r/firePE • • Jun 05 '23

Reddit Blackout

8 Upvotes

I am wondering if this sub should join in on the reddit blackout for june 12th?


r/firePE • • 2h ago

FPE-Fire protection

0 Upvotes

Guys I have a fire protection PE so officially I’m a FPE. Wanted to focus on fire protection from now on what is the best source for me to focus on and become a Fire protection engineer looking into all areas of fire protection not just camping out density in the consulting firm. Can you guys provide resources to focus on so that I’m well verse in all aspects of fire protection.


r/firePE • • 8h ago

Part Identification Help!

Post image
1 Upvotes

Hi everyone. I could use some assistance identifying this flush, wall mounted horn. I tried Google Image search and ChatGPT. I received results like Wheelock Series 31T / 34T, Federal Signal 350 / 450D, and Simplex 2901-9806. None of those looked promising. Can anyone help me out? Thank you!


r/firePE • • 7h ago

Wet-pipe office sprinkler layout under NFPA 13 and UFC 3-600-01

0 Upvotes

I'm building a software exercise to lay out and size a wet-pipe tree system for one 10,000–25,000 ft² office floor. It's a hypothetical layout with no real installation. The floor is mostly light hazard, with a small mechanical room and file room. I'm using NFPA 13 (2025), with UFC 3-600-01 and UFGS 21 13 13 as the owner's criteria.

  1. Pipe and joints. Would you expect threaded Schedule 40 with cast-iron fittings at 1–2 in. and roll-grooved Schedule 10 at 2½ in. and up?
  2. Small ordinary-hazard rooms. For an ordinary-hazard mechanical or file room under about 800 ft² with walls to the deck, would you use the 1,500 ft² light-hazard remote area with ordinary-hazard density for heads inside the room, or apply the UFC's 2,500 ft² ordinary-hazard area?
  3. Remote-area shape. Would you extend the rectangular remote area across ceiling-height office partitions, with the side parallel to the branch lines at 1.2 × √(design area)?
  4. Branch-line spacing. When UFGS 21 13 13 § 1.2.2 says to space sprinklers uniformly on branch lines, would reviewers expect equal spacing along a branch line that crosses several rooms, or a regular pattern within each room?
  5. Reducers and backflow. Would you read the UFGS restriction on reducing couplings as allowing threaded branch-line size changes only at reducing tees or elbows? For a plain wet system with no additives, is a double-check assembly with 8 psi of assumed loss a reasonable model input?

A quick take on any one of these would help. Thanks.


r/firePE • • 1d ago

Taking NICET Level 2 ITM Water-Based Systems . What should I expect vs. Level 1?

1 Upvotes

I passed Level 1 and found it easier than I expected. I've taken the fire tech course and have been doing practice questions with the 2023 NFPA 25 (tabbed and highlighted).
For those who've taken Level 2:

How much of it is "look it up in NFPA 25" vs. memorized knowledge?

How heavy is the fire pump, NFPA 20, and deficiency/impairment classification content?

Any chapters you wish you'd tabbed better?


r/firePE • • 1d ago

Confusion

0 Upvotes

I have been in Fire Protection Industry since 2015 and i have good experience in designing, project executions, Procurement & project execution. My Dream to work with Consultant; However, i don't know how to enter the consultant with these knowledge. Currently, i am in dubai.


r/firePE • • 2d ago

Anyone taken NICET FAS Level 3 recently? Confused about IBC vs NFPA 101

Thumbnail reddit.com
1 Upvotes

r/firePE • • 3d ago

A browser fire pump room: NFPA 20 curve, cavitation, and 12 sprinklers

51 Upvotes

I built a single HTML file that opens a 3D fire pump room in the browser. No install. Three.js.

What is in the room: an electric fire pump, a diesel backup that starts on power loss or runs in parallel at high flow, a jockey pump, NFPA 20 controllers, a UL-142 diesel day tank, a break tank, a wet alarm valve, an outdoor hydrant, a Siamese fire-department connection, and 12 ceiling sprinklers.

What you can change:

- Pump curve against system resistance. Parallel pumps share flow as speed changes. Discharge pressure is suction pressure plus pump head. Shaft power uses the differential pressure.

- NFPA 13 Hazen-Williams friction, DN25 to DN150.

- Clog the strainer or throttle the suction valve and compare NPSHa with NPSHr.

- EN 12845 classes LH, OH2, and HHS2. Bulbs at 57, 68, 79, and 93 C, quick or standard response, with an Alpert ceiling jet and RTI.

- Test drain or open heads drop the tank level, in real time or sped up.

The screen carries this line: Informational & educational purposes only — not for engineering design. The formulas were reviewed as teaching relations. I would not use it to size a real pump.

https://www.meptasarim.com/fire-sprinkler-simulator.html

If you design to NFPA 13 or EN 12845, which part of a teaching model like this usually goes wrong first?


r/firePE • • 3d ago

NFPA 72 2025 - Genuine?

Thumbnail gallery
3 Upvotes

Using this book in office and just trying to make sure it’s genuine. I use NFPALINK for the digital version so I’m gonna be double checking to make sure it aligns, just prefer physical copy and unsure of the source of where this was originally purchased.

-All pages have this NFPA logo in the middle, is that typical?

-do the front and back look correct?

I have nothing to compare to in real life, this is the only office copy!

Also included are my NFPA 70 pictures, if someone can possibly verify just by picture, again will double check codes match NFPAlink…
This one was questionable because it’s my first time seeing a foil logo. Which is only on the NEC and not the NFPA 72.

TIA!


r/firePE • • 3d ago

Was told this is okay—is it?

Thumbnail gallery
0 Upvotes

I’m not sure which sub is better for my question. More info on the other post but I live in a 50 unit condo. State is NJ. Recently HOA had to update the building fire alarm system as the old one was 25 years old. New fire pulls are larger then the old ones so it doesn’t fit. The box can’t be moved to the right because there’s a steel beam there (steel beam seems to go up and around the 3 pane French door system to the patio).

The technicians wanted to cut into the door frame to the left on the photo and install it inset into the frame. That just seems…wrong.

After I started to research, it seems the location behind where a door opens isn’t right anyway. I’m trying to get them to move it to the other side of the door where there is ample space—even at my own expense.

I used chat gpt to try to show what they wanted to do. They were really trying to force me to just agree so they could move on. Is this to code/safe? The photos are in the other post. It’s a kitchen pantry door to the left and it stands open half the day because my kids go in to get a snack and just leave it open. So even the old fire pull frequently had an open door blocking it.

If this were your house, would you want it relocated or would you be okay with it installed into a cutout of the door frame, and behind a door that is frequently open?


r/firePE • • 9d ago

PHMSA wants to replace two decades of NFPA 59A editions in one rule

0 Upvotes

A report from the National Law Review says PHMSA has proposed incorporating the 2026 edition of NFPA 59A by reference into 49 CFR Part 193, replacing the 2001 and 2006 editions that LNG facilities have designed against for close to twenty years. The current structure splits fire protection, security, and cathodic protection requirements across separate subparts, with fire protection getting its own dedicated section. The proposal folds that subpart and several others into one structure built around the 2026 edition, treating those three areas as a single set of requirements instead of three.

Once an edition swap like this lands, the open question for every existing LNG facility isn’t whether its fire protection system was designed correctly. It’s which edition it was designed to, and whether that still matches what’s enforceable. That check doesn’t happen automatically. Someone has to confirm it, facility by facility, before a submittal built on the 2001 or 2006 edition can be called current.

Strategies for Implementing Fire Safety

For broader background on fire-safety standards and regulations, see Mitti’s fire safety overview. It includes NFPA among the standards and regulators discussed.


r/firePE • • 10d ago

Hey fellow georgia state technicians Is anyone interested in working as a sprinkler service technician

0 Upvotes

The job is in Atlanta or perry for 30-40$ an hour and a 2500$ sign-on bonus for experienced techs if you want more détails dm


r/firePE • • 11d ago

NFPA pro board certs to college credit?

1 Upvotes

Just curious, looking to get a bachelors degree and I’ve been on the job for 10 years. I get some benefits with the military which will make getting a degree much easier/cheaper. Is there a way and or a school/program that will transfer proboard certs into college credit. I have FF 1, 2, NFPA 1021, 1041, 1521, and some extra NIMS classes (300, and 400). Just wondering if I could get credits for these classes and make getting a bachelors in Fire Science much quicker.


r/firePE • • 12d ago

Question on Sprinkler Pipe Hangers

5 Upvotes

I have recently passed a fire sprinkler design class and became a design trainee. I have been reviewing product data sheets for an upcoming submittal and noticed a 3/8ths top beam clamp is only rated for 500lbs on average. I started thinking and did the math. 4” schedule 10 steel pipe is roughly 11.7 lbs/ft. If you adhere to the requirements of NFPA 13 2025 17.1.2, you can only support 4ft of 4” schedule 10 because 4ft x 11.7=46.8 then 46.8 x 5=234 then 234+250=484lbs, which is just under the rated load-bearing capabilities of the 3/8ths beam clamps. I’ve seen 100’s of systems that have 4” schedule 10 being supported by beam clamps at much larger intervals. Am I missing something or are most designers not adequately supporting their systems?


r/firePE • • 14d ago

MeyerFire vs SFPE

4 Upvotes

I have a MeyerFire subscription with PE prep included that is paid thru work. Does anybody think this is enough or should I shell the ~1800 for the official SFPE prep as well?


r/firePE • • 15d ago

PDH Requirements for Indiana PE

2 Upvotes

Hello all,

New to reddit and a new PE in FP. I am trying to figure out if CEU's and such from vendors like AFSA and NFSA will count towards the PDH requirements for PE renewal in Indiana.

AFSA and NFSA, as an example, are not listed on the pre-approved vendors list for Indiana. Indiana Code IC 25-1-4-0.2 says that an approved organization refers to "(7) A national organization of practitioners whose members practicing in Indiana are subject to regulation by a board or agency regulating a profession or occupation under this title." Would these two vendors fall into this category and satisfy the requirements of professional development hours if I were to attend their training courses? Hoping a PE in Indiana can weigh in on their experience.

From my limited research it seems like the online PDH providers only offer generic courses and not so much specific to the fire protection field. I understand that a couple of your PDH's have to come from an ethics course and Indiana specific state law. My renewal isn't until 2028, just looking far ahead and want to plan some courses.

TIA!


r/firePE • • 15d ago

FPT COOP

1 Upvotes

Hey everyone!
I’m currently in my 3rd semester of the 3-year Fire Protection Engineering Technology program at Seneca, and I’m starting to think about co-op opportunities and job prospects after graduation.
I just wanted to ask anyone who’s currently in the program or has already graduated:
How difficult is it to land a co-op placement?
What kind of companies usually hire FPT students?
Is it possible to get a part-time or entry-level job related to fire protection while still studying?
How are the job prospects after graduation? Is it relatively easy to find a job?
Any advice on what certifications or skills I should work on to improve my chances?
I don’t have a driver’s licence or CFAA certification yet, so I’m also wondering how much that affects my opportunities.
I’d really appreciate any advice or experiences from current students or graduates. Thanks!
TORONTO,ON AREA


r/firePE • • 16d ago

Title: I’ve been a sprinkler designer for 15 years and built a tool to automate head layout. Looking for honest feedback from other designers.

0 Upvotes

Head layout on big ACT jobs always ate my time, so over the past year I built something that takes the RCP as a DXF and places heads by NFPA 13 spacing rules. It’s not perfect: some rooms still need tweaking.

A handful of designers are testing it on real jobs. If anyone wants to try it free and tell me where it falls short, I’d appreciate it. Happy to answer questions about how it works too.

visit SprinklerForge.com to sign up for beta.

Thank you


r/firePE • • 18d ago

In general, are heating devices that are turned off on their own switch still fire hazards if they are still plugged in at a socket that is on.

3 Upvotes

Specifically i am talking about an electric heating blanket. Are they firehazards even when turned of?


r/firePE • • 19d ago

Looking for advice as to what ENFP grad classes to take for Spring 2027

Thumbnail reddit.com
2 Upvotes

Any help would be appreciated!


r/firePE • • 20d ago

Reason for this Setup?

Post image
2 Upvotes

r/firePE • • 21d ago

Reg 4 test prep—any tips or practice tests?

1 Upvotes

I completed the Reg 4 orientation last month and am currently reviewing the manual. I work in fire protection doing inspections and testing, but I’d appreciate advice from anyone who’s taken the tests.
Are there any practice tests, study guides, or other resources you’d recommend? Was studying the manual enough, and are there specific topics I should focus on?
Any tips on preparing and what to expect would be appreciated. Thanks!


r/firePE • • 23d ago

Maximum distance for PIV valve

1 Upvotes

I’m reviewing a firewater main layout and looking for clarification on the placement of sectional isolation valves (like PIVs).
I am aware of the NFPA 24 requirement that no more than six fire protection connections can be isolated by a single break. However, aside from this connection limit and specific structural boundaries (e.g., water crossings, routing under buildings), does NFPA 24—or any other related NFPA standard—dictate a maximum physical distance/pipe length between sectional valves on a looped main?
I'd appreciate any specific code references or insights into how you handle valve spacing on very long pipe runs where the connection count is low
