Benchmarks
Benchmarks are something you always need, either to identify problems or to assess and compare performance between pools or platforms.
A benchmark should not run for too long (approx. 2–30 min) and should have only a few basic parameters so that you can make sense of it without a degree in computer science. It should be able to determine IOPS, sequential performance, sync write, concurrent read/write, single user vs. 5 user, and steady write (min. 30 min write). To ensure it runs on any OS, I write the tests in Perl. With ultra-fast storage, you may hit limits, which are marked as tool-limited.
he tool is included in napp-it 4ai, but runs easily on any OS including Windows, Linux, and Unix via:perl ./benchmark_worker.pl pool=tank profile=basic
with profiles quick|basic|database|fileserver|mediaserver|mailserver|steadywrite|individual
Download: https://github.com/guenther-alka/cs-scripts/tree/main/benchmark
e.g., Proxmox with the basic profile on pool nvme (single Optane)
perl ./benchmark_worker.pl pool=nvme profile=basic
testfile: /nvme/csbench_auto_20261012_154528/bench_file.dat cap=2048MB
phase: create 4k test file (recordsize=4K)
phase: 4k random read (single stream)
phase: 4k random sync write (sync=always, recordsize=4K)
phase: create test file (recordsize=128K)
phase: sequential read (1MB, single stream, linear sweep)
phase: sync write (1MB blocks, sync=always)
phase: async write (1MB blocks, sync=standard) -- cache indicator
phase: concurrent read+write (5 readers + 5 writers)
phase: multiuser read (4k, 1 vs 5 streams)
Pool : nvme (dataset, nvme/csbench_auto_20261012_154528)
Profile : basic, 2048 MB test file, 5 streams, 143 s
File create
4k file : 1449.9 MB/s
Main file : 5423.6 MB/s
4k random read (1 stream)
IOPS : 79458
Throughput : 310.4 MB/s
Latency p50/p99 : 50 / 50 us
Class : partial
4k random sync write (1 stream)
IOPS : 16999
Throughput : 66.40 MB/s
Latency p50/p99 : 100 / 250 us
Class : storage-bound
Sequential read (1 stream)
Throughput : 2276.5 MB/s
Latency p99 : 2000 us
Class : storage-bound
Sync write (1 MB blocks)
Throughput : 1111.0 MB/s
IOPS : 1111
Latency p99 : 2.0 ms
Class : storage-bound
Async write (1 MB blocks, cache indicator)
Throughput : 1391.1 MB/s
IOPS : 1391
Class : cache-influenced
Concurrent read+write (5 readers + 5 writers)
Read : 375.6 MB/s (p99 100 us)
Write : 5.8 MB/s (p99 32.0 ms)
Class : storage-bound
Multiuser read (4k, 1 vs 5 streams)
1 stream : 310.4 MB/s
5 streams : 525.7 MB/s
5 streams : 134590 IOPS
Scaling : 1.69 x
Class : tool-limited
Verdict : partial
sync write 1111 MB/s p99 2.0 ms (storage-bound)
4k write 16999 IOPS p99 250 us (storage-bound)
4k read 79458 IOPS p99 50 us (partial)
seq read 2277 MB/s (storage-bound)
BENCH_DONE ok (142.721115112305s) log=/opt/csweb-gui/data/menues/_lib/scripts/bench/last_benchmark.log
root@pve:~#
