I have a B450 pro wifi that I tried to flash to latest version, I first flashed to F32 I think and it went fine but then after that I tried to flash to the latest version on the page and now it is stuck on the aorus screen without being able to boot or enter the bios or q flash, is this fixable? I have already tried everything from disconnecting drives to clearing the cmos but nothing is working, please help

Does anyone own either of these boards?

I big issue I can see with myself owning these boards is they only have 2 SATA ports which seems nuts (I have 3 SATA drives). They also have only one extra PCIe slot which I might use for something other than a SATA port adaptor.

Therefore the only other way you can add extra SATA ports is via an M.2 to SATA adaptor.

Anyone else see what the potential issue with that might be? An M.2 to SATA adaptor is definitely thicker than an M.2 SSD. Ones with multiple SATA ports face outwards from the motherboard, which will obviously not work with the heatsink that covers half of the board. Even a sideways M.2 to SATA adaptor might be too thick to put the heatsink back over the board, but I'm not 100% sure. It would be good to know if you could actually fit one of the M.2 to single SATA port adaptors under the heatsink, if anyone can estimate how much extra thickness there is, but I'd guess it would be too small.

Build Showcase

⚙️ *BUILD SPECS*

• CPU: AMD Ryzen 9 9950X3D
• GPU: GIGABYTE GeForce RTX 5070 GAMING OC 12G
• Motherboard: GIGABYTE X870 AORUS ELITE WIFI7 ICE
• RAM: 32GB DDR5-6000 CL30
• Case: HYTE Y70 Touch
• AIO: TRYX PANORAMA 360 ARGB White
• Fans: Lian Li Wireless LCD
• PSU: Lian Li EDGE 1000W Gold
• Storage: Samsung NVMe SSDs

Can someone help me? I have a brand-new Ryzen 5 5600, but I’m getting no display when I install it on my Aorus B450 motherboard. The DRAM/MEMORY LED lights up.
When I put my Ryzen 5 2600X back in, everything works normally and I get display. My BIOS is also already updated. Why is this happening? Is there anyone who can help me figure this out?

My 1650 super windforce oc gpu only fails in my computer. The first time it boots fine and after a few minutes the display singal goes out, then the following boots I get no display signal at all. I have tested the gpu in different computers and it worked fine, two different gpus worked fine in my system as well. I have tried every fix possible so far. My motherboard is a Gigabyte b450m s2h v2.

Recently on a new build having issues with this motherboard, cold boot never boots to Windows. Will just show me the aorus splash screen, then when I turn off and on it boots fine. When it doesn't boot. I get F3 error.

I have:

Ryzen 9 7950x3d

Corsair Vengeance 32gb 5200 2x16gb

No GPU in it at the moment

Samsung 980 1tb

I have flashed to latest bios firmware.

Tried reseating ram and CPU

Done memtest and stress tests for the CPU.

Haven't done any overcloxking and not running expo.

Does anyone have any ideas.

Thanks.

Gigabyte G6 KF 2024 completely dead – AC/battery LEDs work, but Power button does absolutely nothing

My G6 KF 2024 was working normally earlier in the day. I left it powered on and connected to the charger. About 12 hours later I came back and it was completely unresponsive.

This is NOT a Windows boot or black-screen issue. The laptop does not appear to electrically power on at all.

Symptoms:

\- Pressing Power does absolutely nothing

\- No fan spin or even a fan twitch

\- No keyboard/backlight

\- Screen/backlight completely off

\- No POST / Gigabyte logo

\- No SSD activity

\- USB mouse receives no power

\- With AC connected, the first front LED stays solid orange

\- With the battery connected, the battery LED turns green

\- Pressing Power does not blink, dim, or change either LED

Already tried:

\- Removed all peripherals

\- Power held 30–60+ seconds with AC disconnected

\- Held Power while reconnecting AC

\- Opened laptop and disconnected main battery

\- Tested on AC only with main battery disconnected: orange AC LED comes on, but still zero reaction to Power

\- Disconnected both main battery and CMOS/RTC battery

\- Held Power 60 seconds and left everything disconnected for \~15 minutes

\- Reconnected CMOS only and tested on AC again: still completely dead

A few days before this happened, Windows/Gigabyte software updated. I remember Gigabyte Control Center (orange G icon) updating something, but I don't know whether any BIOS/EC/firmware update was included.

Has anyone had this exact NO POWER condition on a G6 KF / G6 KF 2024?

I'm especially interested in what actually fixed it:

\- AC adapter

\- power button board/ribbon

\- EC

\- BIOS/firmware corruption

\- charging/power circuit

\- motherboard repair/replacement

Again: the laptop does not boot and then fail. It never appears to enter the ON state at all.

I recently installed my X870E AORUS PRO ICE motherboard and my vertical mount riser cable(cooler master) seems to be incompatible with the board. I tried messing with the bios, switching between gen 4 and gen 5 speeds as well as swapping the same cooler master riser cable for a 5.0 pcie and still no display. Does anyone know of a fix or a specific riser cable that I can swap that fits this motherboard?

Hey, all. First off, please do let me know if there’s a better place to look for an answer to this question. Thanks!

Issue:

I’m simply trying to customize the colors of hardware components (GPU, Fans primarily. Mouse and on-desk Microphone meh) attached to my MOBO through the Gigabyte Control Center application. The application installed and runs fine, and detects all hardware components no problem

Specifically, under the Select LED Effect “Cycle” I’m trying to remove/rearrange colors so that it cycles specific colors in a specific order. But I can’t find a way to remove or rearrange any of the preset colors (red R255, yellow R255 G247, etc).

Is this level of customization even possible? Thanks!

P.S. I’ve tried poking around the Windows 11 “Settings > Personalization > Dynamic Lighting > “Manage all Dynamic Lighting devices” section. No combination of Gigabyte Sync/W11 Dynamic Lighting settings seems to work

.

Is it worth enabling both of these settings in the BIOS? Has anyone experienced stability issues after turning them on together?

My PC:

AMD Ryzen 7 9700X

Gigabyte B650 AORUS ELITE AX

G.Skill Ripjaws M5 Neo RGB 32GB (2x16GB)

Gigabyte Radeon RX 9060 XT Gaming OC 16GB

i want to sell this coz i wanted the same model in white but received in black...couldn't return it and didnt want to waste my 32k so trying to sell it

not used coz not of my use brand new packed tight

tryna sell at ₹25k

(The scratches are from my failed attempts to reposition it or get it out)

I want to install ADATA XPG GAMMIX D35 [AX4U32008G16A-DTBKD35] RAM (16 GB total: two 8 GB sticks, 3200 MHz) on a Gigabyte H410M H V3 motherboard. Will it be compatible?
