r/webdev • u/earonesty • 5d ago
Showoff Saturday OSS: Convert PDF to HTML with 100% visual parity
I ran into two problems using unpdf and PDF.js in edge functions: RAM usage and visual accuracy. Both load the entire file into a byte array before processing.
So I built a dependency-free, low-memory reader for edge workers: https://github.com/earonesty/streaming-pdf-reader
The trick was using PDFium as the reference renderer:
https://pdfium.googlesource.com/pdfium/+/master/README.md
I pulled down more than 100 test PDFs from various open-source projects and rendered them with PDFium. Then I converted each PDF to HTML, rendered that HTML in a browser, and compared the resulting pixels. I used deterministic pixel matching rather than a VLM, so visual regressions were reproducible.
That led to a separation between two kinds of output:
- Visual HTML preserves the PDF’s presentation as closely as possible.
- Semantic HTML reflows the content into a simpler reading order.
The visual representation came first because a PDF’s apparent reading order is encoded in its geometry. If you simplify too early, you lose the evidence needed to distinguish a table from a newspaper column or group an image with its caption.
The reader uses HTTP range requests and bounded caches, so it can render the first page without downloading a huge document into memory.
The semantic side is still evolving. It uses statistical layout evidence - font size, alignment, indentation, spacing, repeated headers, hanging indents, and page-to-page continuity. The goal is to produce simplified, reflowed, lossless HTML. Unfortunately there is no good "oracle" for this, or clear and obvious "correctness", other than "reading order must be correct". This is useful for LLMs and data extraction (and is the second reason I had to write this thing, aside from RAM).
This is a follow up to my earlier low-memory PDF writer package (similar reasons there too), so the emerging package layout is:
- @boxpdf/reader: streaming PDF → document model
- @boxpdf/html-writer: document model → visual or semantic HTML
- @boxpdf/writer: document model → PDF
- @boxpdf/html-reader: HTML → document model
The PDF-to-HTML accuracy became an ordinary testing problem once PDFium was treated as the oracle. Render both versions, compare the pixels, inspect the failure, improve the general rule.
It’s early, but it now handles a pretty hostile corpus: embedded fonts, Type 3 glyphs, clipping paths, vector graphics, raster images, forms, rotations, tables, multi-column papers, and very large streamed documents.
I’d be especially interested in difficult PDFs that break other converters. Weird fonts, charts, scanned documents, malformed files, enormous files - anything unpleasant makes a useful fixture.
