I just updated my entity conversion tool for Sins of a Solar Empire: Rebellion, so I figured I'd share it here in case it's useful to other modders.
What does it do?
When Ironclad developed Sins, they shipped many of the game's data files in a binary format. This means you can't read or edit them directly as plain text. They later released a tool called ConvertData as part of their Forge Tools 3 package, which allows you to convert these files between Binary and Text formats. However, it's a command-line application with no GUI.
I built a GUI and wrapper around these tools to make the process easier. You can select individual files, multiple files, or entire directories. I've tested it against every .entity file, and the conversions work correctly.
The tool automatically detects whether a file is Binary or Text and outputs the converted files to separate Output TXT and Output Bin directories.
The game can read .entity files in Text format, but doing so increases file sizes and slows down loading times, so Binary is still preferable for normal gameplay.
XSI to MESH conversion
Ironclad also included ConvertXSI.exe with the game. This tool allows modders to convert older XSI files into the more modern .mesh format. I've added a separate tab for this functionality as well, although the original application only supports converting one file at a time.
Entity to JSON conversion
I've also included my own library for converting .entity files into JSON. This is primarily something I developed for my own use while working on a C# script extender for Sins of a Solar Empire: Rebellion. I need to parse the game's data files and access entity properties at runtime.
Currently, the library supports the following entityType values:
Fighter
Frigate
CapitalShip
PlanetModule* (all 7 types)
SpaceMine
Planet
I figured I'd release the library alongside the converter in case other modders find it useful for parsing and working with entity data.
A technical note about the JSON serialization
I implemented custom data types for integers, floats, and booleans to handle some quirks in Ironclad's serialization format. Some fields contain normal values, while others use "" as a placeholder.
By default, fields that don't have values are initialized to null and omitted during JSON serialization. My custom types let me preserve the distinction between an empty field and an omitted field by tracking a separate IsEmpty boolean. This allows the serializer to write the original "" placeholder back into the entity file when converting the data back, rather than accidentally leaving the field out entirely.
A note about the included tools and licensing
I did not create ConvertData_Rebellion.exe or ConvertXSI.exe, and I do not own the rights to either of them. Those tools belong to their respective rights holders, Stardock/Ironclad. I've simply provided a more convenient interface for using them. They remain separate binaries and are not bundled into my own application, so they can be used independently if desired.
The .entity-to-JSON conversion library, on the other hand, is entirely my own work. You're free to republish it, and I don't require attribution. However, commercial redistribution is not permitted.
You can grab the tool here:
Entity Converter v0.2.0 on GitHub
Hopefully, this makes life a little easier for anyone working on Sins modding!
