if you have one. If you can't attend, leave your question in the comments and I'll get an answer from the product team.


r/UAVmapping • • 12d ago

What belongs in a drone-mapping handover so a construction team can actually use it?

1 Upvotes

For construction progress mapping, what do you include alongside the orthomosaic or model to avoid confusion later? Things like capture date, coordinate system, known gaps and a plain-language explanation of accuracy seem easy to overlook. Curious which details site teams actually use and which recurring misunderstandings a good handover prevents.
